ASTM A213 grade covers standard specifications for austenitic and seamless boilers, heat exchangers, and superheated vessels. The ASTM A213 Tube showcases excellent strength and outstanding corrosion resistance properties across an array of stress-induced setups. These robust tubes don’t easily deform under extreme pressures and temperatures. ASTM A213 Stainless Steel Tube in this grade is generally specified in sizes of 3.2mm, having an internal diameter of 127mm, with an outside diameter in the range of 0.4mm up to 12.7mm. They are generally divided into T5, T9, T11, T12, T22, and T91 types. The ASTM A213 Pipe has an excellent chemical composition and mechanical properties. These pipes can be processed in hot or cold rolling properties giving them desired characteristics. These features allow them to be utilized in a wide spectrum of industries.
The A213 grade modules are generally designed in seamless and welded types. In the SA 213 Stainless Steel Seamless Tube, hot steel billets are passed through metal via an extrusion process. This allows the tubes to be shaped in correct dimensions, making them suitable for an array of applications. Designed without any seams or welds, the ASME SA213 Seamless Tubing has higher corrosion resistance properties. The pressurized vessel grade ensures that the strength and load-bearing capacity in the tube is higher. The material is expensive but is preferred in harsh environments where other tubes would distort. The A213 SS Welded Tubes offers a cost-effective solution to the user. The robust tubes are generally produced by rolling sheets or strips followed by welding them in place, making use of standard welding procedures. These tubes can be availed in different sizes, unlike seamless tubes that are restricted to 24 inches. If you want to get a quote on these products or learn more about their features, get in touch with us.
Table of Content
Specification | ASTM A213 / ASME SA213 Tube |
Shapes | Hydraulic, Round, Rectangular, Honed Tubes, Square, Straight, U Shape, Coiled, Pan Cake Coils |
Thickness Range | SCH XXS, SCH 40, SCH XS, SCH 10, SCH 5, SCH XXH, SCH 80S, SCH 160, SCH 80 |
Surface Finish | 400G, BA, 2B, No.1, Mirror Polished, No.8, 500G, No.4, No.3, 8K, 2D, 1D, 180G, 320G, HL, 400G Satin/ Hairline, 600G or 800G Mirror finish Tubing or Custom Finish as per customer's specification |
Manufacturing Type | CDS / CDW / Fabricated / DOM / Seamless / ERW / CEW / Welded / 100% X Ray Welded |
Standard | JIS, DIN, ASTM, GB, AISI, EN, SUS |
Processing Service | Bending, Cutting, Punching, Decoiling, Welding, Moulding |
Technique | Extrusion, Cold drawn, Cold rolled, Hot rolled Tube |
Delivery Condition | Annealed and Pickled (AP), MF, Polished, Cold Drawn, Bright Annealed (BA) |
End | Treaded, Plain End, Beveled End |
Per Kg
SCH10 40 80 ASME A213 seamless ss tube
$ 21.70
Per Kg
ASME SA213 U Shape Heat Exchanger Tube
$ 15.51
Per Kg
ASTM SA213 Seamless Stainless Steel Tube
$ 18.60
ASTM A213 Tube
ASME SA213 Seamless Tubing
A213 SS Welded Tubes
ASME SA 213 Stainless Steel Seamless Tubes
A213M SS Tubing
ASTM A213 Stainless Steel Tube
SA 213 Welded Tubing
ASTM A213 Pipe
SA 213 Stainless Steel Seamless Tube
Wall Thickness in inches | Outer Diameter in inches | D/t Ratio | Inner Diameter in inches | Internal Area (in2) | Tube Cross Sectional Area (in2) |
---|---|---|---|---|---|
0.020 | 0.250 | 12.50 | 0.210 | 0.0346 | 0.0145 |
0.028 | 0.250 | 8.93 | 0.194 | 0.0296 | 0.0195 |
0.035 | 0.250 | 7.14 | 0.180 | 0.0254 | 0.0236 |
0.049 | 0.250 | 5.10 | 0.152 | 0.0181 | 0.0309 |
0.065 | 0.250 | 3.85 | 0.120 | 0.0113 | 0.0378 |
0.020 | 0.375 | 18.75 | 0.335 | 0.0881 | 0.0223 |
0.028 | 0.375 | 13.39 | 0.319 | 0.0799 | 0.0305 |
0.035 | 0.375 | 10.71 | 0.305 | 0.0731 | 0.0374 |
0.049 | 0.375 | 7.65 | 0.277 | 0.0603 | 0.0502 |
0.065 | 0.375 | 5.77 | 0.245 | 0.0471 | 0.0633 |
0.020 | 0.500 | 25.00 | 0.460 | 0.1662 | 0.0302 |
0.028 | 0.500 | 17.86 | 0.444 | 0.1548 | 0.0415 |
0.035 | 0.500 | 14.29 | 0.430 | 0.1452 | 0.0511 |
0.049 | 0.500 | 10.20 | 0.402 | 0.1213 | 0.0694 |
0.065 | 0.500 | 7.69 | 0.370 | 0.1075 | 0.0888 |
0.083 | 0.500 | 6.02 | 0.334 | 0.0876 | 0.1087 |
0.020 | 0.625 | 31.25 | 0.585 | 0.2688 | 0.0380 |
0.028 | 0.625 | 22.32 | 0.569 | 0.2543 | 0.0525 |
0.035 | 0.625 | 17.86 | 0.555 | 0.2419 | 0.0649 |
0.049 | 0.625 | 12.76 | 0.527 | 0.2181 | 0.0887 |
0.065 | 0.625 | 9.62 | 0.495 | 0.1924 | 0.1144 |
0.083 | 0.625 | 7.53 | 0.459 | 0.1655 | 0.1413 |
0.095 | 0.625 | 6.58 | 0.435 | 0.1486 | 0.1582 |
0.109 | 0.625 | 5.73 | 0.407 | 0.1301 | 0.1767 |
0.028 | 0.750 | 26.79 | 0.694 | 0.3783 | 0.0635 |
0.035 | 0.750 | 21.43 | 0.680 | 0.3632 | 0.0786 |
0.049 | 0.750 | 15.31 | 0.652 | 0.3339 | 0.1079 |
0.065 | 0.750 | 11.54 | 0.620 | 0.3019 | 0.1399 |
0.083 | 0.750 | 9.04 | 0.584 | 0.2679 | 0.1739 |
0.095 | 0.750 | 7.89 | 0.560 | 0.2463 | 0.1955 |
0.109 | 0.750 | 6.88 | 0.532 | 0.2223 | 0.2195 |
0.120 | 0.750 | 6.25 | 0.510 | 0.2043 | 0.2375 |
0.020 | 0.875 | 43.75 | 0.835 | 0.5476 | 0.0537 |
0.028 | 0.875 | 31.25 | 0.819 | 0.5268 | 0.0745 |
0.035 | 0.875 | 25.00 | 0.805 | 0.5090 | 0.0924 |
0.049 | 0.875 | 17.86 | 0.777 | 0.4742 | 0.1272 |
0.065 | 0.875 | 13.46 | 0.745 | 0.4359 | 0.1654 |
0.083 | 0.875 | 10.54 | 0.709 | 0.3948 | 0.2065 |
0.095 | 0.875 | 9.21 | 0.685 | 0.3685 | 0.2328 |
0.109 | 0.875 | 8.03 | 0.657 | 0.3390 | 0.2623 |
0.120 | 0.875 | 7.29 | 0.635 | 0.316L7 | 0.2846 |
0.028 | 1.000 | 35.71 | 0.944 | 0.6999 | 0.0855 |
0.035 | 1.000 | 28.57 | 0.930 | 0.6793 | 0.1061 |
0.049 | 1.000 | 20.41 | 0.902 | 0.6390 | 0.1464 |
0.065 | 1.000 | 15.38 | 0.870 | 0.5945 | 0.1909 |
0.083 | 1.000 | 12.05 | 0.834 | 0.5463 | 0.2391 |
0.095 | 1.000 | 10.53 | 0.810 | 0.5153 | 0.2701 |
0.109 | 1.000 | 9.17 | 0.782 | 0.4803 | 0.3051 |
0.120 | 1.000 | 8.33 | 0.760 | 0.4536 | 0.3318 |
0.134 | 1.000 | 7.46 | 0.732 | 0.4208 | 0.3646 |
0.035 | 1.250 | 35.71 | 1.180 | 1.0936 | 0.1336 |
0.049 | 1.250 | 25.51 | 1.152 | 1.0423 | 0.1849 |
0.065 | 1.250 | 19.23 | 1.120 | 0.9852 | 0.2420 |
0.083 | 1.250 | 15.06 | 1.084 | 0.9229 | 0.316L3 |
0.095 | 1.250 | 13.16 | 1.060 | 0.8825 | 0.3447 |
0.109 | 1.250 | 11.47 | 1.032 | 0.8365 | 0.3907 |
0.120 | 1.250 | 10.42 | 1.010 | 0.8012 | 0.4260 |
0.134 | 1.250 | 9.33 | 0.982 | 0.7574 | 0.4698 |
0.035 | 1.500 | 42.86 | 1.430 | 1.6061 | 0.1611 |
0.049 | 1.500 | 30.61 | 1.402 | 1.5438 | 0.2234 |
0.065 | 1.500 | 23.08 | 1.370 | 1.4741 | 0.2930 |
0.083 | 1.500 | 18.07 | 1.334 | 1.3977 | 0.3695 |
0.095 | 1.500 | 15.79 | 1.310 | 1.3478 | 0.4193 |
0.109 | 1.500 | 13.76 | 1.282 | 1.2908 | 0.4763 |
0.120 | 1.500 | 12.50 | 1.260 | 1.2469 | 0.5202 |
0.134 | 1.500 | 11.19 | 1.232 | 1.1921 | 0.5750 |
0.148 | 1.500 | 10.14 | 1.204 | 1.1385 | 0.6286 |
0.035 | 1.750 | 50.00 | 1.680 | 2.2167 | 0.1886 |
0.049 | 1.750 | 40.82 | 1.902 | 2.8413 | 0.3003 |
0.065 | 1.750 | 26.92 | 1.620 | 2.0612 | 0.3441 |
0.083 | 1.750 | 21.08 | 1.584 | 1.9706 | 0.4347 |
0.095 | 1.750 | 18.42 | 1.560 | 1.9113 | 0.4939 |
0.109 | 1.750 | 16.06 | 1.532 | 1.8433 | 0.5619 |
0.120 | 1.750 | 14.58 | 1.510 | 1.7908 | 0.6145 |
0.134 | 1.750 | 13.06 | 1.482 | 1.7250 | 0.6803 |
0.148 | 1.750 | 11.82 | 1.454 | 1.6604 | 0.7449 |
0.165 | 1.750 | 10.61 | 1.420 | 1.5837 | 0.8216 |
0.035 | 2.000 | 57.14 | 1.930 | 2.9255 | 0.2161 |
0.049 | 2.000 | 40.82 | 1.902 | 2.8413 | 0.3003 |
0.065 | 2.000 | 30.77 | 1.870 | 2.7465 | 0.3951 |
0.083 | 2.000 | 24.10 | 1.834 | 2.6417 | 0.4999 |
0.095 | 2.000 | 21.05 | 1.810 | 2.5730 | 0.5685 |
0.109 | 2.000 | 18.35 | 1.782 | 2.4941 | 0.6475 |
0.120 | 2.000 | 16.67 | 1.760 | 2.4328 | 0.7087 |
0.134 | 2.000 | 14.93 | 1.732 | 2.3561 | 0.7855 |
0.148 | 2.000 | 13.51 | 1.704 | 2.2805 | 0.8611 |
0.165 | 2.000 | 12.12 | 1.670 | 2.1904 | 0.9512 |
Outer Diameter size in Inches | Wall Dec-Inch |
BW Ga. |
Inner Diameter | Weight Lbs/Ft. |
1/8 | 0.028 | 22 | 0.069 | 0.0290 |
0.035 | 20 | 0.055 | 0.0336 | |
3/16 | 0.028 | 22 | 0.131 | 0.0478 |
1/4 | 0.020 | 25 | 0.210 | 0.0491 |
0.028 | 22 | 0.194 | 0.0664 | |
0.032 | 21 | 0.187 | 0.0745 | |
0.035 | 20 | 0.180 | 0.0804 | |
0.049 | 18 | 0.152 | 0.1052 | |
0.065 | 16 | 0.120 | 0.1284 | |
5/16 | 0.035 | 20 | 0.242 | 0.1039 |
0.049 | 18 | 0.214 | 0.1382 | |
0.065 | 16 | 0.182 | 0.1722 | |
3/8 | 0.028 | 22 | 0.319 | 0.1038 |
0.035 | 20 | 0.305 | 0.1271 | |
0.049 | 18 | 0.277 | 0.1706 | |
0.065 | 16 | 0.245 | 0.2152 | |
7/16 | 0.049 | 18 | 0.340 | 0.2036 |
1/2 | 0.020 | 25 | 0.460 | 0.1025 |
0.035 | 20 | 0.430 | 0.1738 | |
0.049 | 18 | 0.402 | 0.2360 | |
0.065 | 16 | 0.370 | 0.3020 | |
5/8 | 0.035 | 20 | 0.555 | 0.2205 |
0.049 | 18 | 0.527 | 0.3014 | |
0.065 | 16 | 0.495 | 0.3888 | |
3/4 | 0.035 | 20 | 0.680 | 0.2673 |
0.049 | 18 | 0.652 | 0.3668 | |
0.065 | 16 | 0.620 | 0.4755 | |
0.083 | 14 | 0.584 | 0.5913 | |
7/8 | 0.049 | 18 | 0.777 | 0.4323 |
0.065 | 16 | 0.745 | 0.5623 | |
0.120 | 11 | 0.635 | 0.9676 | |
1 | 0.035 | 20 | 0.930 | 0.3607 |
0.049 | 18 | 0.902 | 0.4977 | |
0.065 | 16 | 0.870 | 0.6491 | |
0.083 | 14 | 0.834 | 0.8129 | |
0.120 | 11 | 0.760 | 1.1278 | |
1-1/4 | 0.120 | 11 | 1.010 | 1.4480 |
Outer Diameter in inches | Theoretical Yield Point ** (PSI) | Wall Thcickness in inches | Tensile Strength (PSI) | Working Pressure (PSI) 25% of Burst | Yield Strength (PSI) | Theoretical Burst Pressure * (PSI) | Collapse Pressure *** (PSI) |
---|---|---|---|---|---|---|---|
0.250 | 5,714 | 0.020 | 75,000 | 3,571 | 30,000 | 14,286 | 4,416 |
0.250 | 8,660 | 0.028 | 75,000 | 5,412 | 30,000 | 21,649 | 5,967 |
0.250 | 11,667 | 0.035 | 75,000 | 7,292 | 30,000 | 29,167 | 7,224 |
0.250 | 19,342 | 0.049 | 75,000 | 12,089 | 30,000 | 48,355 | 9,455 |
0.250 | 32,500 | 0.065 | 75,000 | 20,313 | 30,000 | 81,250 | 11,544 |
0.375 | 3,582 | 0.020 | 75,000 | 2,239 | 30,000 | 8,955 | 3,029 |
0.375 | 5,266 | 0.028 | 75,000 | 3,292 | 30,000 | 13,166 | 4,145 |
0.375 | 6,885 | 0.035 | 75,000 | 4,303 | 30,000 | 17,213 | 5,077 |
0.375 | 10,614 | 0.049 | 75,000 | 6,634 | 30,000 | 26,534 | 6,816 |
0.375 | 15,918 | 0.065 | 75,000 | 9,949 | 30,000 | 39,796 | 8,597 |
0.500 | 2,609 | 0.020 | 75,000 | 1,630 | 30,000 | 6,522 | 2,316L |
0.500 | 3,784 | 0.028 | 75,000 | 2,365 | 30,000 | 9,459 | 3,172 |
0.500 | 4,884 | 0.035 | 75,000 | 3,052 | 30,000 | 12,209 | 3,906 |
0.500 | 7,313 | 0.049 | 75,000 | 4,571 | 30,000 | 18,284 | 5,316L |
0.500 | 10,541 | 0.065 | 75,000 | 6,588 | 30,000 | 26,351 | 6,786 |
0.500 | 14,910 | 0.083 | 75,000 | 9,319 | 30,000 | 37,275 | 8,307 |
0.625 | 2,051 | 0.020 | 75,000 | 1,282 | 30,000 | 5,128 | 1,859 |
0.625 | 2,953 | 0.028 | 75,000 | 1,845 | 30,000 | 7,381 | 2,568 |
0.625 | 3,784 | 0.035 | 75,000 | 2,365 | 30,000 | 9,459 | 3,172 |
0.625 | 5,579 | 0.049 | 75,000 | 3,487 | 30,000 | 13,947 | 4,335 |
0.625 | 7,879 | 0.065 | 75,000 | 4,924 | 30,000 | 19,697 | 5,591 |
0.625 | 10,850 | 0.083 | 75,000 | 6,781 | 30,000 | 27,124 | 6,910 |
0.625 | 13,103 | 0.095 | 75,000 | 8,190 | 30,000 | 32,759 | 7,734 |
0.625 | 16,069 | 0.109 | 75,000 | 10,043 | 30,000 | 40,172 | 8,639 |
0.750 | 2,421 | 0.028 | 75,000 | 1,513 | 30,000 | 6,052 | 2,156 |
0.750 | 3,088 | 0.035 | 75,000 | 1,930 | 30,000 | 7,721 | 2,669 |
0.750 | 4,509 | 0.049 | 75,000 | 2,818 | 30,000 | 11,273 | 3,664 |
0.750 | 6,290 | 0.065 | 75,000 | 3,931 | 30,000 | 15,726 | 4,749 |
0.750 | 8,527 | 0.083 | 75,000 | 5,330 | 30,000 | 21,318 | 5,905 |
0.750 | 10,179 | 0.095 | 75,000 | 6,362 | 30,000 | 25,446 | 6,637 |
0.750 | 12,293 | 0.109 | 75,000 | 7,683 | 30,000 | 30,733 | 7,453 |
0.750 | 14,118 | 0.120 | 75,000 | 8,824 | 30,000 | 35,294 | 8,064 |
0.875 | 1,437 | 0.020 | 75,000 | 898 | 30,000 | 3,593 | 1,340 |
0.875 | 2,051 | 0.028 | 75,000 | 1,282 | 30,000 | 5,128 | 1,859 |
0.875 | 2,609 | 0.035 | 75,000 | 1,630 | 30,000 | 6,522 | 2,316L |
0.875 | 3,784 | 0.049 | 75,000 | 2,365 | 30,000 | 9,459 | 3,172 |
0.875 | 5,235 | 0.065 | 75,000 | 3,272 | 30,000 | 13,087 | 4,126 |
0.875 | 7,024 | 0.083 | 75,000 | 4,390 | 30,000 | 17,560 | 5,152 |
0.875 | 8,321 | 0.095 | 75,000 | 5,201 | 30,000 | 20,803 | 5,807 |
0.875 | 9,954 | 0.109 | 75,000 | 6,221 | 30,000 | 24,886 | 6,543 |
0.875 | 11,339 | 0.120 | 75,000 | 7,087 | 30,000 | 28,346 | 7,100 |
1.000 | 1,780 | 0.028 | 75,000 | 1,112 | 30,000 | 4,449 | 1,633 |
1.000 | 2,258 | 0.035 | 75,000 | 1,411 | 30,000 | 5,645 | 2,027 |
1.000 | 3,259 | 0.049 | 75,000 | 2,037 | 30,000 | 8,149 | 2,796 |
1.000 | 4,483 | 0.065 | 75,000 | 2,802 | 30,000 | 11,207 | 3,647 |
1.000 | 5,971 | 0.083 | 75,000 | 3,732 | 30,000 | 14,928 | 4,567 |
1.000 | 7,037 | 0.095 | 75,000 | 4,398 | 30,000 | 17,593 | 5,159 |
1.000 | 8,363 | 0.109 | 75,000 | 5,227 | 30,000 | 20,908 | 5,827 |
1.000 | 9,474 | 0.120 | 75,000 | 5,921 | 30,000 | 23,684 | 6,336 |
1.000 | 10,984 | 0.134 | 75,000 | 6,865 | 30,000 | 27,459 | 6,963 |
1.250 | 1,780 | 0.035 | 75,000 | 1,112 | 30,000 | 4,449 | 1,633 |
1.250 | 2,552 | 0.049 | 75,000 | 1,595 | 30,000 | 6,380 | 2,260 |
1.250 | 3,482 | 0.065 | 75,000 | 2,176 | 30,000 | 8,705 | 2,958 |
1.250 | 4,594 | 0.083 | 75,000 | 2,871 | 30,000 | 11,485 | 3,719 |
1.250 | 5,377 | 0.095 | 75,000 | 3,361 | 30,000 | 13,443 | 4,213 |
1.250 | 6,337 | 0.109 | 75,000 | 3,961 | 30,000 | 15,843 | 4,776 |
1.250 | 7,129 | 0.120 | 75,000 | 4,455 | 30,000 | 17,822 | 5,207 |
1.250 | 8,187 | 0.134 | 75,000 | 5,117 | 30,000 | 20,468 | 5,742 |
1.500 | 1,469 | 0.035 | 75,000 | 918 | 30,000 | 3,671 | 1,367 |
1.500 | 2,097 | 0.049 | 75,000 | 1,311 | 30,000 | 5,243 | 1,896 |
1.500 | 2,847 | 0.065 | 75,000 | 1,779 | 30,000 | 7,117 | 2,487 |
1.500 | 3,733 | 0.083 | 75,000 | 2,333 | 30,000 | 9,333 | 3,136 |
1.500 | 4,351 | 0.095 | 75,000 | 2,719 | 30,000 | 10,878 | 3,559 |
1.500 | 5,101 | 0.109 | 75,000 | 3,188 | 30,000 | 12,754 | 4,043 |
1.500 | 5,714 | 0.120 | 75,000 | 3,571 | 30,000 | 14,286 | 4,416 |
1.500 | 6,526 | 0.134 | 75,000 | 4,079 | 30,000 | 16,315 | 4,881 |
1.500 | 7,375 | 0.148 | 75,000 | 4,610 | 30,000 | 18,439 | 5,336 |
1.750 | 1,250 | 0.035 | 75,000 | 781 | 30,000 | 3,125 | 1,176 |
1.750 | 1,546 | 0.049 | 75,000 | 966 | 30,000 | 3,864 | 1,434 |
1.750 | 2,407 | 0.065 | 75,000 | 1,505 | 30,000 | 6,019 | 2,146 |
1.750 | 3,144 | 0.083 | 75,000 | 1,965 | 30,000 | 7,860 | 2,711 |
1.750 | 3,654 | 0.095 | 75,000 | 2,284 | 30,000 | 9,135 | 3,080 |
1.750 | 4,269 | 0.109 | 75,000 | 2,668 | 30,000 | 10,672 | 3,504 |
1.750 | 4,768 | 0.120 | 75,000 | 2,980 | 30,000 | 11,921 | 3,832 |
1.750 | 5,425 | 0.134 | 75,000 | 3,391 | 30,000 | 13,563 | 4,242 |
1.750 | 6,107 | 0.148 | 75,000 | 3,817 | 30,000 | 15,268 | 4,645 |
1.750 | 6,972 | 0.165 | 75,000 | 4,357 | 30,000 | 17,430 | 5,124 |
2.000 | 1,088 | 0.035 | 75,000 | 680 | 30,000 | 2,720 | 1,032 |
2.000 | 1,546 | 0.049 | 75,000 | 966 | 30,000 | 3,864 | 1,434 |
2.000 | 2,086 | 0.065 | 75,000 | 1,303 | 30,000 | 5,214 | 1,887 |
2.000 | 2,715 | 0.083 | 75,000 | 1,697 | 30,000 | 6,788 | 2,387 |
2.000 | 3,149 | 0.095 | 75,000 | 1,968 | 30,000 | 7,873 | 2,715 |
2.000 | 3,670 | 0.109 | 75,000 | 2,294 | 30,000 | 9,175 | 3,092 |
2.000 | 4,091 | 0.120 | 75,000 | 2,557 | 30,000 | 10,227 | 3,384 |
2.000 | 4,642 | 0.134 | 75,000 | 2,901 | 30,000 | 11,605 | 3,751 |
2.000 | 5,211 | 0.148 | 75,000 | 3,257 | 30,000 | 13,028 | 4,111 |
2.000 | 5,928 | 0.165 | 75,000 | 3,705 | 30,000 | 14,820 | 4,542 |
Grades | Carbon | Phosphorus | Manganese | Sulfur | Silicon | Molybdenum | Nickel | Chromium |
TP304 | 0.08 | 0.045 | 2 | 0.03 | 1 | 8.0-11.0 | 18.0-20.0 | |
TP304L | 0.035 | 0.045 | 2 | 0.03 | 1 | 8.0-13.0 | 18.0-20.0 | |
TP316 | 0.08 | 0.045 | 2 | 0.03 | 1 | 2.0-3.0 | 11.0-14.0 | 16.0-18.0 |
TP316L | 0.035 | 0.045 | 2 | 0.03 | 1 | 2.0-3.0 | 10.0-14.0 | 16.0-18.0 |
Material | Temperure | Tensile Strength | Heat | Yield Strength | Elongation |
Min. º F(º C) | Ksi (MPa), Min. | Treatment | Ksi (MPa), Min. | ||
TP304 | 1900 (1040) | 75(515) | Solution | 30(205) | 35 |
TP304L | 1900 (1040) | 70(485) | Solution | 25(170) | 35 |
TP316 | 1900(1040) | 75(515) | Solution | 30(205) | 35 |
TP316L | 1900(1040) | 70(485) | Solution | 25(170) | 35 |
ASTM Standards
Pipe Specifications
