ASTM 249 grade covers standard specification of welded austenitic steel boiler, condenser tubes, heat exchanger, and boiler vessels. The ASTM 249 Tube is designed with a chemical content of nickel, chromium, and molybdenum with other constituent alloys. This gives these tubes enhanced resistance to corrosive and oxidative media. ASTM A249 Tubing exhibits superior strength and torsion giving them excellent strength across different applications. The tubes can be furnished in heat-treated conditions keeping in mind the temperature of the solution and quenching method. The ASTM A249 Stainless Tube works well in elevated temperature setups where ordinary metal grades would deteriorate or falter under such pressures.
The tubes in the A249 grade are produced in seamless, welded, and erw configurations. The ASME SA249 Stainless Steel Seamless Tubing is utilized in high pressure and temperature applications as it shows no welds or seams on its surface. This is achieved by passing hot steel billets through the extruded metal giving these tubes excellent strength and the best load-bearing capacity compared to other types of tubes in this range. ASTM A249 Stainless Steel Welded Tubes, on the contrary, is a versatile grade produced by rolling sheets or strips followed by welding them in different procedures. These tubes may not be strong as seamless types but are cheaper than the latter. The A249 ERW Tubes are produced by passing high voltage current through metal to weld them in place longitudinally. These tubes usually don’t require filler metal to be welded in place. ASTM A249 Stainless Steel ERW Tubes are extremely strong and durable as there is no requirement for a fusion of metals in this grade. The weld seam on these tubes is not clearly visible and is seen as in welded tubes. For any queries and questions about our products or their pricing point, contact us for more information.
Table of Content
Specification | ASTM A249 / ASME SA249 Tube |
Shapes | Hydraulic, Round, Rectangular, Honed Tubes, Square, Straight, U Shape, Coiled, Pan Cake Coils |
Surface Finish | 400G, BA, 2B, Mirror Polished, No.8, No.1, 500G, No.4, No.3, 8K, 2D, 1D, 180G, 320G, HL, 400G Satin/ Hairline, 600G or 800G Mirror finish Tubing or Custom Finish as per customer's specification |
Manufacturing Type | CDS / CDW / Fabricated / Seamless / ERW / DOM / CEW / Welded / 100% X Ray Welded |
Thickness Range | SCH XXS, SCH 40, SCH 10, SCH 5, SCH XXH, SCH XS, SCH 80S, SCH 160, SCH 80 |
Standard | JIS, ASTM, GB, DIN, AISI, EN, SUS |
Technique | Cold drawn, Extrusion, Cold rolled, Hot rolled Tube |
Delivery Condition | Annealed and Pickled (AP), Polished, Cold Drawn, MF, Bright Annealed (BA) |
End | Treaded, Beveled End, Plain End |
Processing Service | Bending, Cutting, Decoiling, Welding, Punching, Moulding |
Per Kg
ASME SA249 4 inch sch10 welded tube stainless steel pipe
$ 19.32
Per Kg
ASME SA249 20mm Diameter Seamless Stainless Steel Clad Pipe
$ 10.35
Per Kg
welded Steel Pipe Tube ASME SA249 GR.B SCH 40 black
$ 4.65
ASTM 249 Tube
ASME SA249 Stainless Steel Seamless Tubing
A249 ERW Tubes
ASTM A249 Stainless Steel Welded Tubes
Ss ASME SA 249 M Tubing
ASME SA249 Seamless Tubing
SA249 Stainless Steel ERW Tubes
ASTM A249 M Tubing
A249 Stainless Steel Tube
Grade | Carbon | Manganese | Phosphorus | Sulfur | Silicon | Chromium | Nickel | Molybdenum |
TP304 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | |
TP304L | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | |
TP316 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 |
TP316L | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
Material | Tensile Strength | Heat | Temperure | Yield Strength | Elongation |
Ksi (MPa), Min. | Treatment | Min. | Ksi (MPa), Min. | ||
º F(º C) | |||||
TP304 | 75(515) | Solution | 1900 (1040) | 30(205) | 35 |
TP304L | 70(485) | Solution | 1900 (1040) | 25(170) | 35 |
TP316 | 75(515) | Solution | 1900(1040) | 30(205) | 35 |
TP316L | 70(485) | Solution | 1900(1040) | 25(170) | 35 |
EN-standard | EN Standard | SAE Grade | Unified Numbering System |
X2CrNi18-9 | 1.4307 | 304L | S3043 |
X2CrNi19-11 | 1.4306 | 304L | S30403 |
X2CrNiN18-10 | 1.4311 | 304LN | S30453 |
X5CrNi18-10 | 1.4301 | 304 | S30400 |
X6CrNi18-11 | 1.4948 | 304H | S30409 |
X22CrNi2520 | 1.4841 | 310 | S31000 |
X 5 CrNi 2520 | 1.4845 | 310S | S31008 |
X6CrNiTi18-10 | 1.4541 | 321 | S32100 |
X12CrNiTi18-9 | 1.4878 | 321H | S32109 |
X2CrNiMo17-12-2 | 1.4404 | 316L | S31603 |
X5CrNiMo17-12-2 | 1.4401 | 316 | S31600 |
X2CrNiMoN17-12-2 | 1.4406 | 316LN | S31653 |
X2CrNiMo17-12-3 | 1.4432 | 316L | S31603 |
X2CrNiMo18-14-3 | 1.4435 | 316L | S31603 |
X3CrNiMo17-13-3 | 1.4436 | 316 | S31600 |
X6CrNiMoTi17-12-2 | 1.4571 | 316Ti | S31635 |
X2CrNiMoN17-13-3 | 1.4429 | 316LN | S31653 |
Outer Diameter in Inch | Weight per meter | Wall Thickness in MM | Outer Diameter in Inch | Weight meter | Wall Thickness in mm |
---|---|---|---|---|---|
1/2 | 0.42 | 1.50 | 1 1/4 | 1.13 | 1.50 |
5/8 | 0.44 | 1.20 | 1 3/8 | 1.02 | 1.20 |
5/8 | 0.54 | 1.50 | 1 1/2 | 1.11 | 1.20 |
3/4 | 0.53 | 1.20 | 1 1/2 | 1.38 | 1.50 |
3/4 | 0.66 | 1.50 | 1 1/2 | 1.81 | 2.00 |
3/4 | 0.63 | 1.20 | 1 3/4 | 1.62 | 1.50 |
7/8 | 0.78 | 1.50 | 2 | 1.49 | 1.20 |
7/8 | 1.01 | 2.00 | 2 | 1.85 | 1.50 |
1 | 0.73 | 1.20 | 2 | 2.40 | 2.00 |
1 | 0.90 | 1.50 | 2 1/2 | 2.34 | 1.50 |
1 | 1.17 | 2.00 | 3 | 2.81 | 1.50 |
1 1/8 | 1.02 | 1.50 | 4 | 7.41 | 3.00 |
1 1/4 | 0.92 | 1.20 |
Outer Diameter Size Inches |
Tolerances, Inches | ||
Outer Diameter in Inches |
Wall Thickness | Cut Length (a), In. |
|
Less than 1 | ±0.004 | All Sizes ± 10% |
+1/8–0 |
1 to 1-1/2 | ±0.006 | ||
Over 1-1/2 to 2 | ±0.008 | ||
Over 2 to 2-1/2 | ±0.010 | +3/16–0 | |
Over 2-1/2 to 3 | ±0.012 | ||
Over 3 to 4 | ±0.015 | ||
Over 4 to 5 | +0.015– 0.025 |
