ASTM 249 TP304 grade covers standard specifications for austenitic 304 steel boiler, condenser tubes, heat exchanger, and boiler vessels. The ASTM A249 TP304 Tube is designed with a superior composition consisting of nickel and chromium with other alloying elements. The content embedded within these tubes gives them excellent resistance to reductive and corrosive media. The ASTM A249 Austenitic SS Seamless Tubing is non-magnetic in nature and showcases outstanding strength in the system. These tubes are produced via the extrusion process as hot steel billets are passed through extruded metal. This gives the ASME SA249 Grade Seamless Tubing enhanced tolerance in pressurized vessel applications. This tubing doesn’t easily disorientate in any pressures and has enhanced load-bearing capacity. Our Institution has strong links to some of the best logistical supply chains allowing us to deliver all our products to your doorstep within a short period.
The ASTM A249 GR 304 Welded Tube requires lower processing time and is produced by rolling pieces of sheet or strip followed by welding them in place, making use of standard welding procedures. They are very durable and are cheaper to produce than standard seamless tubes. The ASME SA213 Type 304 ERW Tube is deemed fit for use in high pressure and temperature applications. Designed via passing high-voltage current through the metal, these tubes don’t require any filler metal to be welded in place. ASTM A249 Type 304 cold drawn precision Tubing is highly precise and has accurate dimensions. The cold drawn tubes are processed at room temperature and have outstanding strength and tolerance when compared to a hot rolled tube. If you have any questions or queries about our products or their pricing, contact us or visit any of our outlets for more information
Table of Content
Specification | ASTM A249 Tp304 / ASME SA249 Tp304 Tube |
Shapes | Hydraulic, Honed Tubes, Round, Rectangular, U Shape, Square, Straight, Coiled, Pan Cake Coils |
Surface Finish | 400G, BA, 2B, 320G, Mirror Polished, No.1, 400G Satin/ Hairline, 500G, No.4, No.3, No.8, 8K, 2D, 1D, 180G, HL, 600G or 800G Mirror finish Tubing or Custom Finish as per customer's specification |
Technique | Cold rolled, Extrusion, Cold drawn, Hot rolled Tube |
Manufacturing Type | Welded / CDS / CDW / ERW / Fabricated / Seamless / DOM / CEW / 100% X Ray Welded |
Thickness Range | SCH 5, SCH XXS, SCH 40, SCH 80S, SCH 10, SCH XXH, SCH XS, SCH 160, SCH 80 |
Standard | JIS, DIN, ASTM, GB, AISI, EN, SUS |
End | Beveled End, Treaded, Plain End |
Processing Service | Bending, Moulding, Welding, Cutting, Decoiling, Punching |
Delivery Condition | Cold Drawn, Annealed and Pickled (AP), Polished, MF, Bright Annealed (BA) |
Per Kg
253ma Welded ASME SA249 TP304 Stainless Steel Tubes for Heat Exchanger
$ 21.62
Per Kg
ASME SA249 TP304 Stainless Steel Seamless Instrumentation Tube
$ 4.96
Per Kg
12mm ASME SA249 TP304 Seamless Square Stainless Steel Pipe
$ 11.35
ASTM A249 TP304 Tubes
ASME SA249 Grade TP304 Seamless Tubing
SA 249 304 SS Tubes
ASTM A249 GR 304 Welded Tubing
ASTM A249 Type 304 cold drawn precision Tubing
ASME SA249 Austenitic SS Seamless Tubing
ASME SA213 Type 304 ERW Tube
SS SA 249 UNS S30400 Tube
ASTM A249 SS 304 Seamless Tube
Grade | Carbon | Phosphorus | Manganese | Sulfur | Chromium | Silicon | Nickel |
TP304 | 0.08 | 0.045 | 2 | 0.03 | 18.0-20.0 | 1 | 8.0-11.0 |
Material | Temperature | Elongation | Tensile Strength | Heat | Yield Strength |
Min.º F(º C) | Ksi (MPa), Min. | Treatment | Ksi (MPa), Min. | ||
TP304 | 1900 (1040) | 35 | 75(515) | Solution | 30(205) |
Grade | Unified Numbering System | Old British | Euronorm | Swedish SS | Japanese Industrial Standards | ||
British Standards | European Standards | No | Name | ||||
ASTM A249 TP304 | S30400 | 304S31 | 58E | 1.4301 | X5CrNi18-10 | 2332 | SUS 304 |
Grade |
Density (kg/m3) | Specific Heat 0-100°C (J/kg.K) | Elastic Modulus (GPa) | Thermal Conductivity (W/m.K) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Electrical Resistivity (nΩ.m) | |||
at 100°C | at 500°C | 0-100°C | 0-315°C | 0-538°C | |||||
304 | 8000 | 500 | 193 | 16.2 | 21.5 | 17.2 | 17.8 | 18.4 | 720 |
Dimensions in Mm | Wall Thickness in Mm | Weight per Kg | Dimensions in Mm | Wall Thickness in Mm | Weight per Kg | |
---|---|---|---|---|---|---|
12.7 * 12.7 | 1.20 | 0.44 | 40*40 | 1.20 | 1.49 | |
12.7 * 12.7 | 1.50 | 0.55 | 40*40 | 1.50 | 1.85 | |
15 * 15 | 1.20 | 0.53 | 40*40 | 2.00 | 2.45 | |
15 * 15 | 1.50 | 0.65 | 40*40 | 3.00 | 3.75 | |
20 * 20 | 1.20 | 0.71 | 50*50 | 1.50 | 2.32 | |
20 * 20 | 1.50 | 0.88 | 50*50 | 2.00 | 3.08 | |
20 * 20 | 2.00 | 1.19 | 50*50 | 3.00 | 4.65 | |
25 * 25 | 1.20 | 0.92 | 60*60 | 2.00 | 3.71 | |
25 * 25 | 1.50 | 1.14 | 60*60 | 3.00 | 5.49 | |
25 * 25 | 2.00 | 1.49 | 70*70 | 3.00 | 6.53 | |
25 * 25 | 3.00 | 2.20 | 80*80 | 2.00 | 4.98 | |
30 * 30 | 1.20 | 1.10 | 80*80 | 3.00 | 7.53 | |
30 * 30 | 1.50 | 1.37 | 100 * 100 | 2.00 | 6.40 | |
30 * 30 | 2.00 | 1.84 | 100 * 100 | 3.00 | 9.53 | |
30 * 30 | 3.00 | 2.72 |
Outer Diameter Size Inches |
Tolerances, Inches | ||
Outer Diameter in Inches |
Wall Thickness | Cut Length in Inch |
|
Less than 1 | ±0.004 | All Sizes ± 10% |
+1/8–0 |
1 to 1-1/2 | ±0.006 | ||
Over 1-1/2 to 2 | ±0.008 | ||
Over 2 to 2-1/2 | ±0.010 | +3/16–0 | |
Over 2-1/2 to 3 | ±0.012 | ||
Over 3 to 4 | ±0.015 | ||
Over 4 to 5 | +0.015 – 0.025 |
Wall Thickness in inches | Theoretical Burst Pressure | Minimum Yield Strength (PSI) | Outer Diameter in Inch | Minimum Tensile Strength (PSI) | Collapse Pressure | Working Pressure |
---|---|---|---|---|---|---|
0.049 | 26,534 | 30,000 | 0.375 | 75,000 | 6,816 | 6,634 |
0.020 | 14,286 | 30,000 | 0.250 | 75,000 | 4,416 | 3,571 |
0.035 | 29,167 | 30,000 | 0.250 | 75,000 | 7,224 | 7,292 |
0.049 | 48,355 | 30,000 | 0.250 | 75,000 | 9,455 | 12,089 |
0.065 | 81,250 | 30,000 | 0.250 | 75,000 | 11,544 | 20,313 |
0.028 | 21,649 | 30,000 | 0.250 | 75,000 | 5,967 | 5,412 |
0.020 | 8,955 | 30,000 | 0.375 | 75,000 | 3,029 | 2,239 |
0.049 | 18,284 | 30,000 | 0.500 | 75,000 | 5,304 | 4,571 |
0.028 | 13,166 | 30,000 | 0.375 | 75,000 | 4,145 | 3,292 |
0.035 | 17,213 | 30,000 | 0.375 | 75,000 | 5,077 | 4,303 |
0.065 | 39,796 | 30,000 | 0.375 | 75,000 | 8,597 | 9,949 |
0.020 | 6,522 | 30,000 | 0.500 | 75,000 | 2,304 | 1,630 |
0.028 | 9,459 | 30,000 | 0.500 | 75,000 | 3,172 | 2,365 |
0.035 | 12,209 | 30,000 | 0.500 | 75,000 | 3,906 | 3,052 |
0.065 | 26,351 | 30,000 | 0.500 | 75,000 | 6,786 | 6,588 |
0.083 | 37,275 | 30,000 | 0.500 | 75,000 | 8,307 | 9,319 |
0.020 | 5,128 | 30,000 | 0.625 | 75,000 | 1,859 | 1,282 |
0.028 | 7,381 | 30,000 | 0.625 | 75,000 | 2,568 | 1,845 |
0.035 | 9,459 | 30,000 | 0.625 | 75,000 | 3,172 | 2,365 |
0.049 | 13,947 | 30,000 | 0.625 | 75,000 | 4,335 | 3,487 |
0.065 | 19,697 | 30,000 | 0.625 | 75,000 | 5,591 | 4,924 |
0.065 | 15,726 | 30,000 | 0.750 | 75,000 | 4,749 | 3,931 |
0.083 | 27,124 | 30,000 | 0.625 | 75,000 | 6,910 | 6,781 |
0.095 | 32,759 | 30,000 | 0.625 | 75,000 | 7,734 | 8,190 |
0.109 | 40,172 | 30,000 | 0.625 | 75,000 | 8,639 | 10,043 |
0.028 | 6,052 | 30,000 | 0.750 | 75,000 | 2,156 | 1,513 |
0.035 | 7,721 | 30,000 | 0.750 | 75,000 | 2,669 | 1,930 |
0.049 | 11,273 | 30,000 | 0.750 | 75,000 | 3,664 | 2,818 |
0.083 | 21,318 | 30,000 | 0.750 | 75,000 | 5,905 | 5,330 |
0.095 | 25,446 | 30,000 | 0.750 | 75,000 | 6,637 | 6,362 |
0.109 | 30,733 | 30,000 | 0.750 | 75,000 | 7,453 | 7,683 |
0.120 | 35,294 | 30,000 | 0.750 | 75,000 | 8,064 | 8,824 |
0.020 | 3,593 | 30,000 | 0.875 | 75,000 | 1,340 | 898 |
0.028 | 5,128 | 30,000 | 0.875 | 75,000 | 1,859 | 1,282 |
0.028 | 4,449 | 30,000 | 1.000 | 75,000 | 1,633 | 1,112 |
0.035 | 6,522 | 30,000 | 0.875 | 75,000 | 2,304 | 1,630 |
0.049 | 9,459 | 30,000 | 0.875 | 75,000 | 3,172 | 2,365 |
0.065 | 13,087 | 30,000 | 0.875 | 75,000 | 4,126 | 3,272 |
0.083 | 17,560 | 30,000 | 0.875 | 75,000 | 5,152 | 4,390 |
0.095 | 20,803 | 30,000 | 0.875 | 75,000 | 5,807 | 5,201 |
0.109 | 24,886 | 30,000 | 0.875 | 75,000 | 6,543 | 6,221 |
0.120 | 28,346 | 30,000 | 0.875 | 75,000 | 7,100 | 7,087 |
0.035 | 5,645 | 30,000 | 1.000 | 75,000 | 2,027 | 1,411 |
0.049 | 8,149 | 30,000 | 1.000 | 75,000 | 2,796 | 2,037 |
0.065 | 11,207 | 30,000 | 1.000 | 75,000 | 3,647 | 2,802 |
0.083 | 14,928 | 30,000 | 1.000 | 75,000 | 4,567 | 3,732 |
0.095 | 17,593 | 30,000 | 1.000 | 75,000 | 5,159 | 4,398 |
0.109 | 20,908 | 30,000 | 1.000 | 75,000 | 5,827 | 5,227 |
0.120 | 23,684 | 30,000 | 1.000 | 75,000 | 6,336 | 5,921 |
0.134 | 27,459 | 30,000 | 1.000 | 75,000 | 6,963 | 6,865 |
0.035 | 4,449 | 30,000 | 1.250 | 75,000 | 1,633 | 1,112 |
0.049 | 6,380 | 30,000 | 1.250 | 75,000 | 2,260 | 1,595 |
0.065 | 8,705 | 30,000 | 1.250 | 75,000 | 2,958 | 2,176 |
0.083 | 11,485 | 30,000 | 1.250 | 75,000 | 3,719 | 2,871 |
0.095 | 13,443 | 30,000 | 1.250 | 75,000 | 4,213 | 3,361 |
0.109 | 15,843 | 30,000 | 1.250 | 75,000 | 4,776 | 3,961 |
0.120 | 17,822 | 30,000 | 1.250 | 75,000 | 5,207 | 4,455 |
0.134 | 20,468 | 30,000 | 1.250 | 75,000 | 5,742 | 5,117 |
0.035 | 3,671 | 30,000 | 1.500 | 75,000 | 1,367 | 918 |
0.049 | 5,243 | 30,000 | 1.500 | 75,000 | 1,896 | 1,311 |
0.065 | 7,117 | 30,000 | 1.500 | 75,000 | 2,487 | 1,779 |
0.083 | 9,333 | 30,000 | 1.500 | 75,000 | 3,136 | 2,333 |
0.095 | 10,878 | 30,000 | 1.500 | 75,000 | 3,559 | 2,719 |
0.109 | 12,754 | 30,000 | 1.500 | 75,000 | 4,043 | 3,188 |
0.120 | 14,286 | 30,000 | 1.500 | 75,000 | 4,416 | 3,571 |
0.134 | 16,315 | 30,000 | 1.500 | 75,000 | 4,881 | 4,079 |
0.148 | 18,439 | 30,000 | 1.500 | 75,000 | 5,336 | 4,610 |
0.035 | 3,125 | 30,000 | 1.750 | 75,000 | 1,176 | 781 |
0.049 | 3,864 | 30,000 | 1.750 | 75,000 | 1,434 | 966 |
0.065 | 6,019 | 30,000 | 1.750 | 75,000 | 2,146 | 1,505 |
0.083 | 7,860 | 30,000 | 1.750 | 75,000 | 2,711 | 1,965 |
0.095 | 9,135 | 30,000 | 1.750 | 75,000 | 3,080 | 2,284 |
0.109 | 10,672 | 30,000 | 1.750 | 75,000 | 3,504 | 2,668 |
0.120 | 11,921 | 30,000 | 1.750 | 75,000 | 3,832 | 2,980 |
0.134 | 13,563 | 30,000 | 1.750 | 75,000 | 4,242 | 3,391 |
0.148 | 15,268 | 30,000 | 1.750 | 75,000 | 4,645 | 3,817 |
0.165 | 17,430 | 30,000 | 1.750 | 75,000 | 5,124 | 4,357 |
0.035 | 2,720 | 30,000 | 2.000 | 75,000 | 1,032 | 680 |
0.049 | 3,864 | 30,000 | 2.000 | 75,000 | 1,434 | 966 |
0.065 | 5,214 | 30,000 | 2.000 | 75,000 | 1,887 | 1,303 |
0.083 | 6,788 | 30,000 | 2.000 | 75,000 | 2,387 | 1,697 |
0.095 | 7,873 | 30,000 | 2.000 | 75,000 | 2,715 | 1,968 |
0.109 | 9,175 | 30,000 | 2.000 | 75,000 | 3,092 | 2,294 |
0.120 | 10,227 | 30,000 | 2.000 | 75,000 | 3,384 | 2,557 |
0.134 | 11,605 | 30,000 | 2.000 | 75,000 | 3,751 | 2,901 |
0.148 | 13,028 | 30,000 | 2.000 | 75,000 | 4,111 | 3,257 |
0.165 | 14,820 | 30,000 | 2.000 | 75,000 | 4,542 | 3,705 |
