ASTM A269 TP316L Tube
SA269 Grade 316L Welded Tubes and A269 Type 316L ERW Tubing Supplier in India
ASTM A269 Tp316L is a grade of seamless and welded austenitic steel with nominal wall thickness that is designed with 316 austenitic stainless steel. The ASTM A269 TP316L Tube is composed of an outstanding content of chromium, nickel, and molybdenum. The content embedded with these modules gives them excellent corrosion and oxidation resistance properties. ASTM A269 TP316l Stainless Steel Exhaust Tube is designed with high strength and protects the module in high pressure and temperature setting across stress-induced setups. Our institution believes in quality over anything and ensures we supply the best products across all our outlets.
The ASME SA 269 TP316L Seamless Tube is produced as hot steel billets are passed through extruded metal grades to precisely shape the material in the correct dimensions. These robust tubes have outstanding load-bearing capacity and strength as they don’t possess any welds or seams on the surface of this tube. The alternative to these tubes is the cost-effective SA269 Grade 316L Welded Tubes. The versatile tubes are designed by welding pieces of sheets or strips after they are rolled in place. These tubes are cheaper than standard seamless tubes and are very reliable. The ASTM A269 316L Welded Austenitic Steel Tubing is a low-carbon grade that is resistant to sensitization. This helps the tubes to be easily welded in place without the need for post-weld treatment. A269 Type 316L ERW Tubing is a unique module that is produced after a high voltage electric current is passed through the metal to weld it longitudinally. This tubing doesn’t require any filler material to function normally. If you have any questions or queries about our products or their pricing, contact us or visit any of our outlets for more information.
Buy ASME SA 269 TP316L Seamless Tube and ASTM A269 316L Welded Austenitic Steel Tubing in various size and wall thickness at factory price
Table of Content
- Specification of ASTM A269 TP316L Tube
- ASME SA269 Grade 316L Welded Tubes Price
- A269 316L Stainless Steel Welded Tube Types
- ASTM A269 Grade 316L Tubes Dimension Tolerance
- SS SA 269 UNS S31603 Seamless Tubing Pressure Rating
- Chemical Composition of SA 269 316L SS Welded Tubes
- ASTM A269 Austenitic Stainless Steel Tubes Mechanical Properties
- ASTM A269 TP316L Tube Equivalent
Specification of ASTM A269 TP316L Tube
| Specification | ASTM A269 TP316L/ ASME SA269 TP316L Tube |
| Shapes | Hydraulic, Rectangular, Round, Honed Tubes, Square, Straight, U Shape, Coiled, Pan Cake Coils |
| Surface Finish | 400G, BA, 2B, No.8, No.1, No.4, No.3, 500G, 8K, 2D, 1D, 180G, 320G, HL, 400G Satin/ Hairline, Mirror Polished, 600G or 800G Mirror finish Tubing or Custom Finish as per customer's specification |
| Manufacturing Type | CDS / Fabricated / Seamless / CDW / ERW / DOM / CEW / Welded / 100% X Ray Welded |
| Thickness Range | SCH XXS, SCH 10, SCH 5, SCH 40, SCH XXH, SCH XS, SCH 80S, SCH 160, SCH 80 |
| Standard | ASTM, GB, DIN, JIS, AISI, EN, SUS |
| Technique | Cold drawn, Cold rolled, Extrusion, Hot rolled Tube |
| Delivery Condition | Polished, Cold Drawn, Annealed and Pickled (AP), MF, Bright Annealed (BA) |
| End | Beveled End, Treaded, Plain End |
| Processing Service | Cutting, Decoiling, Bending, Welding, Punching, Moulding |
ASME SA269 Grade 316L Welded Tubes Price
Searching for ASTM A269 TP316L Tube manufacturers in India? Exporter of SS SA 269 UNS S31603 Seamless Tubing and A269 316L Stainless Steel Welded Tube at highly competitive prices
Per Kg
ASME SA269 Tp316L 19.05X2X6100mm Stainless Steel Seamless Tube
$ 17.56
Per Kg
ASTM A269 TP316L Capillary Stainless Steel Coil Tubing
$ 3.10
Per Kg
ASME SA269 TP316L 320g Polished 3/8" (9.53) * 0.89 * 6000mm Tube
$ 10.33
A269 316L Stainless Steel Welded Tube Types
ASTM A269 TP316L Tube
SA269 Grade 316L Welded Tubes
A269 Type 316L ERW Tubing
ASME SA 269 TP316L Seamless Tube
SA 269 UNS S31603 Seamless Tubing
ASTM A269 TP316l Stainless Steel Exhaust Tube
ASTM A269 Grade 316L Tubes Dimension Tolerance
| Nominal wall | Outer Diameter Size | Wall Thickness | Outside Diameter | Length |
| 0.065 (1.65) | 3/4 (19.1) | +/-10% | +/-0.005 (0.13) | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 1 (25.4) | +/-10% | +/-0.005 (0.13) | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 1-1/2 (38.1) | +/-10% | +/-0.008 (0.20) | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 2-1/2 (63.5) | +/-10% | +/-0.010 (0.25) | +1/8 (3.18)/-0 |
| 0.083 (2.11) | 4 (101.6) | +/-10% | +/-0.015 (0.38) | +1/8 (3.18)/-0 |
| 0.109 (2.77) | 6 (152.4) | +/-10% | +/-0.030 (0.76) | +3/16 (4.76)/-0 |
| 0.065 (1.65) | 1/2 (12.7) | +/-10% | +/-0.005 (0.13) | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 2 (50.8) | +/-10% | +/-0.008 (0.20) | +1/8 (3.18)/-0 |
| 0.065 (1.65) | 3 (76.2) | +/-10% | +/-0.010 (0.25) | +1/8 (3.18)/-0 |
| 0.109 (2.77) | 8 (203.2) | +/-10% | +/-0.030 (0.76) | +3/16 (4.76)/-0 |
SS SA 269 UNS S31603 Seamless Tubing Pressure Rating
We can supply SA 269 316L SS Welded Tubes, ASTM A269 TP316l Stainless Steel Exhaust Tube and A269 Grade 316L Tubes in custom length
| Wall Thickness in inches | Outer Diameter in Inch | Minimum Tensile Strength (PSI) | Minimum Yield Strength (PSI) | Working Pressure | Theoretical Burst Pressure | Theoretical Yield Point | Collapse Pressure |
|---|---|---|---|---|---|---|---|
| 0.020 | 0.250 | 75,000 | 30,000 | 3,571 | 14,286 | 5,714 | 4,416 |
| 0.028 | 0.250 | 75,000 | 30,000 | 5,412 | 21,649 | 8,660 | 5,967 |
| 0.035 | 0.250 | 75,000 | 30,000 | 7,292 | 29,167 | 11,667 | 7,224 |
| 0.049 | 0.250 | 75,000 | 30,000 | 12,089 | 48,355 | 19,342 | 9,455 |
| 0.065 | 0.250 | 75,000 | 30,000 | 20,313 | 81,250 | 32,500 | 11,544 |
| 0.020 | 0.375 | 75,000 | 30,000 | 2,239 | 8,955 | 3,582 | 3,029 |
| 0.028 | 0.375 | 75,000 | 30,000 | 3,292 | 13,166 | 5,266 | 4,145 |
| 0.035 | 0.375 | 75,000 | 30,000 | 4,303 | 17,213 | 6,885 | 5,077 |
| 0.049 | 0.375 | 75,000 | 30,000 | 6,634 | 26,534 | 10,614 | 6,816 |
| 0.065 | 0.375 | 75,000 | 30,000 | 9,949 | 39,796 | 15,918 | 8,597 |
| 0.020 | 0.500 | 75,000 | 30,000 | 1,630 | 6,522 | 2,609 | 2,304 |
| 0.028 | 0.500 | 75,000 | 30,000 | 2,365 | 9,459 | 3,784 | 3,172 |
| 0.035 | 0.500 | 75,000 | 30,000 | 3,052 | 12,209 | 4,884 | 3,906 |
| 0.049 | 0.500 | 75,000 | 30,000 | 4,571 | 18,284 | 7,313 | 5,304 |
| 0.065 | 0.500 | 75,000 | 30,000 | 6,588 | 26,351 | 10,541 | 6,786 |
| 0.083 | 0.500 | 75,000 | 30,000 | 9,319 | 37,275 | 14,910 | 8,307 |
| 0.020 | 0.625 | 75,000 | 30,000 | 1,282 | 5,128 | 2,051 | 1,859 |
| 0.028 | 0.625 | 75,000 | 30,000 | 1,845 | 7,381 | 2,953 | 2,568 |
| 0.035 | 0.625 | 75,000 | 30,000 | 2,365 | 9,459 | 3,784 | 3,172 |
| 0.049 | 0.625 | 75,000 | 30,000 | 3,487 | 13,947 | 5,579 | 4,335 |
| 0.065 | 0.625 | 75,000 | 30,000 | 4,924 | 19,697 | 7,879 | 5,591 |
| 0.083 | 0.625 | 75,000 | 30,000 | 6,781 | 27,124 | 10,850 | 6,910 |
| 0.095 | 0.625 | 75,000 | 30,000 | 8,190 | 32,759 | 13,103 | 7,734 |
| 0.109 | 0.625 | 75,000 | 30,000 | 10,043 | 40,172 | 16,069 | 8,639 |
| 0.028 | 0.750 | 75,000 | 30,000 | 1,513 | 6,052 | 2,421 | 2,156 |
| 0.035 | 0.750 | 75,000 | 30,000 | 1,930 | 7,721 | 3,088 | 2,669 |
| 0.049 | 0.750 | 75,000 | 30,000 | 2,818 | 11,273 | 4,509 | 3,664 |
| 0.065 | 0.750 | 75,000 | 30,000 | 3,931 | 15,726 | 6,290 | 4,749 |
| 0.083 | 0.750 | 75,000 | 30,000 | 5,330 | 21,318 | 8,527 | 5,905 |
| 0.095 | 0.750 | 75,000 | 30,000 | 6,362 | 25,446 | 10,179 | 6,637 |
| 0.109 | 0.750 | 75,000 | 30,000 | 7,683 | 30,733 | 12,293 | 7,453 |
| 0.120 | 0.750 | 75,000 | 30,000 | 8,824 | 35,294 | 14,118 | 8,064 |
| 0.020 | 0.875 | 75,000 | 30,000 | 898 | 3,593 | 1,437 | 1,340 |
| 0.028 | 0.875 | 75,000 | 30,000 | 1,282 | 5,128 | 2,051 | 1,859 |
| 0.035 | 0.875 | 75,000 | 30,000 | 1,630 | 6,522 | 2,609 | 2,304 |
| 0.049 | 0.875 | 75,000 | 30,000 | 2,365 | 9,459 | 3,784 | 3,172 |
| 0.065 | 0.875 | 75,000 | 30,000 | 3,272 | 13,087 | 5,235 | 4,126 |
| 0.083 | 0.875 | 75,000 | 30,000 | 4,390 | 17,560 | 7,024 | 5,152 |
| 0.095 | 0.875 | 75,000 | 30,000 | 5,201 | 20,803 | 8,321 | 5,807 |
| 0.109 | 0.875 | 75,000 | 30,000 | 6,221 | 24,886 | 9,954 | 6,543 |
| 0.120 | 0.875 | 75,000 | 30,000 | 7,087 | 28,346 | 11,339 | 7,100 |
| 0.028 | 1.000 | 75,000 | 30,000 | 1,112 | 4,449 | 1,780 | 1,633 |
| 0.035 | 1.000 | 75,000 | 30,000 | 1,411 | 5,645 | 2,258 | 2,027 |
| 0.049 | 1.000 | 75,000 | 30,000 | 2,037 | 8,149 | 3,259 | 2,796 |
| 0.065 | 1.000 | 75,000 | 30,000 | 2,802 | 11,207 | 4,483 | 3,647 |
| 0.083 | 1.000 | 75,000 | 30,000 | 3,732 | 14,928 | 5,971 | 4,567 |
| 0.095 | 1.000 | 75,000 | 30,000 | 4,398 | 17,593 | 7,037 | 5,159 |
| 0.109 | 1.000 | 75,000 | 30,000 | 5,227 | 20,908 | 8,363 | 5,827 |
| 0.120 | 1.000 | 75,000 | 30,000 | 5,921 | 23,684 | 9,474 | 6,336 |
| 0.134 | 1.000 | 75,000 | 30,000 | 6,865 | 27,459 | 10,984 | 6,963 |
| 0.035 | 1.250 | 75,000 | 30,000 | 1,112 | 4,449 | 1,780 | 1,633 |
| 0.049 | 1.250 | 75,000 | 30,000 | 1,595 | 6,380 | 2,552 | 2,260 |
| 0.065 | 1.250 | 75,000 | 30,000 | 2,176 | 8,705 | 3,482 | 2,958 |
| 0.083 | 1.250 | 75,000 | 30,000 | 2,871 | 11,485 | 4,594 | 3,719 |
| 0.095 | 1.250 | 75,000 | 30,000 | 3,361 | 13,443 | 5,377 | 4,213 |
| 0.109 | 1.250 | 75,000 | 30,000 | 3,961 | 15,843 | 6,337 | 4,776 |
| 0.120 | 1.250 | 75,000 | 30,000 | 4,455 | 17,822 | 7,129 | 5,207 |
| 0.134 | 1.250 | 75,000 | 30,000 | 5,117 | 20,468 | 8,187 | 5,742 |
| 0.035 | 1.500 | 75,000 | 30,000 | 918 | 3,671 | 1,469 | 1,367 |
| 0.049 | 1.500 | 75,000 | 30,000 | 1,311 | 5,243 | 2,097 | 1,896 |
| 0.065 | 1.500 | 75,000 | 30,000 | 1,779 | 7,117 | 2,847 | 2,487 |
| 0.083 | 1.500 | 75,000 | 30,000 | 2,333 | 9,333 | 3,733 | 3,136 |
| 0.095 | 1.500 | 75,000 | 30,000 | 2,719 | 10,878 | 4,351 | 3,559 |
| 0.109 | 1.500 | 75,000 | 30,000 | 3,188 | 12,754 | 5,101 | 4,043 |
| 0.120 | 1.500 | 75,000 | 30,000 | 3,571 | 14,286 | 5,714 | 4,416 |
| 0.134 | 1.500 | 75,000 | 30,000 | 4,079 | 16,315 | 6,526 | 4,881 |
| 0.148 | 1.500 | 75,000 | 30,000 | 4,610 | 18,439 | 7,375 | 5,336 |
| 0.035 | 1.750 | 75,000 | 30,000 | 781 | 3,125 | 1,250 | 1,176 |
| 0.049 | 1.750 | 75,000 | 30,000 | 966 | 3,864 | 1,546 | 1,434 |
| 0.065 | 1.750 | 75,000 | 30,000 | 1,505 | 6,019 | 2,407 | 2,146 |
| 0.083 | 1.750 | 75,000 | 30,000 | 1,965 | 7,860 | 3,144 | 2,711 |
| 0.095 | 1.750 | 75,000 | 30,000 | 2,284 | 9,135 | 3,654 | 3,080 |
| 0.109 | 1.750 | 75,000 | 30,000 | 2,668 | 10,672 | 4,270 | 3,504 |
| 0.120 | 1.750 | 75,000 | 30,000 | 2,980 | 11,921 | 4,768 | 3,832 |
| 0.134 | 1.750 | 75,000 | 30,000 | 3,391 | 13,563 | 5,425 | 4,242 |
| 0.148 | 1.750 | 75,000 | 30,000 | 3,817 | 15,268 | 6,107 | 4,645 |
| 0.165 | 1.750 | 75,000 | 30,000 | 4,357 | 17,430 | 6,972 | 5,124 |
| 0.035 | 2.000 | 75,000 | 30,000 | 680 | 2,720 | 1,088 | 1,032 |
| 0.049 | 2.000 | 75,000 | 30,000 | 966 | 3,864 | 1,546 | 1,434 |
| 0.065 | 2.000 | 75,000 | 30,000 | 1,303 | 5,214 | 2,086 | 1,887 |
| 0.083 | 2.000 | 75,000 | 30,000 | 1,697 | 6,788 | 2,715 | 2,387 |
| 0.095 | 2.000 | 75,000 | 30,000 | 1,968 | 7,873 | 3,149 | 2,715 |
| 0.109 | 2.000 | 75,000 | 30,000 | 2,294 | 9,175 | 3,670 | 3,092 |
| 0.120 | 2.000 | 75,000 | 30,000 | 2,557 | 10,227 | 4,091 | 3,384 |
| 0.134 | 2.000 | 75,000 | 30,000 | 2,901 | 11,605 | 4,642 | 3,751 |
| 0.148 | 2.000 | 75,000 | 30,000 | 3,257 | 13,028 | 5,211 | 4,111 |
| 0.165 | 2.000 | 75,000 | 30,000 | 3,705 | 14,820 | 5,928 | 4,542 |
Chemical Composition of SA 269 316L SS Welded Tubes
| Grade | Carbon | Manganese | Phosphorus | Silicon | Sulfur | Molybdenum | Chromium | Nickel | Nitrogen | |
|---|---|---|---|---|---|---|---|---|---|---|
| 316L | Minimum | 2.00 | 16.0 | 10.0 | ||||||
| Maximum | 0.03 | 2.0 | 0.045 | 0.75 | 0.03 | 3.00 | 18.0 | 14.0 | 0.10 |
ASTM A269 Austenitic Stainless Steel Tubes Mechanical Properties
Wide stock of ASTM A269 Austenitic Stainless Steel Tubes in Mumbai, India, free sample available, Contact now latest price list
| Grade | Tensile Str (Mpa) Min |
Yield Str (Mpa) Min |
Elongation | Hardness | |
|---|---|---|---|---|---|
| ROCKWELL B (HR B) MAX | BRINELL (HB) MAX | ||||
| 316L | 485 | 170 | 40 | 95 | 217 |
ASTM A269 TP316L Tube Equivalent
| Grade | Unified Numbering System | EURONORM | OLD BRITISH | SWEDISH SS |
Japanese Industrial Standards | ||
|---|---|---|---|---|---|---|---|
| NO | NAME | British Standards | European Standards | ||||
| 316L | S31603 | 1.4404 | X2CrNiMo17-12-2 | 316S11 | 2348 | SUS 316L | |
