316L is a low-carbon austenitic grade of stainless steel. The Stainless Steel 316L Tube is designed with a superior composition consisting of nickel, chromium, and molybdenum. The content embedded in these tubes gives them excellent resistance against oxidative and corrosive media across stress-induced environments. The tubes in this grade are generally manufactured in seamless, welded, or erw configuration. Stainless Steel 316L Seamless Tube is produced via an extrusion process as hot steel billets are passed through metal to precisely shape the modules. These tubes have outstanding load-bearing capacity but are expensive compared to the UNS S31603 Welded Tubing due to the material used while producing them. A welded tube is produced by rolling sheets or strips followed by welding them in place, making use of standard welding procedures. The 316L SS ERW Tube is a module that is produced by longitudinally welding the item in place. In this process, a high voltage electric current is passed through the metal to put it in its correct place. We are a 316l Stainless Steel Tube Supplier who provides quality assured products for all our esteemed customers. We have ties with some of the best logistical services and transportation, allowing us to supply products in a short time frame.
A WNR. 1.4404 Tube has excellent strength coupled with mechanical properties. These tubes have a minimum tensile strength of 485mpa with a minimum yield strength of 170mpa. These pipes can be readily elongated by 40% and have a hardness of Brinell 217max HB. These components are usually designed in schedules that help in dictating their pressure-bearing capacity. The AISI 316L Schedule 10 Tube is designed to work in low-pressure applications where the stress on the grade is less. For any queries or questions about our products, visit our outlets or get in touch with our customer service for more information.
Table of Content
Standard Specifiaction | 316L Stainless Steel Tube |
---|---|
Processing | Polishing, Polished Grit 120 to 600, Cut-to-length |
ERW Tube Sizes | 1/2 upto 24 inch Nominal Bore |
Wall Thickness (WT) | Schedule 5S to XXS |
Materials Testing | CRYO SERVICE, H2 SERVICE, OXYGEN SERVICE, NACE MR0175 |
Seamless Tube Sizes | 1/2 upto 8 inch Nominal Bore |
End | Plain End, Beveled End, Treaded |
Length | Single Random, Double Random, Cut Length |
EFW Tube Sizes | 6 upto 100 inch Nominal Bore |
Per Kg
316L Round Schedule 10 Stainless Steel Tube
$ 3.10
Per Kg
SUS 316l 4 Inch welded Stainless Steel tubing
$ 2.89
Per Kg
2 inch 316L Thick Wall Stainless Steel Tube
$ 11.25
316l Stainless Steel Tubes
SS 316L Seamless Tube
Stainless Steel 316L Welded Tubing
ASME B36.10M WNR. 1.4404 Tubes
UNS S31603 Seamless Pipe
AISI 316L Schedule 10 Tube
Stainless Steel 316L Seamless Tube
SS 316L Welded Tube
SS grade 1.4404 Tubes
Outer Diameter in Inch | Internal Area (in2) | Wall Thickness in inch | D/t Ratio | Tube Cross Sectional Area (in2) | Inner Diameter in inch |
---|---|---|---|---|---|
0.250 | 0.0346 | 0.020 | 12.50 | 0.0145 | 0.210 |
0.250 | 0.0296 | 0.028 | 8.93 | 0.0195 | 0.194 |
0.250 | 0.0254 | 0.035 | 7.14 | 0.0236 | 0.180 |
0.250 | 0.0181 | 0.049 | 5.10 | 0.0309 | 0.152 |
0.250 | 0.0113 | 0.065 | 3.85 | 0.0378 | 0.120 |
0.375 | 0.0881 | 0.020 | 18.75 | 0.0223 | 0.335 |
0.375 | 0.0799 | 0.028 | 13.39 | 0.0305 | 0.319 |
0.375 | 0.0731 | 0.035 | 10.71 | 0.0374 | 0.305 |
0.375 | 0.0603 | 0.049 | 7.65 | 0.0502 | 0.277 |
0.375 | 0.0471 | 0.065 | 5.77 | 0.0633 | 0.245 |
0.500 | 0.1662 | 0.020 | 25.00 | 0.0302 | 0.460 |
0.500 | 0.1548 | 0.028 | 17.86 | 0.0415 | 0.444 |
0.500 | 0.1452 | 0.035 | 14.29 | 0.0511 | 0.430 |
0.500 | 0.1213 | 0.049 | 10.20 | 0.0694 | 0.402 |
0.500 | 0.1075 | 0.065 | 7.69 | 0.0888 | 0.370 |
0.500 | 0.0876 | 0.083 | 6.02 | 0.1087 | 0.334 |
0.625 | 0.2688 | 0.020 | 31.25 | 0.0380 | 0.585 |
0.625 | 0.2543 | 0.028 | 22.32 | 0.0525 | 0.569 |
0.625 | 0.2419 | 0.035 | 17.86 | 0.0649 | 0.555 |
0.625 | 0.2181 | 0.049 | 12.76 | 0.0887 | 0.527 |
0.625 | 0.1924 | 0.065 | 9.62 | 0.1144 | 0.495 |
0.625 | 0.1655 | 0.083 | 7.53 | 0.1413 | 0.459 |
0.625 | 0.1486 | 0.095 | 6.58 | 0.1582 | 0.435 |
0.625 | 0.1301 | 0.109 | 5.73 | 0.1767 | 0.407 |
0.750 | 0.3783 | 0.028 | 26.79 | 0.0635 | 0.694 |
0.750 | 0.3632 | 0.035 | 21.43 | 0.0786 | 0.680 |
0.750 | 0.3339 | 0.049 | 15.31 | 0.1079 | 0.652 |
0.750 | 0.3019 | 0.065 | 11.54 | 0.1399 | 0.620 |
0.750 | 0.2679 | 0.083 | 9.04 | 0.1739 | 0.584 |
0.750 | 0.2463 | 0.095 | 7.89 | 0.1955 | 0.560 |
0.750 | 0.2223 | 0.109 | 6.88 | 0.2195 | 0.532 |
0.750 | 0.2043 | 0.120 | 6.25 | 0.2375 | 0.510 |
0.875 | 0.5476 | 0.020 | 43.75 | 0.0537 | 0.835 |
0.875 | 0.5268 | 0.028 | 31.25 | 0.0745 | 0.819 |
0.875 | 0.5090 | 0.035 | 25.00 | 0.0924 | 0.805 |
0.875 | 0.4742 | 0.049 | 17.86 | 0.1272 | 0.777 |
0.875 | 0.4359 | 0.065 | 13.46 | 0.1654 | 0.745 |
0.875 | 0.3948 | 0.083 | 10.54 | 0.2065 | 0.709 |
0.875 | 0.3685 | 0.095 | 9.21 | 0.2328 | 0.685 |
0.875 | 0.3390 | 0.109 | 8.03 | 0.2623 | 0.657 |
0.875 | 0.316L7 | 0.120 | 7.29 | 0.2846 | 0.635 |
1.000 | 0.6999 | 0.028 | 35.71 | 0.0855 | 0.944 |
1.000 | 0.6793 | 0.035 | 28.57 | 0.1061 | 0.930 |
1.000 | 0.6390 | 0.049 | 20.41 | 0.1464 | 0.902 |
1.000 | 0.5945 | 0.065 | 15.38 | 0.1909 | 0.870 |
1.000 | 0.5463 | 0.083 | 12.05 | 0.2391 | 0.834 |
1.000 | 0.5153 | 0.095 | 10.53 | 0.2701 | 0.810 |
1.000 | 0.4803 | 0.109 | 9.17 | 0.3051 | 0.782 |
1.000 | 0.4536 | 0.120 | 8.33 | 0.3318 | 0.760 |
1.000 | 0.4208 | 0.134 | 7.46 | 0.3646 | 0.732 |
1.250 | 1.0936 | 0.035 | 35.71 | 0.1336 | 1.180 |
1.250 | 1.0423 | 0.049 | 25.51 | 0.1849 | 1.152 |
1.250 | 0.9852 | 0.065 | 19.23 | 0.2420 | 1.120 |
1.250 | 0.9229 | 0.083 | 15.06 | 0.316L3 | 1.084 |
1.250 | 0.8825 | 0.095 | 13.16 | 0.3447 | 1.060 |
1.250 | 0.8365 | 0.109 | 11.47 | 0.3907 | 1.032 |
1.250 | 0.8012 | 0.120 | 10.42 | 0.4260 | 1.010 |
1.250 | 0.7574 | 0.134 | 9.33 | 0.4698 | 0.982 |
1.500 | 1.6061 | 0.035 | 42.86 | 0.1611 | 1.430 |
1.500 | 1.5438 | 0.049 | 30.61 | 0.2234 | 1.402 |
1.500 | 1.4741 | 0.065 | 23.08 | 0.2930 | 1.370 |
1.500 | 1.3977 | 0.083 | 18.07 | 0.3695 | 1.334 |
1.500 | 1.3478 | 0.095 | 15.79 | 0.4193 | 1.310 |
1.500 | 1.2908 | 0.109 | 13.76 | 0.4763 | 1.282 |
1.500 | 1.2469 | 0.120 | 12.50 | 0.5202 | 1.260 |
1.500 | 1.1921 | 0.134 | 11.19 | 0.5750 | 1.232 |
1.500 | 1.1385 | 0.148 | 10.14 | 0.6286 | 1.204 |
1.750 | 2.2167 | 0.035 | 50.00 | 0.1886 | 1.680 |
1.750 | 2.8413 | 0.049 | 40.82 | 0.3003 | 1.902 |
1.750 | 2.0612 | 0.065 | 26.92 | 0.3441 | 1.620 |
1.750 | 1.9706 | 0.083 | 21.08 | 0.4347 | 1.584 |
1.750 | 1.9113 | 0.095 | 18.42 | 0.4939 | 1.560 |
1.750 | 1.8433 | 0.109 | 16.06 | 0.5619 | 1.532 |
1.750 | 1.7908 | 0.120 | 14.58 | 0.6145 | 1.510 |
1.750 | 1.7250 | 0.134 | 13.06 | 0.6803 | 1.482 |
1.750 | 1.6604 | 0.148 | 11.82 | 0.7449 | 1.454 |
1.750 | 1.5837 | 0.165 | 10.61 | 0.8216 | 1.420 |
2.000 | 2.9255 | 0.035 | 57.14 | 0.2161 | 1.930 |
2.000 | 2.8413 | 0.049 | 40.82 | 0.3003 | 1.902 |
2.000 | 2.7465 | 0.065 | 30.77 | 0.3951 | 1.870 |
2.000 | 2.6417 | 0.083 | 24.10 | 0.4999 | 1.834 |
2.000 | 2.5730 | 0.095 | 21.05 | 0.5685 | 1.810 |
2.000 | 2.4941 | 0.109 | 18.35 | 0.6475 | 1.782 |
2.000 | 2.4328 | 0.120 | 16.67 | 0.7087 | 1.760 |
2.000 | 2.3561 | 0.134 | 14.93 | 0.7855 | 1.732 |
2.000 | 2.2805 | 0.148 | 13.51 | 0.8611 | 1.704 |
2.000 | 2.1904 | 0.165 | 12.12 | 0.9512 | 1.670 |
Outer Diameter in Inch | Wall Thickness in Inch | Working Pressure (PSI) 25% of Burst | Yield Strength (PSI) | Collapse Pressure *** (PSI) | Theoretical Burst Pressure * (PSI) | Theoretical Yield Point ** (PSI) | Tensile Strength (PSI) |
---|---|---|---|---|---|---|---|
0.250 | 0.020 | 3,571 | 30,000 | 4,416 | 14,286 | 5,714 | 75,000 |
0.250 | 0.028 | 5,412 | 30,000 | 5,967 | 21,649 | 8,660 | 75,000 |
0.250 | 0.035 | 7,292 | 30,000 | 7,224 | 29,167 | 11,667 | 75,000 |
0.250 | 0.049 | 12,089 | 30,000 | 9,455 | 48,355 | 19,342 | 75,000 |
0.250 | 0.065 | 20,313 | 30,000 | 11,544 | 81,250 | 32,500 | 75,000 |
0.375 | 0.020 | 2,239 | 30,000 | 3,029 | 8,955 | 3,582 | 75,000 |
0.375 | 0.028 | 3,292 | 30,000 | 4,145 | 13,166 | 5,266 | 75,000 |
0.375 | 0.035 | 4,303 | 30,000 | 5,077 | 17,213 | 6,885 | 75,000 |
0.375 | 0.049 | 6,634 | 30,000 | 6,816 | 26,534 | 10,614 | 75,000 |
0.375 | 0.065 | 9,949 | 30,000 | 8,597 | 39,796 | 15,918 | 75,000 |
0.500 | 0.020 | 1,630 | 30,000 | 2,304 | 6,522 | 2,609 | 75,000 |
0.500 | 0.028 | 2,365 | 30,000 | 3,172 | 9,459 | 3,784 | 75,000 |
0.500 | 0.035 | 3,052 | 30,000 | 3,906 | 12,209 | 4,884 | 75,000 |
0.500 | 0.049 | 4,571 | 30,000 | 5,304 | 18,284 | 7,313 | 75,000 |
0.500 | 0.065 | 6,588 | 30,000 | 6,786 | 26,351 | 10,541 | 75,000 |
0.500 | 0.083 | 9,319 | 30,000 | 8,307 | 37,275 | 14,910 | 75,000 |
0.625 | 0.020 | 1,282 | 30,000 | 1,859 | 5,128 | 2,051 | 75,000 |
0.625 | 0.028 | 1,845 | 30,000 | 2,568 | 7,381 | 2,953 | 75,000 |
0.625 | 0.035 | 2,365 | 30,000 | 3,172 | 9,459 | 3,784 | 75,000 |
0.625 | 0.049 | 3,487 | 30,000 | 4,335 | 13,947 | 5,579 | 75,000 |
0.625 | 0.065 | 4,924 | 30,000 | 5,591 | 19,697 | 7,879 | 75,000 |
0.625 | 0.083 | 6,781 | 30,000 | 6,910 | 27,124 | 10,850 | 75,000 |
0.625 | 0.095 | 8,190 | 30,000 | 7,734 | 32,759 | 13,103 | 75,000 |
0.625 | 0.109 | 10,043 | 30,000 | 8,639 | 40,172 | 16,069 | 75,000 |
0.750 | 0.028 | 1,513 | 30,000 | 2,156 | 6,052 | 2,421 | 75,000 |
0.750 | 0.035 | 1,930 | 30,000 | 2,669 | 7,721 | 3,088 | 75,000 |
0.750 | 0.049 | 2,818 | 30,000 | 3,664 | 11,273 | 4,509 | 75,000 |
0.750 | 0.065 | 3,931 | 30,000 | 4,749 | 15,726 | 6,290 | 75,000 |
0.750 | 0.083 | 5,330 | 30,000 | 5,905 | 21,318 | 8,527 | 75,000 |
0.750 | 0.095 | 6,362 | 30,000 | 6,637 | 25,446 | 10,179 | 75,000 |
0.750 | 0.109 | 7,683 | 30,000 | 7,453 | 30,733 | 12,293 | 75,000 |
0.750 | 0.120 | 8,824 | 30,000 | 8,064 | 35,294 | 14,118 | 75,000 |
0.875 | 0.020 | 898 | 30,000 | 1,340 | 3,593 | 1,437 | 75,000 |
0.875 | 0.028 | 1,282 | 30,000 | 1,859 | 5,128 | 2,051 | 75,000 |
0.875 | 0.035 | 1,630 | 30,000 | 2,304 | 6,522 | 2,609 | 75,000 |
0.875 | 0.049 | 2,365 | 30,000 | 3,172 | 9,459 | 3,784 | 75,000 |
0.875 | 0.065 | 3,272 | 30,000 | 4,126 | 13,087 | 5,235 | 75,000 |
0.875 | 0.083 | 4,390 | 30,000 | 5,152 | 17,560 | 7,024 | 75,000 |
0.875 | 0.095 | 5,201 | 30,000 | 5,807 | 20,803 | 8,321 | 75,000 |
0.875 | 0.109 | 6,221 | 30,000 | 6,543 | 24,886 | 9,954 | 75,000 |
0.875 | 0.120 | 7,087 | 30,000 | 7,100 | 28,346 | 11,339 | 75,000 |
1.000 | 0.028 | 1,112 | 30,000 | 1,633 | 4,449 | 1,780 | 75,000 |
1.000 | 0.035 | 1,411 | 30,000 | 2,027 | 5,645 | 2,258 | 75,000 |
1.000 | 0.049 | 2,037 | 30,000 | 2,796 | 8,149 | 3,259 | 75,000 |
1.000 | 0.065 | 2,802 | 30,000 | 3,647 | 11,207 | 4,483 | 75,000 |
1.000 | 0.083 | 3,732 | 30,000 | 4,567 | 14,928 | 5,971 | 75,000 |
1.000 | 0.095 | 4,398 | 30,000 | 5,159 | 17,593 | 7,037 | 75,000 |
1.000 | 0.109 | 5,227 | 30,000 | 5,827 | 20,908 | 8,363 | 75,000 |
1.000 | 0.120 | 5,921 | 30,000 | 6,336 | 23,684 | 9,474 | 75,000 |
1.000 | 0.134 | 6,865 | 30,000 | 6,963 | 27,459 | 10,984 | 75,000 |
1.250 | 0.035 | 1,112 | 30,000 | 1,633 | 4,449 | 1,780 | 75,000 |
1.250 | 0.049 | 1,595 | 30,000 | 2,260 | 6,380 | 2,552 | 75,000 |
1.250 | 0.065 | 2,176 | 30,000 | 2,958 | 8,705 | 3,482 | 75,000 |
1.250 | 0.083 | 2,871 | 30,000 | 3,719 | 11,485 | 4,594 | 75,000 |
1.250 | 0.095 | 3,361 | 30,000 | 4,213 | 13,443 | 5,377 | 75,000 |
1.250 | 0.109 | 3,961 | 30,000 | 4,776 | 15,843 | 6,337 | 75,000 |
1.250 | 0.120 | 4,455 | 30,000 | 5,207 | 17,822 | 7,129 | 75,000 |
1.250 | 0.134 | 5,117 | 30,000 | 5,742 | 20,468 | 8,187 | 75,000 |
1.500 | 0.035 | 918 | 30,000 | 1,367 | 3,671 | 1,469 | 75,000 |
1.500 | 0.049 | 1,311 | 30,000 | 1,896 | 5,243 | 2,097 | 75,000 |
1.500 | 0.065 | 1,779 | 30,000 | 2,487 | 7,117 | 2,847 | 75,000 |
1.500 | 0.083 | 2,333 | 30,000 | 3,136 | 9,333 | 3,733 | 75,000 |
1.500 | 0.095 | 2,719 | 30,000 | 3,559 | 10,878 | 4,351 | 75,000 |
1.500 | 0.109 | 3,188 | 30,000 | 4,043 | 12,754 | 5,101 | 75,000 |
1.500 | 0.120 | 3,571 | 30,000 | 4,416 | 14,286 | 5,714 | 75,000 |
1.500 | 0.134 | 4,079 | 30,000 | 4,881 | 16,315 | 6,526 | 75,000 |
1.500 | 0.148 | 4,610 | 30,000 | 5,336 | 18,439 | 7,375 | 75,000 |
1.750 | 0.035 | 781 | 30,000 | 1,176 | 3,125 | 1,250 | 75,000 |
1.750 | 0.049 | 966 | 30,000 | 1,434 | 3,864 | 1,546 | 75,000 |
1.750 | 0.065 | 1,505 | 30,000 | 2,146 | 6,019 | 2,407 | 75,000 |
1.750 | 0.083 | 1,965 | 30,000 | 2,711 | 7,860 | 3,144 | 75,000 |
1.750 | 0.095 | 2,284 | 30,000 | 3,080 | 9,135 | 3,654 | 75,000 |
1.750 | 0.109 | 2,668 | 30,000 | 3,504 | 10,672 | 4,213 | 75,000 |
1.750 | 0.120 | 2,980 | 30,000 | 3,832 | 11,921 | 4,768 | 75,000 |
1.750 | 0.134 | 3,391 | 30,000 | 4,242 | 13,563 | 5,425 | 75,000 |
1.750 | 0.148 | 3,817 | 30,000 | 4,645 | 15,268 | 6,107 | 75,000 |
1.750 | 0.165 | 4,357 | 30,000 | 5,124 | 17,430 | 6,972 | 75,000 |
2.000 | 0.035 | 680 | 30,000 | 1,032 | 2,720 | 1,088 | 75,000 |
2.000 | 0.049 | 966 | 30,000 | 1,434 | 3,864 | 1,546 | 75,000 |
2.000 | 0.065 | 1,303 | 30,000 | 1,887 | 5,214 | 2,086 | 75,000 |
2.000 | 0.083 | 1,697 | 30,000 | 2,387 | 6,788 | 2,715 | 75,000 |
2.000 | 0.095 | 1,968 | 30,000 | 2,715 | 7,873 | 3,149 | 75,000 |
2.000 | 0.109 | 2,294 | 30,000 | 3,092 | 9,175 | 3,670 | 75,000 |
2.000 | 0.120 | 2,557 | 30,000 | 3,384 | 10,227 | 4,091 | 75,000 |
2.000 | 0.134 | 2,901 | 30,000 | 3,751 | 11,605 | 4,642 | 75,000 |
2.000 | 0.148 | 3,257 | 30,000 | 4,111 | 13,028 | 5,211 | 75,000 |
2.000 | 0.165 | 3,705 | 30,000 | 4,542 | 14,820 | 5,928 | 75,000 |
Grade | Carbon | Sulfur | Manganese | Phosphorus | Nickel | Silicon | Molybdenum | Chromium | |
316L | Minimum | 10.0 | 2.0-3.0 | 16.0 | |||||
Maximum | 0.035 | 0.030 | 2.0 | 0.045 | 14.0 | 0.75 | 18.0 |
Grade | Tensile Properties (MPa) min | Elongational | Yield Properties 0.2% Proof (MPa) min | Hardness | |
Brinell (HB) max | Rockwell B (HR B) max | ||||
316L | 485 | 40 | 170 | 217 | 95 |
Standards | WERKSTOFF NR. | Japanese Industrial Standards | AFNOR | Unified Numbering System | GOST | British Standards | European Standards |
SS 316L | 1.4404 / 1.4435 | SUS 316L | Z3CND17‐11‐02 / Z3CND18‐14‐03 | S31603 | 03Ch17N14M3 / 03Ch17N14M2 | 316S11 / 316S13 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Grade | Density | Modulus (GPa) | Electrical Resistivity (n.m) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | |||
0-3150C | 0-1000C | 0-5380C | at 5000C | at 1000C | |||||
316L | 8000 | 193 | 740 | 16.2 | 15.9 | 17.5 | 21.5 | 16.3 | 500 |
Outer Daimeter in MM | Tolerance |
---|---|
4mm to 35mm | +/- 0.08mm |
60mm and above | +/- 0.25mm |
35mm to 38mm | +/- 0.15mm |
38mm to 60mm | +/- 0.20mm |
ASTM Standards
Pipe Specifications
