ASTM A213 TP304L Tube
ASME SA213 Type 304L Seamless Tubing Supplier in Mumbai, India
ASTM A213 Tp304l grade covers standard specifications for boilers, heat exchangers, and superheated vessels. The ASTM A213 Tp304l Tube is a low-carbon austenitic grade designed with a superior composition of nickel and chromium, allowing these tubes to work well in corrosive and oxidative media across stress-induced setups. The versatile SA 213 TP 304L Stainless Steel Tubing can work in high-temperature applications for a prolonged period of time. This tubing has excellent surface quality and has very low levels of sensitization in the system.
The ASTM A249 TP304 grade covers seamless, welded, and erw configurations. ASME SA213 Type 304L Seamless Tubing is designed to work in high temperature setups. This tubing is manufactured is produced as hot steel billets are passed through extruded metal to weld them in their correct position. This gives the tubes without any welds excellent strength and load-bearing capacity than welded tubes. The ASTM A213 TP304L Welded Tube is a cost-effective solution to the seamless tubes. These tubes may not have the same strength but can be shaped in different dimensions, which is not possible with seamless pipes. The ASME SA 213 304L Stainless Steel Welded Pipe are manufactured as sheets or strips are rolled followed by welding them in place making use of standard shop welding procedures. The tubes are subject to several tests before they are made fit for use in high-temperature applications. SA213 Grade 304L ERW Tubing is a module that is produced after a high voltage electric current is passed through the metal to weld it longitudinally. This tubing doesn’t require any filler material to function normally. Our tie-up with the best logistical and supply chains allows us to transport products to your doorstep on short notice. For any questions and queries about our products or their pricing, contact us or visit any of our outlets for more information.
Supplier & stockist of ASTM A213 TP304L Welded Tube and SA213 Grade 304L ERW Tubing according to ASME, ASTM standards
Table of Content
- ASME SA213 Type 304L Seamless Tubing Specification List
- ASTM A213 TP304L Tube Price List
- ASTM A213 TP304L Welded Tube Types
- Weight chart of SA213 Grade 304L ERW Tubing
- ASTM A213 TP304L Welded Tube Chemical Composition
- Mechanical Properties of A312 TP 304L ERW Pipe
- SA 213 304L Stainless Steel Welded Pipe Equivalent
- Physical Properties of ASTM A213 Grade 304L Tubing
- ASTM A213 TP304L Tube Pressure Ratings
ASME SA213 Type 304L Seamless Tubing Specification List
| Specification | ASTM A213 TP304L Tubes / ASME SA213 TP304L Tube |
| Shapes | Rectangular, Hydraulic, Round, Straight, Honed Tubes, Square, U Shape, Coiled, Pan Cake Coils |
| Surface Finish | 400G, 500G, 320G, BA, 2B, No.1, No.8, No.4, No.3, 8K, 2D, Mirror Polished, 1D, 600G or 800G Mirror finish Tubing, 180G, HL, 400G Satin/ Hairline or Custom Finish as per customer's specification |
| Manufacturing Type | CDS / ERW / CDW / DOM / abricated / Welded / CEW / Seamless / 100% X Ray Welded |
| Thickness Range | CH 80S, SCH XXS, SCH 5, SCH 10, SCH 40, SCH XS, SCH 160, SCH XXH, SSCH 80 |
| Standard | ASTM, GB, JIS, DIN, AISI, EN, SUS |
| Technique | Cold drawn, Cold rolled, Extrusion, Hot rolled Tube |
| End | Plain End, Beveled End, Treaded |
| Delivery Condition | Polished, Cold Drawn, Annealed and Pickled (AP), MF, Bright Annealed (BA) |
| Processing Service | Bending, Punching, Cutting, Decoiling, Welding, Moulding |
ASTM A213 TP304L Tube Price List
Per Kg
ASTM A213 Tp304L 2mm Round Welded Seamless Stainless Steel Pipe Tube
$ 2.59
Per Kg
ASME SA213 TP304L Seamless Stainless Steel 0.5-30mm Tube
$ 7.03
Per Kg
ASME SA213 TP304L 10Mm 20Mm 30Mm Diameter Stainless Steel Pipe
$ 1.86
ASTM A213 TP304L Welded Tube Types
ASME SA213 Type 304L Seamless Tubing
ASTM A213 TP304L Tubes
A312 TP 304L ERW Pipe
SA213 Grade 304L ERW Tubing
ASTM A213 Grade 304L Tubing
SA 213 304L Stainless Steel Welded Pipe
SA 213 TP 304L Stainless Steel Tubing
ASME SA213 Grade 304L Seamless Pipe
SA213 Type 304L Seamless Tubing
Weight chart of SA213 Grade 304L ERW Tubing
| Inner Diameter | Outer Diameter Sizes in Inches | Weight Lbs/Ft. |
Wall Dec-In |
BW Ga. |
| 0.131 | 3/16 | 0.0478 | 0.028 | 22 |
| 0.069 | 1/8 | 0.0290 | 0.028 | 22 |
| 0.055 | 0.0336 | 0.035 | 20 | |
| 0.242 | 5/16 | 0.1039 | 0.035 | 20 |
| 0.214 | 0.1382 | 0.049 | 18 | |
| 0.182 | 0.1722 | 0.065 | 16 | |
| 0.319 | 3/8 | 0.1038 | 0.028 | 22 |
| 0.305 | 0.1271 | 0.035 | 20 | |
| 0.277 | 0.1706 | 0.049 | 18 | |
| 0.245 | 0.2152 | 0.065 | 16 | |
| 0.460 | 1/2 | 0.1025 | 0.020 | 25 |
| 0.430 | 0.1738 | 0.035 | 20 | |
| 0.402 | 0.2360 | 0.049 | 18 | |
| 0.370 | 0.3020 | 0.065 | 16 | |
| 0.210 | 1/4 | 0.0491 | 0.020 | 25 |
| 0.194 | 0.0664 | 0.028 | 22 | |
| 0.187 | 0.0745 | 0.032 | 21 | |
| 0.180 | 0.0804 | 0.035 | 20 | |
| 0.152 | 0.1052 | 0.049 | 18 | |
| 0.120 | 0.1284 | 0.065 | 16 | |
| 0.340 | 7/16 | 0.2036 | 0.049 | 18 |
| 0.555 | 5/8 | 0.2205 | 0.035 | 20 |
| 0.527 | 0.3014 | 0.049 | 18 | |
| 0.495 | 0.3888 | 0.065 | 16 | |
| 0.777 | 7/8 | 0.4323 | 0.049 | 18 |
| 0.745 | 0.5623 | 0.065 | 16 | |
| 0.635 | 0.9676 | 0.120 | 11 | |
| 0.680 | 3/4 | 0.2673 | 0.035 | 20 |
| 0.652 | 0.3668 | 0.049 | 18 | |
| 0.620 | 0.4755 | 0.065 | 16 | |
| 0.584 | 0.5913 | 0.083 | 14 | |
| 0.930 | 1 | 0.3607 | 0.035 | 20 |
| 0.902 | 0.4977 | 0.049 | 18 | |
| 0.870 | 0.6491 | 0.065 | 16 | |
| 0.834 | 0.8129 | 0.083 | 14 | |
| 0.760 | 1.1278 | 0.120 | 11 | |
| 1.010 | 1-1/4 | 1.4480 | 0.120 | 11 |
ASTM A213 TP304L Welded Tube Chemical Composition
| Grade | Carbon | Manganese | Sulfur | Phosphorus | Silicon | Chromium | Nickel |
| TP304L | 0.035 | 2 | 0.03 | 0.045 | 1 | 18.0-20.0 | 8.0-11.0 |
Mechanical Properties of A312 TP 304L ERW Pipe
| Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation |
| Treatment | Minimum º F(º C) | Ksi (MPa), Minimum | Ksi (MPa), Minimum | ||
| TP304 | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
SA 213 304L Stainless Steel Welded Pipe Equivalent
| Grade | Unified Numbering System | Old British | Euronorm | Swedish SS | Japanese Industrial Standards | GOST | ||
| British Standards | European Standards | No | Name | |||||
| 304L | S30403 | 304S31 | 58E | 1.4306 / 1.4307 | X5CrNi18-10 | 2332 | SUS 304L | 03Х18Н11 |
Physical Properties of ASTM A213 Grade 304L Tubing
| Grade | Specific Heat 0-1000C (J/kg.K) | Density (kg/m3) | Mean Coefficient of Thermal Expansion (m/m/0C) | Elastic Modulus (GPa) | Thermal Conductivity (W/m.K) | Electrical Resistivity (n.m) | |||
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 304L | 500 | 8000 | 17.2 | 17.8 | 18.4 | 193 | 16.2 | 21.5 | 720 |
ASTM A213 TP304L Tube Pressure Ratings
| Wall Thcickness in inches | Outer Diameter in inches | Working Pressure (PSI) 25% of Burst | Theoretical Yield Point ** (PSI) | Tensile Strength (PSI) | Theoretical Burst Pressure * (PSI) | Yield Strength (PSI) |
|---|---|---|---|---|---|---|
| 0.049 | 0.375 | 6,634 | 10,614 | 75,000 | 26,534 | 30,000 |
| 0.028 | 0.250 | 5,412 | 8,660 | 75,000 | 21,649 | 30,000 |
| 0.035 | 0.250 | 7,292 | 11,667 | 75,000 | 29,167 | 30,000 |
| 0.049 | 0.250 | 12,089 | 19,342 | 75,000 | 48,355 | 30,000 |
| 0.065 | 0.250 | 20,313 | 32,500 | 75,000 | 81,250 | 30,000 |
| 0.020 | 0.375 | 2,239 | 3,582 | 75,000 | 8,955 | 30,000 |
| 0.028 | 0.375 | 3,292 | 5,266 | 75,000 | 13,166 | 30,000 |
| 0.020 | 0.250 | 3,571 | 5,714 | 75,000 | 14,286 | 30,000 |
| 0.035 | 0.375 | 4,303 | 6,885 | 75,000 | 17,213 | 30,000 |
| 0.065 | 0.375 | 9,949 | 15,918 | 75,000 | 39,796 | 30,000 |
| 0.020 | 0.500 | 1,630 | 2,609 | 75,000 | 6,522 | 30,000 |
| 0.028 | 0.500 | 2,365 | 3,784 | 75,000 | 9,459 | 30,000 |
| 0.035 | 0.500 | 3,052 | 4,884 | 75,000 | 12,209 | 30,000 |
| 0.065 | 0.500 | 6,588 | 10,541 | 75,000 | 26,351 | 30,000 |
| 0.083 | 0.500 | 9,319 | 14,910 | 75,000 | 37,275 | 30,000 |
| 0.020 | 0.625 | 1,282 | 2,051 | 75,000 | 5,128 | 30,000 |
| 0.028 | 0.625 | 1,845 | 2,953 | 75,000 | 7,381 | 30,000 |
| 0.049 | 0.500 | 4,571 | 7,313 | 75,000 | 18,284 | 30,000 |
| 0.035 | 0.625 | 2,365 | 3,784 | 75,000 | 9,459 | 30,000 |
| 0.049 | 0.875 | 2,365 | 3,784 | 75,000 | 9,459 | 30,000 |
| 0.049 | 0.625 | 3,487 | 5,579 | 75,000 | 13,947 | 30,000 |
| 0.065 | 0.625 | 4,924 | 7,879 | 75,000 | 19,697 | 30,000 |
| 0.083 | 0.625 | 6,781 | 10,850 | 75,000 | 27,124 | 30,000 |
| 0.095 | 0.625 | 8,190 | 13,103 | 75,000 | 32,759 | 30,000 |
| 0.109 | 0.625 | 10,043 | 16,069 | 75,000 | 40,172 | 30,000 |
| 0.028 | 0.750 | 1,513 | 2,421 | 75,000 | 6,052 | 30,000 |
| 0.109 | 0.750 | 7,683 | 12,293 | 75,000 | 30,733 | 30,000 |
| 0.035 | 0.750 | 1,930 | 3,088 | 75,000 | 7,721 | 30,000 |
| 0.049 | 0.750 | 2,818 | 4,509 | 75,000 | 11,273 | 30,000 |
| 0.065 | 0.750 | 3,931 | 6,290 | 75,000 | 15,726 | 30,000 |
| 0.083 | 0.750 | 5,330 | 8,527 | 75,000 | 21,318 | 30,000 |
| 0.095 | 0.750 | 6,362 | 10,179 | 75,000 | 25,446 | 30,000 |
| 0.120 | 0.750 | 8,824 | 14,118 | 75,000 | 35,294 | 30,000 |
| 0.020 | 0.875 | 898 | 1,437 | 75,000 | 3,593 | 30,000 |
| 0.028 | 0.875 | 1,282 | 2,051 | 75,000 | 5,128 | 30,000 |
| 0.035 | 0.875 | 1,630 | 2,609 | 75,000 | 6,522 | 30,000 |
| 0.065 | 0.875 | 3,272 | 5,235 | 75,000 | 13,087 | 30,000 |
| 0.083 | 0.875 | 4,390 | 7,024 | 75,000 | 17,560 | 30,000 |
| 0.095 | 0.875 | 5,201 | 8,321 | 75,000 | 20,803 | 30,000 |
| 0.109 | 0.875 | 6,221 | 9,954 | 75,000 | 24,886 | 30,000 |
| 0.120 | 0.875 | 7,087 | 11,339 | 75,000 | 28,346 | 30,000 |
| 0.028 | 1.000 | 1,112 | 1,780 | 75,000 | 4,449 | 30,000 |
| 0.035 | 1.000 | 1,411 | 2,258 | 75,000 | 5,645 | 30,000 |
| 0.049 | 1.000 | 2,037 | 3,259 | 75,000 | 8,149 | 30,000 |
| 0.065 | 1.000 | 2,802 | 4,483 | 75,000 | 11,207 | 30,000 |
| 0.083 | 1.000 | 3,732 | 5,971 | 75,000 | 14,928 | 30,000 |
| 0.095 | 1.000 | 4,398 | 7,037 | 75,000 | 17,593 | 30,000 |
| 0.109 | 1.000 | 5,227 | 8,363 | 75,000 | 20,908 | 30,000 |
| 0.120 | 1.000 | 5,921 | 9,474 | 75,000 | 23,684 | 30,000 |
| 0.134 | 1.000 | 6,865 | 10,984 | 75,000 | 27,459 | 30,000 |
| 0.035 | 1.250 | 1,112 | 1,780 | 75,000 | 4,449 | 30,000 |
| 0.049 | 1.250 | 1,595 | 2,552 | 75,000 | 6,380 | 30,000 |
| 0.065 | 1.250 | 2,176 | 3,482 | 75,000 | 8,705 | 30,000 |
| 0.083 | 1.250 | 2,871 | 4,594 | 75,000 | 11,485 | 30,000 |
| 0.095 | 1.250 | 3,361 | 5,377 | 75,000 | 13,443 | 30,000 |
| 0.109 | 1.250 | 3,961 | 6,337 | 75,000 | 15,843 | 30,000 |
| 0.120 | 1.250 | 4,455 | 7,129 | 75,000 | 17,822 | 30,000 |
| 0.134 | 1.250 | 5,117 | 8,187 | 75,000 | 20,468 | 30,000 |
| 0.035 | 1.500 | 918 | 1,469 | 75,000 | 3,671 | 30,000 |
| 0.049 | 1.500 | 1,311 | 2,097 | 75,000 | 5,243 | 30,000 |
| 0.065 | 1.500 | 1,779 | 2,847 | 75,000 | 7,117 | 30,000 |
| 0.083 | 1.500 | 2,333 | 3,733 | 75,000 | 9,333 | 30,000 |
| 0.095 | 1.500 | 2,719 | 4,351 | 75,000 | 10,878 | 30,000 |
| 0.109 | 1.500 | 3,188 | 5,101 | 75,000 | 12,754 | 30,000 |
| 0.120 | 1.500 | 3,571 | 5,714 | 75,000 | 14,286 | 30,000 |
| 0.134 | 1.500 | 4,079 | 6,526 | 75,000 | 16,315 | 30,000 |
| 0.148 | 1.500 | 4,610 | 7,375 | 75,000 | 18,439 | 30,000 |
| 0.035 | 1.750 | 781 | 1,250 | 75,000 | 3,125 | 30,000 |
| 0.049 | 1.750 | 966 | 1,546 | 75,000 | 3,864 | 30,000 |
| 0.065 | 1.750 | 1,505 | 2,407 | 75,000 | 6,019 | 30,000 |
| 0.083 | 1.750 | 1,965 | 3,144 | 75,000 | 7,860 | 30,000 |
| 0.095 | 1.750 | 2,284 | 3,654 | 75,000 | 9,135 | 30,000 |
| 0.109 | 1.750 | 2,668 | 4,269 | 75,000 | 10,672 | 30,000 |
| 0.120 | 1.750 | 2,980 | 4,768 | 75,000 | 11,921 | 30,000 |
| 0.134 | 1.750 | 3,391 | 5,425 | 75,000 | 13,563 | 30,000 |
| 0.148 | 1.750 | 3,817 | 6,107 | 75,000 | 15,268 | 30,000 |
| 0.165 | 1.750 | 4,357 | 6,972 | 75,000 | 17,430 | 30,000 |
| 0.035 | 2.000 | 680 | 1,088 | 75,000 | 2,720 | 30,000 |
| 0.049 | 2.000 | 966 | 1,546 | 75,000 | 3,864 | 30,000 |
| 0.065 | 2.000 | 1,303 | 2,086 | 75,000 | 5,214 | 30,000 |
| 0.083 | 2.000 | 1,697 | 2,715 | 75,000 | 6,788 | 30,000 |
| 0.095 | 2.000 | 1,968 | 3,149 | 75,000 | 7,873 | 30,000 |
| 0.109 | 2.000 | 2,294 | 3,670 | 75,000 | 9,175 | 30,000 |
| 0.120 | 2.000 | 2,557 | 4,091 | 75,000 | 10,227 | 30,000 |
| 0.134 | 2.000 | 2,901 | 4,642 | 75,000 | 11,605 | 30,000 |
| 0.148 | 2.000 | 3,257 | 5,211 | 75,000 | 13,028 | 30,000 |
| 0.165 | 2.000 | 3,705 | 5,928 | 75,000 | 14,820 | 30,000 |
