ASTM A269 grade covers seamless and welded austenitic steel with nominal wall thickness. The ASTM A269 Tubing has a good chemical composition and is utilized in applications in low or high temperature systems that are susceptible to general corrosion. They cover items of different material types and wall thicknesses. ASTM A269 Stainless Steel Tube is a high-strength component that has excellent resistance to pitting and crevice corrosion that is generally seen in 300 grade steel. The versatile ASME SA269 Tube is a pressurized vessel grade that is a common feature across high-temperature applications. The tubes in this grade are very robust and don’t easily disorientate or get damaged by high pressures.
The ASME SA269 Seamless Stainless Steel Tube is a high-strength grade designed via an extrusion process. Here hot steel billets are passed through the metal, creating a tube without any welds or seams. These unique properties give these modules the capacity to work in high temperatures and have 20% higher load-bearing capacity compared to a welded tube grade. ASTM A269 SS Welded Tube is a cost-effective alternative to the seamless tube. The tubes are produced as strips or sheets are rolled followed by welding them in place using standard welding procedures. Apart from this, they can be shaped in customizable sizes and dimensions that are not possible with seamless tubes. The A269 Stainless Steel Tubing has been subjected to vigorous testing and screening before they are shipped. Our institution's connection with the best supply systems and logistical chains allows us to ship all our products to your doorstep in a short span of time. For any queries or questions about our products or to get a quote on them, contact us or visit any of our outlets for more information.
Specification | ASME A269/ ASME SA269 Tube |
Shapes | Rectangular, Round, Hydraulic, Honed Tubes, Square, "U" Shape, Straight, Coiled, Pan Cake Coils |
Manufacturing Type | Fabricated / Seamless / CDW / ERW / DOM / CEW / CDS / Welded / 100% X Ray Welded |
Delivery Condition | Polished, Annealed and Pickled (AP), Cold Drawn, MF, Bright Annealed (BA) |
Surface Finish | BA, 2B, No.8, No.1, No.3, 500G, 8K, HL, 2D, 1D, 180G, 320G, 400G Satin/ Hairline, No.4, Mirror Polished, 400G, 600G or 800G Mirror finish Tubing or Custom Finish as per customer's specification |
Thickness Range | SCH XXS, SCH XXH, SCH 5, SCH 10, SCH 40, SCH 80S, SCH XS, SCH 160, SCH 80 |
Standard | ASTM, DIN, JIS, GB, AISI, EN, SUS |
END | Beveled End, Plain End, Treaded |
Processing Service | Cutting, Bending, Decoiling, Welding, Punching, Moulding |
Technique | Cold rolled, Cold drawn, Extrusion, Hot rolled Tube |
Packing | Sleeved, Ends Capped, Wooden Boxed |
Per Kg
ASME SA269 25mm 48mm 63mm Stainless Steel Heat Exchanger Tubes
$ 24.28
Per Kg
ASME SA269 Instrument Tubing 1/2 inch OD x 0.035 inch Thickness
$ 67.15
Per Kg
ASME SA269 A249 Small Size Stainless Steel Boiler Tube Piping
$ 16.00
ASTM A269 Tubing
ASME SA269 Tube
ASTM A269 Stainless Steel Tube
ASME SA269 Seamless Tubing
ASTM A269 SS Tubing
ASME SA269 Pipe
Grade | Carbon | Nickel | Manganese | Sulfur | Silicon | Phosphorus | Chromium | Niobium | Molybdenum | Titanium |
---|---|---|---|---|---|---|---|---|---|---|
TP321 | 0.08 | 9.0-12.0 | 2.00 | 0.030 | 1.00 | 0.045 | 17.0-19.0 | 5C -0.70 | ||
TP304 | 0.08 | 8.0-11.0 | 2.00 | 0.030 | 1.00 | 0.045 | 18.0-20.0 | |||
TP316 | 0.08 | 10.0-14.0 | 2.00 | 0.030 | 1.00 | 0.045 | 16.0-18.0 | 2.00-3.00 | ||
TP304L | 0.035 | 8.0-12.0 | 2.00 | 0.030 | 1.00 | 0.045 | 18.0-20.0 | |||
TP316L | 0.035 D | 10.0-15.0 | 2.00 | 0.030 | 1.00 | 0.045 | 16.0-18.0 | 2.00-3.00 | ||
TP347 | 0.08 | 9.0-12.0 | 2.00 | 0.030 | 1.00 | 0.045 | 17.0-19.0 | 10C -1.10 |
Grade | Temperure F (C) | Heat treatment | Hardness | |
---|---|---|---|---|
Brinell | Rockwell | |||
TP304 | 1900 (1040) | Solution | 192HBW/ 200HV | 90HRB |
TP304L | 1900 (1040) | Solution | 192HBW/ 200HV | 90HRB |
TP316 | 1900(1040) | Solution | 192HBW/ 200HV | 90HRB |
TP316L | 1900(1040) | Solution | 192HBW/ 200HV | 90HRB |
TP321 | 1900(1040) F | Solution | 192HBW/ 200HV | 90HRB |
TP347 | 1900(1040) | Solution | 192HBW/ 200HV | 90HRB |
SAE grade | EN-standard Steel name |
UNS | EN-standard |
---|---|---|---|
409 | X6CrTi12 | S40900 | 1.4512 |
410 | S41000 | ||
301 | X10CrNi18-8 | S30100 | 1.4310 |
301LN | X2CrNiN18-7 | 1.4318 | |
304L | X2CrNi18-9 | S3043 | 1.4307 |
316 | G-X 6 CrNiMo 18-10 | S31600 | 1.4408 |
304L | X2CrNi19-11 | S30403 | 1.4306 |
304LN | X2CrNiN18-10 | S30453 | 1.4311 |
310 | X22CrNi2520 | S31000 | 1.4841 |
304 | X5CrNi18-10 | S30400 | 1.4301 |
304H | X6CrNi18-11 | S30409 | 1.4948 |
316LN | X2CrNiMoN17-12-2 | S31653 | 1.4406 |
305 | X5CrNi18-12 | S30500 | 1.4303 |
312 | X5CrNi30-9 | ||
310S | X 5 CrNi 2520 | S31008 | 1.4845 |
321 | X6CrNiTi18-10 | S32100 | 1.4541 |
316 | X3CrNiMo17-13-3 | S31600 | 1.4436 |
321H | X12CrNiTi18-9 | S32109 | 1.4878 |
2304 | X2CrNi23-4 | S32304 | 1.4362 |
316L | X2CrNiMo17-12-2 | S31603 | 1.4404 |
316 | X5CrNiMo17-12-2 | S31600 | 1.4401 |
316L | X2CrNiMo17-12-3 | S31603 | 1.4432 |
316L | X2CrNiMo18-14-3 | S31603 | 1.4435 |
316Ti | X6CrNiMoTi17-12-2 | S31635 | 1.4571 |
316LN | X2CrNiMoN17-13-3 | S31653 | 1.4429 |
317L | X2CrNiMo18-15-4 | S31703 | 1.4438 |
2205 | X2CrNiMoN22-5-3 | S31803/S32205 | 1.4462 |
J405 | X2CrNiMoCuWN25-7-4 | S32760 | 1.4501 |
904L | X1NiCrMoCu25-20-5 | N08904 | 1.4539 |
X1NiCrMoCuN25-20-7 | N08926 | 1.4529 | |
254SMO | X1CrNiMoCuN20-18-7 | S31254 | 1.4547 |
Nominal Pipe Size | Tolerance, % | |
---|---|---|
+ | – | |
≥ 20, seamless, t/D≤ 5% | 22.5 | 12.5 |
3~18, t/D≤ 5% | 22.5 | 12.5 |
≥ 20, seamless, t/D> 5% | 15.0 | 12.5 |
1/8-2 1 /2 | 20.0 | 12.5 |
3~18, t/D> 5% | 15.0 | 12.5 |
≥ 20, welded | 17.5 | 12.5 |
