ASTM A213 Tp304 is a grade that covers standard heat exchanger or high-pressure tubes that are designed with 304 austenitic stainless steel. The ASTM A213 TP304 Tube is designed with a superior composition consisting of chromium and nickel. This gives the tubes enhanced resistance against corrosive and oxidative media across an array of stress-induced environments. The grade covers standard seamless, welded, and erw configurations. The A213 Type 304 Seamless Tubes are produced via an extrusion process, where hot steel billets are passed through metal to shape them in correct dimensions up to 24 inches. The absence of seam or welds within the ASTM A213 TP304 SS Seamless Tubing has excellent strength and superior load-bearing capacity in difficult environmental conditions. The material is expensive but is preferred in harsh environments where other tubes would distort.
The SA213 Grade 304 SS Welded Tube is a good alternative to the expensive seamless tubes. The versatile tubes are produced by rolling pieces of sheet or strip and welding them in place using standard shop welding procedures. This ASME SA213 Gr 304 Welded Tubing is tested and screened before it is used in high pressure and temperature applications. The tubing can be produced in different sizes. The ASTM A213 304 ERW Tubing is produced by welding steel longitudinally without requiring filler material. Here high-voltage electric current is passed through the metal grade to weld it in the correct configuration. ASTM A213 Type 304 ERW Tubing has a lower rate of sensitization and is available in sizes between 1/8 to 36 NB. These tubes have a thickness between 0.8mm up to 12.7mm and can be availed in custom lengths. If you have any questions or queries about our products or their pricing, contact us or visit any of our outlets for more information.
Table of Content
Specification | ASTM A213 TP304 / ASME SA213 TP304 Tube |
Shapes | Hydraulic, Round, Rectangular, Honed Tubes, Square, Straight, U Shape, Coiled, Pan Cake Coils |
Thickness Range | SCH XXS, SCH 5, SCH 40, SCH XS, SCH 10, SCH 160, SCH XXH, SCH 80S, SCH 80 |
Surface Finish | 400G, 500G, BA, 2B, No.1, Mirror Polished, No.8, No.4, No.3, 8K, 2D, 1D, 600G or 800G Mirror finish Tubing, 180G, 320G, HL, 400G Satin/ Hairline or Custom Finish as per customer's specification |
Manufacturing Type | CDS / CDW / DOM / abricated / Seamless / Welded / ERW / CEW / 100% X Ray Welded |
Standard | GB, JIS, DIN, ASTM, AISI, EN, SUS |
Technique | Cold rolled, Extrusion, Cold drawn, Hot rolled Tube |
Delivery Condition | Polished, Annealed and Pickled (AP), MF, Cold Drawn, Bright Annealed (BA) |
Processing Service | Bending, Cutting, Decoiling, Punching, Welding, Moulding |
End | Plain End, Treaded, Beveled End |
Download PDF: Catalogue 1, Catalogue 2
Per Kg
ASME SA213 TP304 1/4 * 0.035 Inch Stainless Steel Tube
$ 6.21
Per Kg
Astm A213 Tp304 23Mm 140Mm Seamless Steel Pipe Tube
$ 4.14
Per Kg
A213 TP304 1inch- 24inch Sch10-160s Seamless Pipe
$ 10.34
ASTM A213 TP304 Tubes
ASME SA213 Gr 304 Welded Tubing
A213 Type 304 Seamless Tubes
ASME SA213 304 ERW Tubing
SA213 Grade 304 SS Welded Tube
SA 213 TP 304 Tubing
ASTM A213 TP304 SS Seamless Tubing
ASTM A213 Type 304 ERW Tubing
ASTM A213 Gr Tp304 Welded Tubes
Grade | Carbon | Manganese | Sulfur | Phosphorus | Silicon | Chromium | Nickel |
TP304 | 0.08 | 2 | 0.03 | 0.045 | 1 | 18.0-20.0 | 8.0-11.0 |
Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation |
Treatment | Minimum º F(º C) | Ksi (MPa), Minimum | Ksi (MPa), Minimum | ||
TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
Grade | Old British | Unified Numbering System | Swedish SS | Euronorm | Japanese Industrial Standards | ||
British Standards | European Standards | No | Name | ||||
ASTM A213 TP304 | 304S31 | 58E | S30400 | 2332 | 1.4301 | X5CrNi18-10 | SUS 304 |
Outer Diameter in inches | Wall Thcickness in inches | Theoretical Yield Point ** (PSI) | Theoretical Burst Pressure * (PSI) | Working Pressure (PSI) 25% of Burst | Tensile Strength (PSI) | Yield Strength (PSI) |
---|---|---|---|---|---|---|
0.250 | 0.020 | 5,714 | 14,286 | 3,571 | 75,000 | 30,000 |
0.250 | 0.028 | 8,660 | 21,649 | 5,412 | 75,000 | 30,000 |
0.250 | 0.035 | 11,667 | 29,167 | 7,292 | 75,000 | 30,000 |
0.250 | 0.049 | 19,342 | 48,355 | 12,089 | 75,000 | 30,000 |
0.250 | 0.065 | 32,500 | 81,250 | 20,313 | 75,000 | 30,000 |
0.375 | 0.020 | 3,582 | 8,955 | 2,239 | 75,000 | 30,000 |
0.375 | 0.028 | 5,266 | 13,166 | 3,292 | 75,000 | 30,000 |
0.375 | 0.035 | 6,885 | 17,213 | 4,303 | 75,000 | 30,000 |
0.375 | 0.049 | 10,614 | 26,534 | 6,634 | 75,000 | 30,000 |
0.375 | 0.065 | 15,918 | 39,796 | 9,949 | 75,000 | 30,000 |
0.500 | 0.020 | 2,609 | 6,522 | 1,630 | 75,000 | 30,000 |
0.500 | 0.028 | 3,784 | 9,459 | 2,365 | 75,000 | 30,000 |
0.500 | 0.035 | 4,884 | 12,209 | 3,052 | 75,000 | 30,000 |
0.500 | 0.049 | 7,313 | 18,284 | 4,571 | 75,000 | 30,000 |
0.500 | 0.065 | 10,541 | 26,351 | 6,588 | 75,000 | 30,000 |
0.500 | 0.083 | 14,910 | 37,275 | 9,319 | 75,000 | 30,000 |
0.625 | 0.020 | 2,051 | 5,128 | 1,282 | 75,000 | 30,000 |
0.625 | 0.028 | 2,953 | 7,381 | 1,845 | 75,000 | 30,000 |
0.625 | 0.035 | 3,784 | 9,459 | 2,365 | 75,000 | 30,000 |
0.625 | 0.049 | 5,579 | 13,947 | 3,487 | 75,000 | 30,000 |
0.625 | 0.065 | 7,879 | 19,697 | 4,924 | 75,000 | 30,000 |
0.625 | 0.083 | 10,850 | 27,124 | 6,781 | 75,000 | 30,000 |
0.625 | 0.095 | 13,103 | 32,759 | 8,190 | 75,000 | 30,000 |
0.625 | 0.109 | 16,069 | 40,172 | 10,043 | 75,000 | 30,000 |
0.750 | 0.028 | 2,421 | 6,052 | 1,513 | 75,000 | 30,000 |
0.750 | 0.035 | 3,088 | 7,721 | 1,930 | 75,000 | 30,000 |
0.750 | 0.049 | 4,509 | 11,273 | 2,818 | 75,000 | 30,000 |
0.750 | 0.065 | 6,290 | 15,726 | 3,931 | 75,000 | 30,000 |
0.750 | 0.083 | 8,527 | 21,318 | 5,330 | 75,000 | 30,000 |
0.750 | 0.095 | 10,179 | 25,446 | 6,362 | 75,000 | 30,000 |
0.750 | 0.109 | 12,293 | 30,733 | 7,683 | 75,000 | 30,000 |
0.750 | 0.120 | 14,118 | 35,294 | 8,824 | 75,000 | 30,000 |
0.875 | 0.020 | 1,437 | 3,593 | 898 | 75,000 | 30,000 |
0.875 | 0.028 | 2,051 | 5,128 | 1,282 | 75,000 | 30,000 |
0.875 | 0.035 | 2,609 | 6,522 | 1,630 | 75,000 | 30,000 |
0.875 | 0.049 | 3,784 | 9,459 | 2,365 | 75,000 | 30,000 |
0.875 | 0.065 | 5,235 | 13,087 | 3,272 | 75,000 | 30,000 |
0.875 | 0.083 | 7,024 | 17,560 | 4,390 | 75,000 | 30,000 |
0.875 | 0.095 | 8,321 | 20,803 | 5,201 | 75,000 | 30,000 |
0.875 | 0.109 | 9,954 | 24,886 | 6,221 | 75,000 | 30,000 |
0.875 | 0.120 | 11,339 | 28,346 | 7,087 | 75,000 | 30,000 |
1.000 | 0.028 | 1,780 | 4,449 | 1,112 | 75,000 | 30,000 |
1.000 | 0.035 | 2,258 | 5,645 | 1,411 | 75,000 | 30,000 |
1.000 | 0.049 | 3,259 | 8,149 | 2,037 | 75,000 | 30,000 |
1.000 | 0.065 | 4,483 | 11,207 | 2,802 | 75,000 | 30,000 |
1.000 | 0.083 | 5,971 | 14,928 | 3,732 | 75,000 | 30,000 |
1.000 | 0.095 | 7,037 | 17,593 | 4,398 | 75,000 | 30,000 |
1.000 | 0.109 | 8,363 | 20,908 | 5,227 | 75,000 | 30,000 |
1.000 | 0.120 | 9,474 | 23,684 | 5,921 | 75,000 | 30,000 |
1.000 | 0.134 | 10,984 | 27,459 | 6,865 | 75,000 | 30,000 |
1.250 | 0.035 | 1,780 | 4,449 | 1,112 | 75,000 | 30,000 |
1.250 | 0.049 | 2,552 | 6,380 | 1,595 | 75,000 | 30,000 |
1.250 | 0.065 | 3,482 | 8,705 | 2,176 | 75,000 | 30,000 |
1.250 | 0.083 | 4,594 | 11,485 | 2,871 | 75,000 | 30,000 |
1.250 | 0.095 | 5,377 | 13,443 | 3,361 | 75,000 | 30,000 |
1.250 | 0.109 | 6,337 | 15,843 | 3,961 | 75,000 | 30,000 |
1.250 | 0.120 | 7,129 | 17,822 | 4,455 | 75,000 | 30,000 |
1.250 | 0.134 | 8,187 | 20,468 | 5,117 | 75,000 | 30,000 |
1.500 | 0.035 | 1,469 | 3,671 | 918 | 75,000 | 30,000 |
1.500 | 0.049 | 2,097 | 5,243 | 1,311 | 75,000 | 30,000 |
1.500 | 0.065 | 2,847 | 7,117 | 1,779 | 75,000 | 30,000 |
1.500 | 0.083 | 3,733 | 9,333 | 2,333 | 75,000 | 30,000 |
1.500 | 0.095 | 4,351 | 10,878 | 2,719 | 75,000 | 30,000 |
1.500 | 0.109 | 5,101 | 12,754 | 3,188 | 75,000 | 30,000 |
1.500 | 0.120 | 5,714 | 14,286 | 3,571 | 75,000 | 30,000 |
1.500 | 0.134 | 6,526 | 16,315 | 4,079 | 75,000 | 30,000 |
1.500 | 0.148 | 7,375 | 18,439 | 4,610 | 75,000 | 30,000 |
1.750 | 0.035 | 1,250 | 3,125 | 781 | 75,000 | 30,000 |
1.750 | 0.049 | 1,546 | 3,864 | 966 | 75,000 | 30,000 |
1.750 | 0.065 | 2,407 | 6,019 | 1,505 | 75,000 | 30,000 |
1.750 | 0.083 | 3,144 | 7,860 | 1,965 | 75,000 | 30,000 |
1.750 | 0.095 | 3,654 | 9,135 | 2,284 | 75,000 | 30,000 |
1.750 | 0.109 | 4,269 | 10,672 | 2,668 | 75,000 | 30,000 |
1.750 | 0.120 | 4,768 | 11,921 | 2,980 | 75,000 | 30,000 |
1.750 | 0.134 | 5,425 | 13,563 | 3,391 | 75,000 | 30,000 |
1.750 | 0.148 | 6,107 | 15,268 | 3,817 | 75,000 | 30,000 |
1.750 | 0.165 | 6,972 | 17,430 | 4,357 | 75,000 | 30,000 |
2.000 | 0.035 | 1,088 | 2,720 | 680 | 75,000 | 30,000 |
2.000 | 0.049 | 1,546 | 3,864 | 966 | 75,000 | 30,000 |
2.000 | 0.065 | 2,086 | 5,214 | 1,303 | 75,000 | 30,000 |
2.000 | 0.083 | 2,715 | 6,788 | 1,697 | 75,000 | 30,000 |
2.000 | 0.095 | 3,149 | 7,873 | 1,968 | 75,000 | 30,000 |
2.000 | 0.109 | 3,670 | 9,175 | 2,294 | 75,000 | 30,000 |
2.000 | 0.120 | 4,091 | 10,227 | 2,557 | 75,000 | 30,000 |
2.000 | 0.134 | 4,642 | 11,605 | 2,901 | 75,000 | 30,000 |
2.000 | 0.148 | 5,211 | 13,028 | 3,257 | 75,000 | 30,000 |
2.000 | 0.165 | 5,928 | 14,820 | 3,705 | 75,000 | 30,000 |
Outer Diameter Sizes in Inches | Weight Lbs/Ft. |
BW Ga. |
Inner Diameter | Wall Dec-In |
3/16 | 0.0478 | 22 | 0.131 | 0.028 |
1/4 | 0.0491 | 25 | 0.210 | 0.020 |
0.0664 | 22 | 0.194 | 0.028 | |
0.0745 | 21 | 0.187 | 0.032 | |
0.0804 | 20 | 0.180 | 0.035 | |
0.1052 | 18 | 0.152 | 0.049 | |
0.1284 | 16 | 0.120 | 0.065 | |
1/8 | 0.0290 | 22 | 0.069 | 0.028 |
0.0336 | 20 | 0.055 | 0.035 | |
5/16 | 0.1039 | 20 | 0.242 | 0.035 |
0.1382 | 18 | 0.214 | 0.049 | |
0.1722 | 16 | 0.182 | 0.065 | |
3/8 | 0.1038 | 22 | 0.319 | 0.028 |
0.1271 | 20 | 0.305 | 0.035 | |
0.1706 | 18 | 0.277 | 0.049 | |
0.2152 | 16 | 0.245 | 0.065 | |
1/2 | 0.1025 | 25 | 0.460 | 0.020 |
0.1738 | 20 | 0.430 | 0.035 | |
0.2360 | 18 | 0.402 | 0.049 | |
0.3020 | 16 | 0.370 | 0.065 | |
7/16 | 0.2036 | 18 | 0.340 | 0.049 |
5/8 | 0.2205 | 20 | 0.555 | 0.035 |
0.3014 | 18 | 0.527 | 0.049 | |
0.3888 | 16 | 0.495 | 0.065 | |
7/8 | 0.4323 | 18 | 0.777 | 0.049 |
0.5623 | 16 | 0.745 | 0.065 | |
0.9676 | 11 | 0.635 | 0.120 | |
3/4 | 0.2673 | 20 | 0.680 | 0.035 |
0.3668 | 18 | 0.652 | 0.049 | |
0.4755 | 16 | 0.620 | 0.065 | |
0.5913 | 14 | 0.584 | 0.083 | |
1 | 0.3607 | 20 | 0.930 | 0.035 |
0.4977 | 18 | 0.902 | 0.049 | |
0.6491 | 16 | 0.870 | 0.065 | |
0.8129 | 14 | 0.834 | 0.083 | |
1.1278 | 11 | 0.760 | 0.120 | |
1-1/4 | 1.4480 | 11 | 1.010 | 0.120 |
Grade |
Elastic Modulus (GPa) | Density (kg/m3) | Thermal Conductivity (W/m.K) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | |||
at 100°C | at 500°C | 0-100°C | 0-315°C | 0-538°C | |||||
304 | 193 | 8000 | 16.2 | 21.5 | 17.2 | 17.8 | 18.4 | 500 | 720 |
Nominal Pipe Size | Outer Diameter Tolerance | |||
+ | – | |||
Inch | mm | Inch | mm | |
1/8~1 1 /2 > 1 1 /2~4 > 4~8 > 8~18 > 18~26 > 26~34 > 34~48 |
1/64(0.015) 1/32(0.031) 1/16(0.062) 3/32(0.093) 1/8(0.125) 5/32(0.156) 3/16(0.187) |
0.4 0.8 1.6 2.4 3.2 4.0 4.8 |
1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) |
0.8 0.8 0.8 0.8 0.8 0.8 0.8 |
