ASTM a213 Tp316L is a grade belonging to heat exchanger or high-pressure tubes that are designed with 316L austenitic stainless steel. The ASTM A213 TP316L Tube is manufactured with a superior chemical composition of nickel, chromium, and molybdenum. The content allows these modules to work in highly corrosive and oxidative media. The low-carbon ASTM A213 SS 316L Tube is also seen in environments where pitting and crevice corrosion are easily induced on the material. These tubes are designed in thickness between 0.40mm up to 12.70mm. The robust 316L tubes can be processed in a hot or cold drawing process. ASTM A213 TP316L Cold Drawn Tube is processed at room temperatures allowing the modules to have enhanced surface finish and outstanding strength. Our illustrious institute has tie-ups with some of the best logistical systems in the country, allowing us to transport products efficiently to your doorstep.
The components in the ASTM a213Tp316L grade are produced in seamless, welded, or erw configurations. The SA213 Tp316L Seamless Tubes are manufactured via the extrusion process. Here hot steel billets are passed through the metal to precisely shape them in the correct dimensions. Designed without welds or seam, the ASTM A213 UNS S316l00 Seamless Tube has outstanding strength and 20% higher load-bearing capacity when compared to welded tubes. These tubes are designed in size between 1/2 OD up to 12 OD and are available in lengths of single, double random, and cut sizes. The material utilized in producing the AISI 316L Seamless Tubing makes them a little more expensive than welded pipes. They, however, are very much preferred in harsh applications across stress-induced setups. The AISI 316L ERW Tubing is manufactured as a high-voltage current is passed through the metal to longitudinally weld it in place without the need for any filler material. For more information or any queries, visit any of our outlets or contact us.
Table of Content
Specification | ASTM A213 TP316L Tubes / ASME SA213 TP316L Tube |
Thickness Range | SCH 40, SCH XXS, SCH 5, SCH XS, SCH 10, SCH 160, SCH XXH, SCH 80S, SCH 80 |
Standard | GB, JIS, DIN, ASTM, AISI, EN, SUS |
Surface Finish | 400G, 500G, BA, 2B, No.1, No.8, No.4, No.3, 8K, 2D, 1D, 600G or 800G Mirror finish Tubing, 180G, 320G, Mirror Polished, HL, 400G Satin/ Hairline or Custom Finish as per customer's specification |
Shapes | Straight, Hydraulic, Round, Rectangular, Honed Tubes, Square, U Shape, Coiled, Pan Cake Coils |
Manufacturing Type | CDS / CDW / DOM / Welded / abricated / Seamless / ERW / CEW / 100% X Ray Welded |
Technique | Cold rolled, Cold drawn, Extrusion, Hot rolled Tube |
Delivery Condition | Polished, MF, Annealed and Pickled (AP), Cold Drawn, Bright Annealed (BA) |
Processing Service | Punching, Bending, Cutting, Decoiling, Welding, Moulding |
End | Plain End, Treaded, Beveled End |
Per Kg
Industry Grade ASTM A213 TP316 Seamless Pipe & Tube
$ 4.93
Per Kg
ASME SA213 TP316l stainless steel seamless tube
$ 21.74
Per Kg
A213 Tp316 22Mm Stainless Seamless Precision Steel Tube
$ 4.14
SA213 Tp316L Seamless Tubes
AISI 316L ERW Tubing
ASME SA213 TP316L Tubes
ASTM A213 TP316L Cold Drawn Tube
SA213 TP316L Seamless Tube
ASTM A213 UNS S316l00 Seamless Tubes
ASME SA213 GR Tp316L Tubes
ASME SA213 Grade TP316L Stainless Steel Seamless Tube
ASME SA213 TP316L Welded Tubes
Grade | Specific Heat 0-1000C (J/kg.K) | Density (kg/m3) | Elastic Modulus (GPa) | Thermal Conductivity (W/m.K) | Mean Coefficient of Thermal Expansion (m/m/0C) | Electrical Resistivity (n.m) | |||
at 1000C | at 5000C | 0-1000C | 0-3150C | 0-5380C | |||||
316L | 500 | 8000 | 193 | 16.3 | 21.5 | 15.9 | 16.2 | 17.5 | 740 |
Grade | Carbon | Manganese | Silicon | Phosphorus | Sulfur | Chromium | Molybdenum | Nickel | |
316L | Minimum | 16.0 | 2.0-3.0 | 10.0 | |||||
Maximum | 0.035 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 14.0 |
Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
Treatment | Min. º F(º C) | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
TP316L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
Standard | Werkstoff Nr. | Unified Numbering System | Japanese Industrial Standards | British Standards | GOST | AFNOR | European Standards |
SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316LS11 / 316LS13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Wall Thcickness in inches | Theoretical Burst Pressure * (PSI) | Outer Diameter in inches | Theoretical Yield Point ** (PSI) | Working Pressure (PSI) 25% of Burst | Tensile Strength (PSI) | Yield Strength (PSI) |
---|---|---|---|---|---|---|
0.049 | 26,534 | 0.375 | 10,614 | 6,634 | 75,000 | 30,000 |
0.165 | 14,820 | 2.000 | 5,928 | 3,705 | 75,000 | 30,000 |
0.028 | 21,649 | 0.250 | 8,660 | 5,412 | 75,000 | 30,000 |
0.035 | 29,167 | 0.250 | 11,667 | 7,292 | 75,000 | 30,000 |
0.049 | 48,355 | 0.250 | 19,342 | 12,089 | 75,000 | 30,000 |
0.065 | 81,250 | 0.250 | 32,500 | 20,313 | 75,000 | 30,000 |
0.020 | 8,955 | 0.375 | 3,582 | 2,239 | 75,000 | 30,000 |
0.028 | 13,166 | 0.375 | 5,266 | 3,292 | 75,000 | 30,000 |
0.020 | 14,286 | 0.250 | 5,714 | 3,571 | 75,000 | 30,000 |
0.035 | 17,213 | 0.375 | 6,885 | 4,303 | 75,000 | 30,000 |
0.065 | 39,796 | 0.375 | 15,918 | 9,949 | 75,000 | 30,000 |
0.020 | 6,522 | 0.500 | 2,609 | 1,630 | 75,000 | 30,000 |
0.028 | 9,459 | 0.500 | 3,784 | 2,365 | 75,000 | 30,000 |
0.035 | 12,209 | 0.500 | 4,884 | 3,052 | 75,000 | 30,000 |
0.065 | 26,351 | 0.500 | 10,541 | 6,588 | 75,000 | 30,000 |
0.083 | 37,275 | 0.500 | 14,910 | 9,319 | 75,000 | 30,000 |
0.020 | 5,128 | 0.625 | 2,051 | 1,282 | 75,000 | 30,000 |
0.028 | 7,381 | 0.625 | 2,953 | 1,845 | 75,000 | 30,000 |
0.049 | 18,284 | 0.500 | 7,313 | 4,571 | 75,000 | 30,000 |
0.035 | 9,459 | 0.625 | 3,784 | 2,365 | 75,000 | 30,000 |
0.049 | 9,459 | 0.875 | 3,784 | 2,365 | 75,000 | 30,000 |
0.049 | 13,947 | 0.625 | 5,579 | 3,487 | 75,000 | 30,000 |
0.065 | 19,697 | 0.625 | 7,879 | 4,924 | 75,000 | 30,000 |
0.083 | 27,124 | 0.625 | 10,850 | 6,781 | 75,000 | 30,000 |
0.095 | 32,759 | 0.625 | 13,103 | 8,190 | 75,000 | 30,000 |
0.109 | 40,172 | 0.625 | 16,069 | 10,043 | 75,000 | 30,000 |
0.028 | 6,052 | 0.750 | 2,421 | 1,513 | 75,000 | 30,000 |
0.109 | 30,733 | 0.750 | 12,293 | 7,683 | 75,000 | 30,000 |
0.035 | 7,721 | 0.750 | 3,088 | 1,930 | 75,000 | 30,000 |
0.049 | 11,273 | 0.750 | 4,509 | 2,818 | 75,000 | 30,000 |
0.065 | 15,726 | 0.750 | 6,290 | 3,931 | 75,000 | 30,000 |
0.083 | 21,318 | 0.750 | 8,527 | 5,330 | 75,000 | 30,000 |
0.095 | 25,446 | 0.750 | 10,179 | 6,362 | 75,000 | 30,000 |
0.120 | 35,294 | 0.750 | 14,118 | 8,824 | 75,000 | 30,000 |
0.020 | 3,593 | 0.875 | 1,437 | 898 | 75,000 | 30,000 |
0.028 | 5,128 | 0.875 | 2,051 | 1,282 | 75,000 | 30,000 |
0.035 | 6,522 | 0.875 | 2,609 | 1,630 | 75,000 | 30,000 |
0.065 | 13,087 | 0.875 | 5,235 | 3,272 | 75,000 | 30,000 |
0.083 | 17,560 | 0.875 | 7,024 | 4,390 | 75,000 | 30,000 |
0.095 | 20,803 | 0.875 | 8,321 | 5,201 | 75,000 | 30,000 |
0.109 | 24,886 | 0.875 | 9,954 | 6,221 | 75,000 | 30,000 |
0.120 | 28,346 | 0.875 | 11,339 | 7,087 | 75,000 | 30,000 |
0.028 | 4,449 | 1.000 | 1,780 | 1,112 | 75,000 | 30,000 |
0.035 | 5,645 | 1.000 | 2,258 | 1,411 | 75,000 | 30,000 |
0.049 | 8,149 | 1.000 | 3,259 | 2,037 | 75,000 | 30,000 |
0.065 | 11,207 | 1.000 | 4,483 | 2,802 | 75,000 | 30,000 |
0.083 | 14,928 | 1.000 | 5,971 | 3,732 | 75,000 | 30,000 |
0.095 | 17,593 | 1.000 | 7,037 | 4,398 | 75,000 | 30,000 |
0.109 | 20,908 | 1.000 | 8,363 | 5,227 | 75,000 | 30,000 |
0.120 | 23,684 | 1.000 | 9,474 | 5,921 | 75,000 | 30,000 |
0.134 | 27,459 | 1.000 | 10,984 | 6,865 | 75,000 | 30,000 |
0.035 | 4,449 | 1.250 | 1,780 | 1,112 | 75,000 | 30,000 |
0.049 | 6,380 | 1.250 | 2,552 | 1,595 | 75,000 | 30,000 |
0.065 | 8,705 | 1.250 | 3,482 | 2,176 | 75,000 | 30,000 |
0.083 | 11,485 | 1.250 | 4,594 | 2,871 | 75,000 | 30,000 |
0.095 | 13,443 | 1.250 | 5,377 | 3,361 | 75,000 | 30,000 |
0.109 | 15,843 | 1.250 | 6,337 | 3,961 | 75,000 | 30,000 |
0.120 | 17,822 | 1.250 | 7,129 | 4,455 | 75,000 | 30,000 |
0.134 | 20,468 | 1.250 | 8,187 | 5,117 | 75,000 | 30,000 |
0.035 | 3,671 | 1.500 | 1,469 | 918 | 75,000 | 30,000 |
0.049 | 5,243 | 1.500 | 2,097 | 1,311 | 75,000 | 30,000 |
0.065 | 7,117 | 1.500 | 2,847 | 1,779 | 75,000 | 30,000 |
0.083 | 9,333 | 1.500 | 3,733 | 2,333 | 75,000 | 30,000 |
0.095 | 10,878 | 1.500 | 4,351 | 2,719 | 75,000 | 30,000 |
0.109 | 12,754 | 1.500 | 5,101 | 3,188 | 75,000 | 30,000 |
0.120 | 14,286 | 1.500 | 5,714 | 3,571 | 75,000 | 30,000 |
0.134 | 16,315 | 1.500 | 6,526 | 4,079 | 75,000 | 30,000 |
0.148 | 18,439 | 1.500 | 7,375 | 4,610 | 75,000 | 30,000 |
0.035 | 3,125 | 1.750 | 1,250 | 781 | 75,000 | 30,000 |
0.049 | 3,864 | 1.750 | 1,546 | 966 | 75,000 | 30,000 |
0.065 | 6,019 | 1.750 | 2,407 | 1,505 | 75,000 | 30,000 |
0.083 | 7,860 | 1.750 | 3,144 | 1,965 | 75,000 | 30,000 |
0.095 | 9,135 | 1.750 | 3,654 | 2,284 | 75,000 | 30,000 |
0.109 | 10,672 | 1.750 | 4,269 | 2,668 | 75,000 | 30,000 |
0.120 | 11,921 | 1.750 | 4,768 | 2,980 | 75,000 | 30,000 |
0.134 | 13,563 | 1.750 | 5,425 | 3,391 | 75,000 | 30,000 |
0.148 | 15,268 | 1.750 | 6,107 | 3,817 | 75,000 | 30,000 |
0.165 | 17,430 | 1.750 | 6,972 | 4,357 | 75,000 | 30,000 |
0.035 | 2,720 | 2.000 | 1,088 | 680 | 75,000 | 30,000 |
0.049 | 3,864 | 2.000 | 1,546 | 966 | 75,000 | 30,000 |
0.065 | 5,214 | 2.000 | 2,086 | 1,303 | 75,000 | 30,000 |
0.083 | 6,788 | 2.000 | 2,715 | 1,697 | 75,000 | 30,000 |
0.095 | 7,873 | 2.000 | 3,149 | 1,968 | 75,000 | 30,000 |
0.109 | 9,175 | 2.000 | 3,670 | 2,294 | 75,000 | 30,000 |
0.120 | 10,227 | 2.000 | 4,091 | 2,557 | 75,000 | 30,000 |
0.134 | 11,605 | 2.000 | 4,642 | 2,901 | 75,000 | 30,000 |
0.148 | 13,028 | 2.000 | 5,211 | 3,257 | 75,000 | 30,000 |
BW Ga. |
Outer Diameter Sizes in Inches | Weight Lbs/Ft. |
Inner Diameter | Wall Dec-In |
22 | 3/16 | 0.0478 | 0.131 | 0.028 |
22 | 1/8 | 0.0290 | 0.069 | 0.028 |
20 | 0.0336 | 0.055 | 0.035 | |
20 | 5/16 | 0.1039 | 0.242 | 0.035 |
18 | 0.1382 | 0.214 | 0.049 | |
16 | 0.1722 | 0.182 | 0.065 | |
22 | 3/8 | 0.1038 | 0.319 | 0.028 |
20 | 0.1271 | 0.305 | 0.035 | |
18 | 0.1706 | 0.277 | 0.049 | |
16 | 0.2152 | 0.245 | 0.065 | |
25 | 1/2 | 0.1025 | 0.460 | 0.020 |
20 | 0.1738 | 0.430 | 0.035 | |
18 | 0.2360 | 0.402 | 0.049 | |
16 | 0.3020 | 0.370 | 0.065 | |
25 | 1/4 | 0.0491 | 0.210 | 0.020 |
22 | 0.0664 | 0.194 | 0.028 | |
21 | 0.0745 | 0.187 | 0.032 | |
20 | 0.0804 | 0.180 | 0.035 | |
18 | 0.1052 | 0.152 | 0.049 | |
16 | 0.1284 | 0.120 | 0.065 | |
18 | 7/16 | 0.2036 | 0.340 | 0.049 |
20 | 5/8 | 0.2205 | 0.555 | 0.035 |
18 | 0.3014 | 0.527 | 0.049 | |
16 | 0.3888 | 0.495 | 0.065 | |
18 | 7/8 | 0.4323 | 0.777 | 0.049 |
16 | 0.5623 | 0.745 | 0.065 | |
11 | 0.9676 | 0.635 | 0.120 | |
20 | 3/4 | 0.2673 | 0.680 | 0.035 |
18 | 0.3668 | 0.652 | 0.049 | |
16 | 0.4755 | 0.620 | 0.065 | |
14 | 0.5913 | 0.584 | 0.083 | |
20 | 1 | 0.3607 | 0.930 | 0.035 |
18 | 0.4977 | 0.902 | 0.049 | |
16 | 0.6491 | 0.870 | 0.065 | |
14 | 0.8129 | 0.834 | 0.083 | |
11 | 1.1278 | 0.760 | 0.120 | |
11 | 1-1/4 | 1.4480 | 1.010 | 0.120 |
