ASTM A249 TP304L Tube
ASME SA249 Gr 304L Welded Tubing and A249 Type 304L ERW Tube Supplier in India
ASTM A249 TP304L is a standard specification that covers boiler and heat exchanger tubes that are designed with a 304l stainless steel grade. The ASTM A249 TP304L Tube is an austenitic grade designed with a low-carbon content. These tubes have a chemical composition consisting of chromium and nickel. This gives the tubes enhanced resistance to corrosive and oxidative media. The ASTM A249 Tp 304L Austenitic Stainless Steel Tube works well in a high-temperature setup and showcases enhanced formability allowing them to be shaped in correct dimensions. ASTM A249 Austenitic SS Tube has good resistance to sensitization allowing these tubes to be welded, making use of standard procedures. Our institution has good tie-ups with logistical systems, allowing us to deliver products within a short span of time to our customers.
The versatile grade of tubes are designed in seamless, welded, and erw configurations. Each of these types has its own set of features that allow them to be utilized across different applications. The SA249 UNS S30403 Seamless Tubing is manufactured via the extrusion process. Here hot steel billets are passed through the metal to precisely shape them in the correct dimensions. Designed without welds or seams these tubes have higher strength and load-bearing capacity compared to welded tubes. ASME SA249 Gr 304L Welded Tubing is produced as sheets or strips are rolled and subsequently welded in an array of shop welding procedures. The tubes are not as strong as seamless pipes but are cheaper than the latter. The A249 Type 304L ERW Tube is a unique module that is welded longitudinally in place. These tubes are welded in place by passing high voltage electricity through them. These tubes don’t require any filler material to weld them in place. To know more about tubes in this grade or get a quote on them, contact our customer service for more information.
ASTM A249 Tp 304L Austenitic Stainless Steel Tube and SA249 GR TP249 Welded Tubing exporter in Mumbai
Table of Content
- Specification of ASTM A249 TP304L Tube
- ASME SA249 TP304L Tubing Price list
- ASME SA249 Gr 304L Welded Tubing Types
- Pressure Rating of A249 Type 304L ERW Tube
- SA249 GR TP249 Welded Tubing Dimension Chart
- ASTM A249 Austenitic SS Tube Chemical Composition
- ASME SA 249 304L Stainless Steel ERW Tubing Mechanical Properties
- Equivalent material of ASTM A249 TP304L Tube
- Physical Properties of UNS S30403 SA 249 Tubes
Specification of ASTM A249 TP304L Tube
Check Online Price List of Sa-249 TP304L ERW Tube and ASTM A249 Grade 304L Welded Tubes
| Specification | ASTM A249 Tp304L / ASME SA249 Tp304L Tube |
| Shapes | Hydraulic, Honed Tubes, Round, Rectangular, U Shape, Square, Straight, Coiled, Pan Cake Coils |
| Technique | Cold rolled, Extrusion, Cold drawn, Hot rolled Tube |
| Manufacturing Type | Welded / CDS / CDW / ERW / Fabricated / Seamless / DOM / CEW / 100% X Ray Welded |
| Surface Finish | 400G, BA, 2B, 320G, Mirror Polished, No.1, 400G Satin/ Hairline, 500G, No.4, No.3, No.8, 8K, 2D, 1D, 180G, HL, 600G or 800G Mirror finish Tubing or Custom Finish as per customer's specification |
| Thickness Range | SCH 5, SCH XXS, SCH 40, SCH 80S, SCH 10, SCH XXH, SCH XS, SCH 160, SCH 80 |
| End | Beveled End, Treaded, Plain End |
| Processing Service | Bending, Moulding, Welding, Cutting, Decoiling, Punching |
| Standard | JIS, DIN, ASTM, GB, AISI, EN, SUS |
| Delivery Condition | Cold Drawn, Annealed and Pickled (AP), Polished, MF, Bright Annealed (BA) |
ASME SA249 TP304L Tubing Price list
Per Kg
ASTM A249 Tp304l 2b Ba No1 Welded Stainless Steel Decorative Tube
$ 12.40
Per Kg
ASME SA249 tp304l 20mm 15mm stainless steel mirror round perforated tube
$ 13.95
Per Kg
ASME SA269 TP304l Polished 3/8" (9.53) * 0.89 * 6000mm Stainless Steel Tube
$ 10.33
ASME SA249 Gr 304L Welded Tubing Types
ASTM A249 TP304L Tube
ASME SA249 Gr 304L Welded Tubing
A249 Type 304L ERW Tube
ASTM A249 Tp 304L Austenitic Stainless Steel Tube
SA249 GR TP249 Welded Tubing
Sa-249 TP304L ERW Tube
ASTM A249 Grade 304L Welded Tubes
ASME SA 249 304L Stainless Steel Tube
SA249 UNS S30403 Seamless Tubing
Pressure Rating of A249 Type 304L ERW Tube
Searching for ASTM A249 TP304L Tube manufacturers in India? Exporter of ASME SA 249 304L Stainless Steel Tube and SA249 UNS S30403 Seamless Tubing at highly competitive prices
| Outer Diameter in Inch | Wall Thickness in inches | Theoretical Burst Pressure | Minimum Yield Strength (PSI) | Minimum Tensile Strength (PSI) | Collapse Pressure | Working Pressure |
|---|---|---|---|---|---|---|
| 0.375 | 0.049 | 26,534 | 30,000 | 75,000 | 6,816 | 6,634 |
| 0.250 | 0.020 | 14,286 | 30,000 | 75,000 | 4,416 | 3,571 |
| 0.250 | 0.035 | 29,167 | 30,000 | 75,000 | 7,224 | 7,292 |
| 0.250 | 0.049 | 48,355 | 30,000 | 75,000 | 9,455 | 12,089 |
| 0.250 | 0.065 | 81,250 | 30,000 | 75,000 | 11,544 | 20,313 |
| 0.250 | 0.028 | 21,649 | 30,000 | 75,000 | 5,967 | 5,412 |
| 0.375 | 0.020 | 8,955 | 30,000 | 75,000 | 3,029 | 2,239 |
| 0.500 | 0.049 | 18,284 | 30,000 | 75,000 | 5,304 | 4,571 |
| 0.375 | 0.028 | 13,166 | 30,000 | 75,000 | 4,145 | 3,292 |
| 0.375 | 0.035 | 17,213 | 30,000 | 75,000 | 5,077 | 4,303 |
| 0.375 | 0.065 | 39,796 | 30,000 | 75,000 | 8,597 | 9,949 |
| 0.500 | 0.020 | 6,522 | 30,000 | 75,000 | 2,304 | 1,630 |
| 0.500 | 0.028 | 9,459 | 30,000 | 75,000 | 3,172 | 2,365 |
| 0.500 | 0.035 | 12,209 | 30,000 | 75,000 | 3,906 | 3,052 |
| 0.500 | 0.065 | 26,351 | 30,000 | 75,000 | 6,786 | 6,588 |
| 0.500 | 0.083 | 37,275 | 30,000 | 75,000 | 8,307 | 9,319 |
| 0.625 | 0.020 | 5,128 | 30,000 | 75,000 | 1,859 | 1,282 |
| 0.625 | 0.028 | 7,381 | 30,000 | 75,000 | 2,568 | 1,845 |
| 0.625 | 0.035 | 9,459 | 30,000 | 75,000 | 3,172 | 2,365 |
| 0.625 | 0.049 | 13,947 | 30,000 | 75,000 | 4,335 | 3,487 |
| 0.625 | 0.065 | 19,697 | 30,000 | 75,000 | 5,591 | 4,924 |
| 0.750 | 0.065 | 15,726 | 30,000 | 75,000 | 4,749 | 3,931 |
| 0.625 | 0.083 | 27,124 | 30,000 | 75,000 | 6,910 | 6,781 |
| 0.625 | 0.095 | 32,759 | 30,000 | 75,000 | 7,734 | 8,190 |
| 0.625 | 0.109 | 40,172 | 30,000 | 75,000 | 8,639 | 10,043 |
| 0.750 | 0.028 | 6,052 | 30,000 | 75,000 | 2,156 | 1,513 |
| 0.750 | 0.035 | 7,721 | 30,000 | 75,000 | 2,669 | 1,930 |
| 0.750 | 0.049 | 11,273 | 30,000 | 75,000 | 3,664 | 2,818 |
| 0.750 | 0.083 | 21,318 | 30,000 | 75,000 | 5,905 | 5,330 |
| 0.750 | 0.095 | 25,446 | 30,000 | 75,000 | 6,637 | 6,362 |
| 0.750 | 0.109 | 30,733 | 30,000 | 75,000 | 7,453 | 7,683 |
| 0.750 | 0.120 | 35,294 | 30,000 | 75,000 | 8,064 | 8,824 |
| 0.875 | 0.020 | 3,593 | 30,000 | 75,000 | 1,340 | 898 |
| 0.875 | 0.028 | 5,128 | 30,000 | 75,000 | 1,859 | 1,282 |
| 1.000 | 0.028 | 4,449 | 30,000 | 75,000 | 1,633 | 1,112 |
| 0.875 | 0.035 | 6,522 | 30,000 | 75,000 | 2,304 | 1,630 |
| 0.875 | 0.049 | 9,459 | 30,000 | 75,000 | 3,172 | 2,365 |
| 0.875 | 0.065 | 13,087 | 30,000 | 75,000 | 4,126 | 3,272 |
| 0.875 | 0.083 | 17,560 | 30,000 | 75,000 | 5,152 | 4,390 |
| 0.875 | 0.095 | 20,803 | 30,000 | 75,000 | 5,807 | 5,201 |
| 0.875 | 0.109 | 24,886 | 30,000 | 75,000 | 6,543 | 6,221 |
| 0.875 | 0.120 | 28,346 | 30,000 | 75,000 | 7,100 | 7,087 |
| 1.000 | 0.035 | 5,645 | 30,000 | 75,000 | 2,027 | 1,411 |
| 1.000 | 0.049 | 8,149 | 30,000 | 75,000 | 2,796 | 2,037 |
| 1.000 | 0.065 | 11,207 | 30,000 | 75,000 | 3,647 | 2,802 |
| 1.000 | 0.083 | 14,928 | 30,000 | 75,000 | 4,567 | 3,732 |
| 1.000 | 0.095 | 17,593 | 30,000 | 75,000 | 5,159 | 4,398 |
| 1.000 | 0.109 | 20,908 | 30,000 | 75,000 | 5,827 | 5,227 |
| 1.000 | 0.120 | 23,684 | 30,000 | 75,000 | 6,336 | 5,921 |
| 1.000 | 0.134 | 27,459 | 30,000 | 75,000 | 6,963 | 6,865 |
| 1.250 | 0.035 | 4,449 | 30,000 | 75,000 | 1,633 | 1,112 |
| 1.250 | 0.049 | 6,380 | 30,000 | 75,000 | 2,260 | 1,595 |
| 1.250 | 0.065 | 8,705 | 30,000 | 75,000 | 2,958 | 2,176 |
| 1.250 | 0.083 | 11,485 | 30,000 | 75,000 | 3,719 | 2,871 |
| 1.250 | 0.095 | 13,443 | 30,000 | 75,000 | 4,213 | 3,361 |
| 1.250 | 0.109 | 15,843 | 30,000 | 75,000 | 4,776 | 3,961 |
| 1.250 | 0.120 | 17,822 | 30,000 | 75,000 | 5,207 | 4,455 |
| 1.250 | 0.134 | 20,468 | 30,000 | 75,000 | 5,742 | 5,117 |
| 1.500 | 0.035 | 3,671 | 30,000 | 75,000 | 1,367 | 918 |
| 1.500 | 0.049 | 5,243 | 30,000 | 75,000 | 1,896 | 1,311 |
| 1.500 | 0.065 | 7,117 | 30,000 | 75,000 | 2,487 | 1,779 |
| 1.500 | 0.083 | 9,333 | 30,000 | 75,000 | 3,136 | 2,333 |
| 1.500 | 0.095 | 10,878 | 30,000 | 75,000 | 3,559 | 2,719 |
| 1.500 | 0.109 | 12,754 | 30,000 | 75,000 | 4,043 | 3,188 |
| 1.500 | 0.120 | 14,286 | 30,000 | 75,000 | 4,416 | 3,571 |
| 1.500 | 0.134 | 16,315 | 30,000 | 75,000 | 4,881 | 4,079 |
| 1.500 | 0.148 | 18,439 | 30,000 | 75,000 | 5,336 | 4,610 |
| 1.750 | 0.035 | 3,125 | 30,000 | 75,000 | 1,176 | 781 |
| 1.750 | 0.049 | 3,864 | 30,000 | 75,000 | 1,434 | 966 |
| 1.750 | 0.065 | 6,019 | 30,000 | 75,000 | 2,146 | 1,505 |
| 1.750 | 0.083 | 7,860 | 30,000 | 75,000 | 2,711 | 1,965 |
| 1.750 | 0.095 | 9,135 | 30,000 | 75,000 | 3,080 | 2,284 |
| 1.750 | 0.109 | 10,672 | 30,000 | 75,000 | 3,504 | 2,668 |
| 1.750 | 0.120 | 11,921 | 30,000 | 75,000 | 3,832 | 2,980 |
| 1.750 | 0.134 | 13,563 | 30,000 | 75,000 | 4,242 | 3,391 |
| 1.750 | 0.148 | 15,268 | 30,000 | 75,000 | 4,645 | 3,817 |
| 1.750 | 0.165 | 17,430 | 30,000 | 75,000 | 5,124 | 4,357 |
| 2.000 | 0.035 | 2,720 | 30,000 | 75,000 | 1,032 | 680 |
| 2.000 | 0.049 | 3,864 | 30,000 | 75,000 | 1,434 | 966 |
| 2.000 | 0.065 | 5,214 | 30,000 | 75,000 | 1,887 | 1,303 |
| 2.000 | 0.083 | 6,788 | 30,000 | 75,000 | 2,387 | 1,697 |
| 2.000 | 0.095 | 7,873 | 30,000 | 75,000 | 2,715 | 1,968 |
| 2.000 | 0.109 | 9,175 | 30,000 | 75,000 | 3,092 | 2,294 |
| 2.000 | 0.120 | 10,227 | 30,000 | 75,000 | 3,384 | 2,557 |
| 2.000 | 0.134 | 11,605 | 30,000 | 75,000 | 3,751 | 2,901 |
| 2.000 | 0.148 | 13,028 | 30,000 | 75,000 | 4,111 | 3,257 |
| 2.000 | 0.165 | 14,820 | 30,000 | 75,000 | 4,542 | 3,705 |
SA249 GR TP249 Welded Tubing Dimension Chart
| Dimensions in Mm | Wall Thickness in Mm | Weight per Kg | Dimensions in Mm | Weight per Kg | Wall Thickness in Mm | |
|---|---|---|---|---|---|---|
| 12.7 * 12.7 | 1.20 | 1.49 | 40*40 | 0.44 | 1.20 | |
| 12.7 * 12.7 | 1.50 | 1.85 | 40*40 | 0.55 | 1.50 | |
| 15 * 15 | 1.20 | 2.45 | 40*40 | 0.53 | 2.00 | |
| 15 * 15 | 1.50 | 3.75 | 40*40 | 0.65 | 3.00 | |
| 20 * 20 | 1.20 | 2.32 | 50*50 | 0.71 | 1.50 | |
| 20 * 20 | 1.50 | 3.08 | 50*50 | 0.88 | 2.00 | |
| 20 * 20 | 2.00 | 4.65 | 50*50 | 1.19 | 3.00 | |
| 25 * 25 | 1.20 | 3.71 | 60*60 | 0.92 | 2.00 | |
| 25 * 25 | 1.50 | 5.49 | 60*60 | 1.14 | 3.00 | |
| 25 * 25 | 2.00 | 6.53 | 70*70 | 1.49 | 3.00 | |
| 25 * 25 | 3.00 | 4.98 | 80*80 | 2.20 | 2.00 | |
| 30 * 30 | 1.20 | 7.53 | 80*80 | 1.10 | 3.00 | |
| 30 * 30 | 1.50 | 6.40 | 100 * 100 | 1.37 | 2.00 | |
| 30 * 30 | 2.00 | 9.53 | 100 * 100 | 1.84 | 3.00 | |
| 30 * 30 | 3.00 | 2.72 | ||||
ASTM A249 Austenitic SS Tube Chemical Composition
| Grade | Carbon | Phosphorus | Sulfur | Manganese | Silicon | Chromium | Nickel |
| TP304L | 0.035 | 0.045 | 0.03 | 2 | 1 | 18.0-20.0 | 8.0-13.0 |
ASME SA 249 304L Stainless Steel ERW Tubing Mechanical Properties
Huge Range of ASTM A249 Austenitic SS Tube and ASME SA 249 304L Stainless Steel ERW Tubing in India, supplying UNS S30403 SA 249 Tubes since 2001
| Material | Temperure | Heat | Yield Strength | Tensile Strength | Elongation |
| Min. | Treatment | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| º F(º C) | |||||
| TP304L | 1900 (1040) | Solution | 25(170) | 70(485) | 35 |
Equivalent material of ASTM A249 TP304L Tube
| Grade | Unified Numbering System | Old British | Euronorm | Swedish SS | Japanese Industrial Standards | GOST | ||
| British Standards | European Standards | No | Name | |||||
| 304L | S30403 | 304S31 | 58E | 1.4306 / 1.4307 | X5CrNi18-10 | 2332 | SUS 304L | 03Х18Н11 |
Physical Properties of UNS S30403 SA 249 Tubes
| Grade | Elastic Modulus (GPa) | Density (kg/m3) | Thermal Conductivity (W/m.K) | Electrical Resistivity (n.m) | Mean Coefficient of Thermal Expansion (m/m/0C) | Specific Heat 0-1000C (J/kg.K) | |||
| at 1000C | at 5000C | 0-1000C | 0-3150C | 0-5380C | |||||
| 304L | 193 | 8000 | 16.2 | 21.5 | 720 | 17.2 | 17.8 | 18.4 | 500 |
