A 316 module is an austenitic grade of stainless steel designed with a superior composition of chromium, nickel, and molybdenum. The Marine grade 316 Stainless Steel Tubing has excellent resistance to corrosive and oxidative media. These tubes also showcase outstanding tolerance against pitting and crevice corrosion in marine ecosystems. The versatile grade of tubes are generally designed in a seamless and welded configuration. A Stainless Steel 316 seamless Tubing is a high-strength grade produced via an extrusion process. Here hot steel billets are passed through metal, allowing them to be shaped in correct dimensions. These tubes have a 20% higher load-bearing capacity than welded tubes. The UNS S31600 Welded Tube has welds or seams as strips or sheets are rolled followed by welding them in place following standard procedures. These tubes may have lower strength compared to seamless pipes, but they are cheaper and can be availed in different sizes.
A SS grade 1.4401 Tube showcases outstanding mechanical and physical properties. The versatile grade of pipes have a minimum tensile strength of 515Mpa. These plates have minimum yield strength of 205Mpa. They can be readily elongated by 40% and have a hardness of 217 Brinell. The WNR. 1.4401 Seamless Tube has a rectangular cross section and has a density of 8 g/cm3 with an elastic modulus of 193GPA. These tubes showcase a thermal conductivity of 16.3 at 100 degrees C. Our institution is the leading 316 stainless steel tube supplier that can provide the best products in a short time frame due to our ties with different logistical chains and supply systems. The tubes of this grade at our outlets are quality assured and the best in the market. If you have any queries or want to know more about the 316 tubes or our other products, visit any of our outlets or contact us for added information.
Table of Content
Standard Specifiaction | 316 Stainless Steel Tube |
---|---|
Wall Thickness (WT) | Schedule 5S to XXS |
Seamless Tube Sizes | 1/2 upto 8 inch Nominal Bore |
Processing | Polishing, Polished Grit 120 to 600, Cut-to-length |
ERW Tube Sizes | 1/2 upto 24 inch Nominal Bore |
Length | Single Random, Double Random, Cut Length |
EFW Tube Sizes | 6 upto 100 inch Nominal Bore |
End | Plain End, Beveled End, Treaded |
Materials Testing | CRYO SERVICE, H2 SERVICE, OXYGEN SERVICE, NACE MR0175 |
Per Kg
SS 316 Bright Annealed Stainless Steel Tube
$ 3.10
Per Kg
22*1.5 304 Round Seamless stainless steel tubes
$ 5.17
Per Kg
Stainless Steel 316 Schedule 40 Hollow Pipe tube
$ 4.03
316 Stainless Steel Tubes
Stainless Steel 316 seamless Tube
Marine grade 316 Stainless Steel Tubing
WNR. 1.4401 Seamless Tube
UNS S31600 Welded Tubing
SS 316 Seamless Tube
Stainless Steel 316 Tubing
AISI 316 Tube
SS grade 1.4401 Tube
Outer Diameter in Inch | Working Pressure (PSI) 25% of Burst | Wall Thickness in Inch | Yield Strength (PSI) | Theoretical Burst Pressure * (PSI) | Collapse Pressure *** (PSI) | Theoretical Yield Point ** (PSI) | Tensile Strength (PSI) |
---|---|---|---|---|---|---|---|
0.250 | 3,571 | 0.020 | 30,000 | 14,286 | 4,416 | 5,714 | 75,000 |
0.250 | 5,412 | 0.028 | 30,000 | 21,649 | 5,967 | 8,660 | 75,000 |
0.250 | 7,292 | 0.035 | 30,000 | 29,167 | 7,224 | 11,667 | 75,000 |
0.250 | 12,089 | 0.049 | 30,000 | 48,355 | 9,455 | 19,342 | 75,000 |
0.250 | 20,313 | 0.065 | 30,000 | 81,250 | 11,544 | 32,500 | 75,000 |
0.375 | 2,239 | 0.020 | 30,000 | 8,955 | 3,029 | 3,582 | 75,000 |
0.375 | 3,292 | 0.028 | 30,000 | 13,166 | 4,145 | 5,266 | 75,000 |
0.375 | 4,303 | 0.035 | 30,000 | 17,213 | 5,077 | 6,885 | 75,000 |
0.375 | 6,634 | 0.049 | 30,000 | 26,534 | 6,816 | 10,614 | 75,000 |
0.375 | 9,949 | 0.065 | 30,000 | 39,796 | 8,597 | 15,918 | 75,000 |
0.500 | 1,630 | 0.020 | 30,000 | 6,522 | 2,304 | 2,609 | 75,000 |
0.500 | 2,365 | 0.028 | 30,000 | 9,459 | 3,172 | 3,784 | 75,000 |
0.500 | 3,052 | 0.035 | 30,000 | 12,209 | 3,906 | 4,884 | 75,000 |
0.500 | 4,571 | 0.049 | 30,000 | 18,284 | 5,304 | 7,313 | 75,000 |
0.500 | 6,588 | 0.065 | 30,000 | 26,351 | 6,786 | 10,541 | 75,000 |
0.500 | 9,319 | 0.083 | 30,000 | 37,275 | 8,307 | 14,910 | 75,000 |
0.625 | 1,282 | 0.020 | 30,000 | 5,128 | 1,859 | 2,051 | 75,000 |
0.625 | 1,845 | 0.028 | 30,000 | 7,381 | 2,568 | 2,953 | 75,000 |
0.625 | 2,365 | 0.035 | 30,000 | 9,459 | 3,172 | 3,784 | 75,000 |
0.625 | 3,487 | 0.049 | 30,000 | 13,947 | 4,335 | 5,579 | 75,000 |
0.625 | 4,924 | 0.065 | 30,000 | 19,697 | 5,591 | 7,879 | 75,000 |
0.625 | 6,781 | 0.083 | 30,000 | 27,124 | 6,910 | 10,850 | 75,000 |
0.625 | 8,190 | 0.095 | 30,000 | 32,759 | 7,734 | 13,103 | 75,000 |
0.625 | 10,043 | 0.109 | 30,000 | 40,172 | 8,639 | 16,069 | 75,000 |
0.750 | 1,513 | 0.028 | 30,000 | 6,052 | 2,156 | 2,421 | 75,000 |
0.750 | 1,930 | 0.035 | 30,000 | 7,721 | 2,669 | 3,088 | 75,000 |
0.750 | 2,818 | 0.049 | 30,000 | 11,273 | 3,664 | 4,509 | 75,000 |
0.750 | 3,931 | 0.065 | 30,000 | 15,726 | 4,749 | 6,290 | 75,000 |
0.750 | 5,330 | 0.083 | 30,000 | 21,318 | 5,905 | 8,527 | 75,000 |
0.750 | 6,362 | 0.095 | 30,000 | 25,446 | 6,637 | 10,179 | 75,000 |
0.750 | 7,683 | 0.109 | 30,000 | 30,733 | 7,453 | 12,293 | 75,000 |
0.750 | 8,824 | 0.120 | 30,000 | 35,294 | 8,064 | 14,118 | 75,000 |
0.875 | 898 | 0.020 | 30,000 | 3,593 | 1,340 | 1,437 | 75,000 |
0.875 | 1,282 | 0.028 | 30,000 | 5,128 | 1,859 | 2,051 | 75,000 |
0.875 | 1,630 | 0.035 | 30,000 | 6,522 | 2,304 | 2,609 | 75,000 |
0.875 | 2,365 | 0.049 | 30,000 | 9,459 | 3,172 | 3,784 | 75,000 |
0.875 | 3,272 | 0.065 | 30,000 | 13,087 | 4,126 | 5,235 | 75,000 |
0.875 | 4,390 | 0.083 | 30,000 | 17,560 | 5,152 | 7,024 | 75,000 |
0.875 | 5,201 | 0.095 | 30,000 | 20,803 | 5,807 | 8,321 | 75,000 |
0.875 | 6,221 | 0.109 | 30,000 | 24,886 | 6,543 | 9,954 | 75,000 |
0.875 | 7,087 | 0.120 | 30,000 | 28,346 | 7,100 | 11,339 | 75,000 |
1.000 | 1,112 | 0.028 | 30,000 | 4,449 | 1,633 | 1,780 | 75,000 |
1.000 | 1,411 | 0.035 | 30,000 | 5,645 | 2,027 | 2,258 | 75,000 |
1.000 | 2,037 | 0.049 | 30,000 | 8,149 | 2,796 | 3,259 | 75,000 |
1.000 | 2,802 | 0.065 | 30,000 | 11,207 | 3,647 | 4,483 | 75,000 |
1.000 | 3,732 | 0.083 | 30,000 | 14,928 | 4,567 | 5,971 | 75,000 |
1.000 | 4,398 | 0.095 | 30,000 | 17,593 | 5,159 | 7,037 | 75,000 |
1.000 | 5,227 | 0.109 | 30,000 | 20,908 | 5,827 | 8,363 | 75,000 |
1.000 | 5,921 | 0.120 | 30,000 | 23,684 | 6,336 | 9,474 | 75,000 |
1.000 | 6,865 | 0.134 | 30,000 | 27,459 | 6,963 | 10,984 | 75,000 |
1.250 | 1,112 | 0.035 | 30,000 | 4,449 | 1,633 | 1,780 | 75,000 |
1.250 | 1,595 | 0.049 | 30,000 | 6,380 | 2,260 | 2,552 | 75,000 |
1.250 | 2,176 | 0.065 | 30,000 | 8,705 | 2,958 | 3,482 | 75,000 |
1.250 | 2,871 | 0.083 | 30,000 | 11,485 | 3,719 | 4,594 | 75,000 |
1.250 | 3,361 | 0.095 | 30,000 | 13,443 | 4,213 | 5,377 | 75,000 |
1.250 | 3,961 | 0.109 | 30,000 | 15,843 | 4,776 | 6,337 | 75,000 |
1.250 | 4,455 | 0.120 | 30,000 | 17,822 | 5,207 | 7,129 | 75,000 |
1.250 | 5,117 | 0.134 | 30,000 | 20,468 | 5,742 | 8,187 | 75,000 |
1.500 | 918 | 0.035 | 30,000 | 3,671 | 1,367 | 1,469 | 75,000 |
1.500 | 1,311 | 0.049 | 30,000 | 5,243 | 1,896 | 2,097 | 75,000 |
1.500 | 1,779 | 0.065 | 30,000 | 7,117 | 2,487 | 2,847 | 75,000 |
1.500 | 2,333 | 0.083 | 30,000 | 9,333 | 3,136 | 3,733 | 75,000 |
1.500 | 2,719 | 0.095 | 30,000 | 10,878 | 3,559 | 4,351 | 75,000 |
1.500 | 3,188 | 0.109 | 30,000 | 12,754 | 4,043 | 5,101 | 75,000 |
1.500 | 3,571 | 0.120 | 30,000 | 14,286 | 4,416 | 5,714 | 75,000 |
1.500 | 4,079 | 0.134 | 30,000 | 16,315 | 4,881 | 6,526 | 75,000 |
1.500 | 4,610 | 0.148 | 30,000 | 18,439 | 5,336 | 7,375 | 75,000 |
1.750 | 781 | 0.035 | 30,000 | 3,125 | 1,176 | 1,250 | 75,000 |
1.750 | 966 | 0.049 | 30,000 | 3,864 | 1,434 | 1,546 | 75,000 |
1.750 | 1,505 | 0.065 | 30,000 | 6,019 | 2,146 | 2,407 | 75,000 |
1.750 | 1,965 | 0.083 | 30,000 | 7,860 | 2,711 | 3,144 | 75,000 |
1.750 | 2,284 | 0.095 | 30,000 | 9,135 | 3,080 | 3,654 | 75,000 |
1.750 | 2,668 | 0.109 | 30,000 | 10,672 | 3,504 | 4,213 | 75,000 |
1.750 | 2,980 | 0.120 | 30,000 | 11,921 | 3,832 | 4,768 | 75,000 |
1.750 | 3,391 | 0.134 | 30,000 | 13,563 | 4,242 | 5,425 | 75,000 |
1.750 | 3,817 | 0.148 | 30,000 | 15,268 | 4,645 | 6,107 | 75,000 |
1.750 | 4,357 | 0.165 | 30,000 | 17,430 | 5,124 | 6,972 | 75,000 |
2.000 | 680 | 0.035 | 30,000 | 2,720 | 1,032 | 1,088 | 75,000 |
2.000 | 966 | 0.049 | 30,000 | 3,864 | 1,434 | 1,546 | 75,000 |
2.000 | 1,303 | 0.065 | 30,000 | 5,214 | 1,887 | 2,086 | 75,000 |
2.000 | 1,697 | 0.083 | 30,000 | 6,788 | 2,387 | 2,715 | 75,000 |
2.000 | 1,968 | 0.095 | 30,000 | 7,873 | 2,715 | 3,149 | 75,000 |
2.000 | 2,294 | 0.109 | 30,000 | 9,175 | 3,092 | 3,670 | 75,000 |
2.000 | 2,557 | 0.120 | 30,000 | 10,227 | 3,384 | 4,091 | 75,000 |
2.000 | 2,901 | 0.134 | 30,000 | 11,605 | 3,751 | 4,642 | 75,000 |
2.000 | 3,257 | 0.148 | 30,000 | 13,028 | 4,111 | 5,211 | 75,000 |
2.000 | 3,705 | 0.165 | 30,000 | 14,820 | 4,542 | 5,928 | 75,000 |
Grade | Carbon | Manganese | Sulfur | Silicon | Chromium | Phosphorus | Molybdenum | Nickel | |
316 | Minimum. | 16.0 | 2.0-3.0 | 10.0 | |||||
Maximum | 0.035 | 2.0 | 0.030 | 0.75 | 18.0 | 0.045 | 14.0 |
Grade | Yield Properties | Tensile Properties | Elongational | Hardness | |
Brinell | Rockwell B | ||||
316 | 205 | 515 | 40 | 217 | 95 |
Grade | Density | Thermal Conductivity | Electrical Resistivity (n.m) | Modulus | Mean Coefficient | Specific Heat from 0 to 1000C | |||
at 5000C | at 1000C | 0-3150C | 0-1000C | 0-5380C | |||||
316 | 7750 | 18.7 | 14.2 | 720 | 200 | 16.2 | 15.9 | 17.0 | 500 |
Standards | Unified Numbering System | British Standards | GOST | WERKSTOFF NR. | JIS | European Standards | AFNOR |
SS 316 | S31600 | 316S33 / 316S31 | – | 1.4401 / 1.4436 | SUS 316 | X3CrNiMo17-13-3 / X5CrNiMo17-12-2 | Z7CND17‐11‐02 |
Outer Diameter in inch | Tube Cross Sectional Area (in2) | Wall Thickness in inch | Internal Area (in2) | D/t Ratio | Inner daimeter in inch |
---|---|---|---|---|---|
0.250 | 0.0145 | 0.020 | 0.0346 | 12.50 | 0.210 |
0.250 | 0.0195 | 0.028 | 0.0296 | 8.93 | 0.194 |
0.250 | 0.0236 | 0.035 | 0.0254 | 7.14 | 0.180 |
0.250 | 0.0309 | 0.049 | 0.0181 | 5.10 | 0.152 |
0.250 | 0.0378 | 0.065 | 0.0113 | 3.85 | 0.120 |
0.375 | 0.0223 | 0.020 | 0.0881 | 18.75 | 0.335 |
0.375 | 0.0305 | 0.028 | 0.0799 | 13.39 | 0.319 |
0.375 | 0.0374 | 0.035 | 0.0731 | 10.71 | 0.305 |
0.375 | 0.0502 | 0.049 | 0.0603 | 7.65 | 0.277 |
0.375 | 0.0633 | 0.065 | 0.0471 | 5.77 | 0.245 |
0.500 | 0.0302 | 0.020 | 0.1662 | 25.00 | 0.460 |
0.500 | 0.0415 | 0.028 | 0.1548 | 17.86 | 0.444 |
0.500 | 0.0511 | 0.035 | 0.1452 | 14.29 | 0.430 |
0.500 | 0.0694 | 0.049 | 0.1213 | 10.20 | 0.402 |
0.500 | 0.0888 | 0.065 | 0.1075 | 7.69 | 0.370 |
0.500 | 0.1087 | 0.083 | 0.0876 | 6.02 | 0.334 |
0.625 | 0.0380 | 0.020 | 0.2688 | 31.25 | 0.585 |
0.625 | 0.0525 | 0.028 | 0.2543 | 22.32 | 0.569 |
0.625 | 0.0649 | 0.035 | 0.2419 | 17.86 | 0.555 |
0.625 | 0.0887 | 0.049 | 0.2181 | 12.76 | 0.527 |
0.625 | 0.1144 | 0.065 | 0.1924 | 9.62 | 0.495 |
0.625 | 0.1413 | 0.083 | 0.1655 | 7.53 | 0.459 |
0.625 | 0.1582 | 0.095 | 0.1486 | 6.58 | 0.435 |
0.625 | 0.1767 | 0.109 | 0.1301 | 5.73 | 0.407 |
0.750 | 0.0635 | 0.028 | 0.3783 | 26.79 | 0.694 |
0.750 | 0.0786 | 0.035 | 0.3632 | 21.43 | 0.680 |
0.750 | 0.1079 | 0.049 | 0.3339 | 15.31 | 0.652 |
0.750 | 0.1399 | 0.065 | 0.3019 | 11.54 | 0.620 |
0.750 | 0.1739 | 0.083 | 0.2679 | 9.04 | 0.584 |
0.750 | 0.1955 | 0.095 | 0.2463 | 7.89 | 0.560 |
0.750 | 0.2195 | 0.109 | 0.2223 | 6.88 | 0.532 |
0.750 | 0.2375 | 0.120 | 0.2043 | 6.25 | 0.510 |
0.875 | 0.0537 | 0.020 | 0.5476 | 43.75 | 0.835 |
0.875 | 0.0745 | 0.028 | 0.5268 | 31.25 | 0.819 |
0.875 | 0.0924 | 0.035 | 0.5090 | 25.00 | 0.805 |
0.875 | 0.1272 | 0.049 | 0.4742 | 17.86 | 0.777 |
0.875 | 0.1654 | 0.065 | 0.4359 | 13.46 | 0.745 |
0.875 | 0.2065 | 0.083 | 0.3948 | 10.54 | 0.709 |
0.875 | 0.2328 | 0.095 | 0.3685 | 9.21 | 0.685 |
0.875 | 0.2623 | 0.109 | 0.3390 | 8.03 | 0.657 |
0.875 | 0.2846 | 0.120 | 0.316L7 | 7.29 | 0.635 |
1.000 | 0.0855 | 0.028 | 0.6999 | 35.71 | 0.944 |
1.000 | 0.1061 | 0.035 | 0.6793 | 28.57 | 0.930 |
1.000 | 0.1464 | 0.049 | 0.6390 | 20.41 | 0.902 |
1.000 | 0.1909 | 0.065 | 0.5945 | 15.38 | 0.870 |
1.000 | 0.2391 | 0.083 | 0.5463 | 12.05 | 0.834 |
1.000 | 0.2701 | 0.095 | 0.5153 | 10.53 | 0.810 |
1.000 | 0.3051 | 0.109 | 0.4803 | 9.17 | 0.782 |
1.000 | 0.3318 | 0.120 | 0.4536 | 8.33 | 0.760 |
1.000 | 0.3646 | 0.134 | 0.4208 | 7.46 | 0.732 |
1.250 | 0.1336 | 0.035 | 1.0936 | 35.71 | 1.180 |
1.250 | 0.1849 | 0.049 | 1.0423 | 25.51 | 1.152 |
1.250 | 0.2420 | 0.065 | 0.9852 | 19.23 | 1.120 |
1.250 | 0.316L3 | 0.083 | 0.9229 | 15.06 | 1.084 |
1.250 | 0.3447 | 0.095 | 0.8825 | 13.16 | 1.060 |
1.250 | 0.3907 | 0.109 | 0.8365 | 11.47 | 1.032 |
1.250 | 0.4260 | 0.120 | 0.8012 | 10.42 | 1.010 |
1.250 | 0.4698 | 0.134 | 0.7574 | 9.33 | 0.982 |
1.500 | 0.1611 | 0.035 | 1.6061 | 42.86 | 1.430 |
1.500 | 0.2234 | 0.049 | 1.5438 | 30.61 | 1.402 |
1.500 | 0.2930 | 0.065 | 1.4741 | 23.08 | 1.370 |
1.500 | 0.3695 | 0.083 | 1.3977 | 18.07 | 1.334 |
1.500 | 0.4193 | 0.095 | 1.3478 | 15.79 | 1.310 |
1.500 | 0.4763 | 0.109 | 1.2908 | 13.76 | 1.282 |
1.500 | 0.5202 | 0.120 | 1.2469 | 12.50 | 1.260 |
1.500 | 0.5750 | 0.134 | 1.1921 | 11.19 | 1.232 |
1.500 | 0.6286 | 0.148 | 1.1385 | 10.14 | 1.204 |
1.750 | 0.1886 | 0.035 | 2.2167 | 50.00 | 1.680 |
1.750 | 0.3003 | 0.049 | 2.8413 | 40.82 | 1.902 |
1.750 | 0.3441 | 0.065 | 2.0612 | 26.92 | 1.620 |
1.750 | 0.4347 | 0.083 | 1.9706 | 21.08 | 1.584 |
1.750 | 0.4939 | 0.095 | 1.9113 | 18.42 | 1.560 |
1.750 | 0.5619 | 0.109 | 1.8433 | 16.06 | 1.532 |
1.750 | 0.6145 | 0.120 | 1.7908 | 14.58 | 1.510 |
1.750 | 0.6803 | 0.134 | 1.7250 | 13.06 | 1.482 |
1.750 | 0.7449 | 0.148 | 1.6604 | 11.82 | 1.454 |
1.750 | 0.8216 | 0.165 | 1.5837 | 10.61 | 1.420 |
2.000 | 0.2161 | 0.035 | 2.9255 | 57.14 | 1.930 |
2.000 | 0.3003 | 0.049 | 2.8413 | 40.82 | 1.902 |
2.000 | 0.3951 | 0.065 | 2.7465 | 30.77 | 1.870 |
2.000 | 0.4999 | 0.083 | 2.6417 | 24.10 | 1.834 |
2.000 | 0.5685 | 0.095 | 2.5730 | 21.05 | 1.810 |
2.000 | 0.6475 | 0.109 | 2.4941 | 18.35 | 1.782 |
2.000 | 0.7087 | 0.120 | 2.4328 | 16.67 | 1.760 |
2.000 | 0.7855 | 0.134 | 2.3561 | 14.93 | 1.732 |
2.000 | 0.8611 | 0.148 | 2.2805 | 13.51 | 1.704 |
2.000 | 0.9512 | 0.165 | 2.1904 | 12.12 | 1.670 |
ASTM Standards
Pipe Specifications
