ASME SA312 Gr 316 Seamless Pipe and A312 Type 316 Welded Pipes Supplier in India


ASTM A312 TP316 Pipe

The A312 TP316 belongs to an austenitic grade of stainless steel alloys. ASTM A312 TP316 is manufactured with a superior composition of nickel, chromium, and molybdenum, allowing them to be used across different industries. The grade exhibits superior resistance to corrosive and oxidative media in the system. The ASME SA 312 TP316 Pipe can work well in elevated temperature and pressure applications. The robust modules don’t deteriorate easily and have enhanced resistance against pitting by acids and crevice corrosion. Our institution's connection with the best supply systems and logistical chains allows us to ship all our products to your doorstep in a short span of time.

The ASME SA312 Gr 316 Seamless Pipe is a pressurized vessel grade that is produced through an extrusion process. In this process, here hot steel billets are passed through the metal to shape them in sizes up to 24 inches. The absence of welds or seams in the ASME SA 312 TP316 Seamless Pipe gives them excellent load-bearing capacity and strength. These pipes work well in high-temperature setups and are very expensive compared to the ASTM A312 TP316 Stainless Steel Welded Pipe. A welded pipe grade is produced as strips or sheets are rolled followed by welding them in place using standard welding procedures. The versatile A312 Type 316 Welded Pipes are preferred in moderate to low temperature and pressure applications. These pipes are designed in sizes between 1/8 to 36 NB and lengths above 24 inches. The A312 Type 316 Erw Pipe is a component that is produced after a high voltage electric current is passed through the metal to weld it longitudinally. This tubing doesn’t require any filler material to function normally. If you have any questions or queries about our products or their pricing, contact us or visit us for more information.

Exporter & supplier of ASTM A312 TP316 Stainless Steel Welded Pipe and ASME SA 312 TP316 Pipe according to ASME B36.19


ASME SA312 Gr 316 Seamless Pipe Specification Chart

Standard Specification ASTM A312 TP316
ASME SA312 TP316
Size ½ to 6 Inch Nominal Bore
Wall Thickness 0.1 - 60 mm
Schedule Pipe Thickness Range Schedule 60, XS, Schedule 160, Schedule 120, STD, Schedule 40, Schedule 140, Schedule 20, Schedule 80, Schedule 80, XXS, Schedule 30, Supplier in Mumbai
Length
  • Single Random Length 5 to 7 Meter
  • Double Random Length 10 - 12 Meter
Types Welded, Seamless, ERW, EFW Supplier and Manufacturer
Manufacturing Shapes Round, Box Section, Square, Rectangle
Standard DIN, JIS, ASTM, GB, ASME, AISI, AMS, EN, GOST
Surface Finish Polished, Bright, Annealing, Cold Finish, Pickling
Technique Cold Rolled
Hot Rolled
Manufacturing Technology Hot
Cold Formed

ASTM A312 TP316 Pipe Price List

Wide range of ASTM A312 TP316 Stainless Steel Round and Square Tubes in Mumbai, best price of SA312 Gr 316 Seamless pipe in India

Trilok Steel Industries

Per Kg

ASTM A312 Tp 316 Stainless Steel Schedule 40 Pipes


$ 12.44

Trilok Steel Industries

Per Kg

ASTM A312 3a 700mm Large Diameter Tp316 Welded Tube

$ 19.71

Trilok Steel Industries

Per Kg

ASTM A312 Tp316 Welded 300mm Stainless Steel Pipes Tube

$ 31.10

Types of A312 Type 316 Welded Pipes

ASME SA312 Gr 316 Seamless Pipes

ASME SA312 Gr 316 Seamless Pipes

A312 Type 316 Welded Pipes

A312 Type 316 Welded Pipes

ASTM A312 TP316 Pipes

ASTM A312 TP316 Pipes

ASTM A312 TP316 Stainless Steel Welded Pipes

ASTM A312 TP316 Stainless Steel Welded Pipes

ASME SA 312 TP316 Pipes

ASME SA 312 TP316 Pipes

ASTM A312 TP316 Stainless Steel Round Tube

ASTM A312 TP316 Stainless Steel Round Tube

ASTM A312 TP316 ERW Pipe

ASTM A312 TP316 ERW Pipe

ASME SA 312 TP316 Semaless Pipe

ASME SA 312 TP316 Semaless Pipe

ASTM A312 Tp 316 stainless steel pipes

ASTM A312 Tp 316 stainless steel pipes

ASTM A312 TP316 Stainless Steel Welded Pipe Pressure Rating

Pipe Size
(inches)
Pipe Schedule 700 300 200 600 100 400 750 500 650
1 80 2528 3265 3634 2659 4213 3002 2501 2791 2580
1 160 3684 4759 5296 3876 6140 4375 3646 4068 3761
1.5 40 1354 1750 1947 1425 2257 1608 1340 1496 1383
1 40 1824 2362 2629 1924 3048 2171 1810 2019 1867
5 80 1189 1535 1709 1250 1981 1411 1176 1312 1213
4 40 919 1187 1321 967 1531 1091 909 1014 938
1.5 80 1909 2466 2744 2009 3182 2267 1889 2108 1949
2 40 1141 1474 1640 1201 1902 1355 1129 1260 1165
5 40 805 1040 1158 847 1342 956 797 889 822
2 80 1648 2129 2369 1734 2747 1957 1631 1820 1682
10 80 966 1247 1388 1016 1609 1147 956 1066 986
2 160 2699 3486 3880 2840 4499 3205 2671 2980 2755
1.5 160 2772 3580 3984 2916 4619 3291 2743 3060 2829
3 40 1084 1400 1558 1140 1806 1287 1072 1196 1106
10 40 584 755 840 615 974 694 578 945 596
3 80 1532 1979 2202 1612 2553 1819 1516 1691 1564
3 160 2304 2976 3312 2424 3840 2736 2280 2544 2352
4 80 1328 1715 1909 1397 2213 1577 1314 1466 1355
8 160 1905 2460 2738 2004 3175 2262 1885 2103 1944
4 160 2161 2791 3106 2273 3601 2566 2138 2386 2206
5 160 2049 2646 2945 2155 3414 2433 2027 2262 2091
6 40 732 945 1052 770 1219 869 724 808 747
6 80 1148 1483 1650 1208 1913 1363 1136 1267 1172
6 160 1973 2549 2836 2076 3289 2343 1953 2179 2014
8 40 644 832 926 678 1073 765 637 711 657
8 80 1015 1311 1459 1068 1692 1205 1005 1121 1036
10 160 1880 2439 2714 1986 3147 2242 1868 2085 1927

ASME SA 312 TP316 Pipe Chemical Composition

Buy ASTM A312 TP316 ERW Pipe at dealer price in Mumbai, we stock high quality material procured from leading ASME SA 312 TP316 Pipe manufacturers in Europe, South Korea and India
Grade Carbon Phosphorus Manganese Sulfur Chromium Nickel Silicon Molybdenum
TP316 0.08 0.045 2 0.03 16.0-18.0 11.0-14.0 1 2.0-3.0

ASTM A312 TP316 ERW Pipe Mechanical Properties

Material Temperure Heat Yield Strength Tensile Strength Elongation
º F(º C) Min. Treatment Ksi (MPa), Min. Ksi (MPa), Min.
ASTM A312 TP316 1900(1040) Solution 30(205) 75(515) 35

Equivalent of ASME SA 312 TP316 Seamless Pipe

Check sizes and schedule chart of ASTM A312 TP316 Stainless Steel Welded Pipe and ASME SA 312 TP316 Seamless Pipe price in India
Werkstoff/ DIN European Standards grades ASTM grades
1.4401X5CrNiMo17-12-2ASTM A 312 Grade TP316

Physical Properties of ASTM A312 Gr Tp316 Pipe

Grade Elastic Modulus (GPa) Density (kg/m3) Thermal Conductivity (W/m.K) Mean Coefficient of Thermal Expansion (m/m/0C) Specific Heat 0-1000C (J/kg.K) Electrical Resistivity (n.m)
at 1000C at 5000C 0-1000C 0-3150C 0-5380C
ASTM A312 TP316 193 8000 16.3 21.5 15.9 16.2 17.5 500 740
