ASTM A312 TP316L Pipe
ASME SA312 Gr 316L Seamless Pipe and A312 Type 316L ERW Pipes Supplier in India
The A312 type TP316L belongs to a low-carbon austenitic grade of stainless steel. The A312 TP316L is produced with a superior composition of nickel, chromium, and molybdenum, allowing them to be used across different industries. This gives the items in this grade superior corrosion and oxidation resistance properties. The grade covers standards seamless, welded, erw, efw, and cold drawn piping components. The ASME SA312 Gr 316L Seamless Pipe is a pressurized vessel component designed for use in high temperature and pressure applications. These pipes are produced as hot steel billets are passed through extruded metal to precisely shape the material in the correct dimensions. This SA312 Grade 316L Seamless Pipe is slightly expensive due to the material used in producing them; however, the grade has outstanding load-bearing capacity and strength as they don’t possess any welds or seams on the surface of these pipes. The ASTM A312 Tp316l Cold Draw Seamless Pipes are manufactured soon after the hot rolling process. Processed at room temperatures, these pipes are run over dies allowing these pipes to have enhanced strength and surface finish when compared to ordinary grade of steel.
The A312 Type 316L ERW Pipe is produced by rolling pieces of sheet or strip and forming a longitudinal seam. In this process, a high-voltage current is passed through the metal to weld it in place without the need for filler material. The ASME SA312 Grade 316L Efw Pipes are produced by passing high-speed beams that allow the conversion of kinetic energy into heat, where the workpiece melts and welds the material in place. Our institution believes in quality over anything and ensures we supply the best products across all our outlets. If you have any questions or queries about our products or their pricing, contact us or visit any of our outlets for more information.
Check ASTM A312 Tp 316l Welded Pipe and ASME SA312 Grade 316L Efw Pipes wall thickness chart, Specification & Schedules
Table of Content
- ASME SA312 Gr 316L Seamless Pipe Specification
- ASTM A312 TP316L Pipe Price List
- Types of A312 Type 316L ERW Pipes
- ASTM A312 Tp 316l Welded Pipe Physical Properties
- ASME SA312 Grade 316L Efw Pipes Chemical Composition
- ASME SA312 Grade 316L Seamless Pipe Mechanical Properties
- Equivalent of ASTM A312 Tp316l Stainless Steel Pipe
- ASME Sa312 Tp 316l Pipe Dimension Tolerance
- Pressure Rating of ASTM A312 Tp316l Cold Draw Seamless Pipes
ASME SA312 Gr 316L Seamless Pipe Specification
Heavy wall thickness ASTM A312 Tp316L Welded Stainless Steel Pipes and ASME SA312 Grade 316L Seamless Pipe according to American National Standards Institute (ANSI)
| Standard Specification | ASTM A312 TP316L ASME SA312 TP316L |
| Size | ½ to 6 Inch Nominal Bore |
| Schedule Pipe Thickness Range | Schedule 60, XS, Schedule 160, Schedule 120, STD, Schedule 40, Schedule 140, Schedule 20, Schedule 80, Schedule 80, XXS, Schedule 30, Supplier in Mumbai |
| Wall Thickness | 0.1 - 60 mm |
| Length |
|
| Standard | DIN, JIS, ASTM, GB, ASME, AISI, AMS, EN, GOST |
| Types | Welded, Seamless, ERW, EFW Supplier and Manufacturer |
| Manufacturing Shapes | Round, Box Section, Square, Rectangle |
| Surface Finish | Polished, Bright, Annealing, Cold Finish, Pickling |
| Technique | Cold Rolled Hot Rolled |
| Manufacturing Technology | Hot Cold Formed |
ASTM A312 TP316L Pipe Price List
Per Kg
ASTM A312 Tp316l Cold Rolled Seamless Stainless Steel Pipes
$ 6.22
Per Kg
1/2-24 Stainless Steel ASTM A312 Tp321 Seamless Steel Pipes
$ 4.15
Per Kg
Aisi 316l 14mm ASTM A312 Tp316l Stainless Steel Pipes
$ 12.44
Types of A312 Type 316L ERW Pipes
ASTM A312 TP316L Pipes
ASME SA312 Gr 316L Seamless Pipes
A312 Type 316L ERW Pipes
ASTM A312 Tp 316l Welded Pipes
ASME SA312 Grade 316L Efw Pipes
ASTM A312 Tp316l Stainless Steel Pipes
ASME SA312 Grade 316L Seamless Pipes
ASTM A312 Tp316l Cold Draw Seamless Pipes
ASTM A312 Tp316l Stainless Steel Square Pipe
ASTM A312 Tp 316l Welded Pipe Physical Properties
| Grade | Thermal Conductivity (W/m.K) | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
| at 1000C | at 5000C | 0-1000C | 0-3150C | 0-5380C | |||||
| ASTM A312 TP316L | 16.3 | 21.5 | 8000 | 193 | 15.9 | 16.2 | 17.5 | 500 | 740 |
ASME SA312 Grade 316L Efw Pipes Chemical Composition
Looking for ASTM A312 Tp316l Stainless Steel Pipe material for High temperature applications? ASME Sa312 Tp 316l Pipe available in 3/4"-24" size range
| Grade | Carbon | Sulfur | Manganese | Phosphorus | Silicon | Nickel | Chromium | Molybdenum |
| ASTM A312 TP316L | 0.035 | 0.03 | 2 | 0.045 | 1 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 |
ASME SA312 Grade 316L Seamless Pipe Mechanical Properties
| Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
| Treatment | º F(º C) Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| ASTM A312 TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
Equivalent of ASTM A312 Tp316l Stainless Steel Pipe
| Grade | Unified Numbering System | Old British | Euronorm | Swedish SS | Japanese Industrial Standards | ||
| British Standards | European Standards | No | Name | ||||
| ASTM A312 TP316L | S31603 | 304S11 | 58E | 1.4436 | X3CrNiMo17-13-3 | 2348 | SUS 316L |
ASME Sa312 Tp 316l Pipe Dimension Tolerance
Befor you buy don't forget to compare our price list with other ASTM A312 Tp316l Cold Draw Seamless Pipes suppliers in Asia
| Nominal wall | Wall Thickness | Outer Diameter Size | Length | Outside Diameter |
| 0.065 (1.65) | +/-10% | 2-1/2 (63.5) | +1/8 (3.18)/-0 | +/-0.010 (0.25) |
| 0.065 (1.65) | +/-10% | 3/4 (19.1) | +1/8 (3.18)/-0 | +/-0.005 (0.13) |
| 0.065 (1.65) | +/-10% | 1 (25.4) | +1/8 (3.18)/-0 | +/-0.005 (0.13) |
| 0.083 (2.11) | +/-10% | 4 (101.6) | +1/8 (3.18)/-0 | +/-0.015 (0.38) |
| 0.065 (1.65) | +/-10% | 1/2 (12.7) | +1/8 (3.18)/-0 | +/-0.005 (0.13) |
| 0.065 (1.65) | +/-10% | 1-1/2 (38.1) | +1/8 (3.18)/-0 | +/-0.008 (0.20) |
| 0.065 (1.65) | +/-10% | 2 (50.8) | +1/8 (3.18)/-0 | +/-0.008 (0.20) |
| 0.065 (1.65) | +/-10% | 3 (76.2) | +1/8 (3.18)/-0 | +/-0.010 (0.25) |
| 0.109 (2.77) | +/-10% | 6 (152.4) | +3/16 (4.76)/-0 | +/-0.030 (0.76) |
| 0.109 (2.77) | +/-10% | 8 (203.2) | +3/16 (4.76)/-0 | +/-0.030 (0.76) |
Pressure Rating of ASTM A312 Tp316l Cold Draw Seamless Pipes
| Outer Diameter in Inch | Wall Thickness in inches | Minimum Tensile Strength (PSI) | Working Pressure | Minimum Yield Strength (PSI) | Theoretical Burst Pressure | Theoretical Yield Point | Collapse Pressure |
|---|---|---|---|---|---|---|---|
| 0.250 | 0.020 | 75,000 | 3,571 | 30,000 | 14,286 | 5,714 | 4,416 |
| 0.250 | 0.028 | 75,000 | 5,412 | 30,000 | 21,649 | 8,660 | 5,967 |
| 0.250 | 0.035 | 75,000 | 7,292 | 30,000 | 29,167 | 11,667 | 7,224 |
| 0.250 | 0.049 | 75,000 | 12,089 | 30,000 | 48,355 | 19,342 | 9,455 |
| 0.250 | 0.065 | 75,000 | 20,313 | 30,000 | 81,250 | 32,500 | 11,544 |
| 0.375 | 0.020 | 75,000 | 2,239 | 30,000 | 8,955 | 3,582 | 3,029 |
| 0.375 | 0.028 | 75,000 | 3,292 | 30,000 | 13,166 | 5,266 | 4,145 |
| 0.375 | 0.035 | 75,000 | 4,303 | 30,000 | 17,213 | 6,885 | 5,077 |
| 0.375 | 0.049 | 75,000 | 6,634 | 30,000 | 26,534 | 10,614 | 6,816 |
| 0.375 | 0.065 | 75,000 | 9,949 | 30,000 | 39,796 | 15,918 | 8,597 |
| 0.500 | 0.020 | 75,000 | 1,630 | 30,000 | 6,522 | 2,609 | 2,304 |
| 0.500 | 0.028 | 75,000 | 2,365 | 30,000 | 9,459 | 3,784 | 3,172 |
| 0.500 | 0.035 | 75,000 | 3,052 | 30,000 | 12,209 | 4,884 | 3,906 |
| 0.500 | 0.049 | 75,000 | 4,571 | 30,000 | 18,284 | 7,313 | 5,304 |
| 0.500 | 0.065 | 75,000 | 6,588 | 30,000 | 26,351 | 10,541 | 6,786 |
| 0.500 | 0.083 | 75,000 | 9,319 | 30,000 | 37,275 | 14,910 | 8,307 |
| 0.625 | 0.020 | 75,000 | 1,282 | 30,000 | 5,128 | 2,051 | 1,859 |
| 0.625 | 0.028 | 75,000 | 1,845 | 30,000 | 7,381 | 2,953 | 2,568 |
| 0.625 | 0.035 | 75,000 | 2,365 | 30,000 | 9,459 | 3,784 | 3,172 |
| 0.625 | 0.049 | 75,000 | 3,487 | 30,000 | 13,947 | 5,579 | 4,335 |
| 0.625 | 0.065 | 75,000 | 4,924 | 30,000 | 19,697 | 7,879 | 5,591 |
| 0.625 | 0.083 | 75,000 | 6,781 | 30,000 | 27,124 | 10,850 | 6,910 |
| 0.625 | 0.095 | 75,000 | 8,190 | 30,000 | 32,759 | 13,103 | 7,734 |
| 0.625 | 0.109 | 75,000 | 10,043 | 30,000 | 40,172 | 16,069 | 8,639 |
| 0.750 | 0.028 | 75,000 | 1,513 | 30,000 | 6,052 | 2,421 | 2,156 |
| 0.750 | 0.035 | 75,000 | 1,930 | 30,000 | 7,721 | 3,088 | 2,669 |
| 0.750 | 0.049 | 75,000 | 2,818 | 30,000 | 11,273 | 4,509 | 3,664 |
| 0.750 | 0.065 | 75,000 | 3,931 | 30,000 | 15,726 | 6,290 | 4,749 |
| 0.750 | 0.083 | 75,000 | 5,330 | 30,000 | 21,318 | 8,527 | 5,905 |
| 0.750 | 0.095 | 75,000 | 6,362 | 30,000 | 25,446 | 10,179 | 6,637 |
| 0.750 | 0.109 | 75,000 | 7,683 | 30,000 | 30,733 | 12,293 | 7,453 |
| 0.750 | 0.120 | 75,000 | 8,824 | 30,000 | 35,294 | 14,118 | 8,064 |
| 0.875 | 0.020 | 75,000 | 898 | 30,000 | 3,593 | 1,437 | 1,340 |
| 0.875 | 0.028 | 75,000 | 1,282 | 30,000 | 5,128 | 2,051 | 1,859 |
| 0.875 | 0.035 | 75,000 | 1,630 | 30,000 | 6,522 | 2,609 | 2,304 |
| 0.875 | 0.049 | 75,000 | 2,365 | 30,000 | 9,459 | 3,784 | 3,172 |
| 0.875 | 0.065 | 75,000 | 3,272 | 30,000 | 13,087 | 5,235 | 4,126 |
| 0.875 | 0.083 | 75,000 | 4,390 | 30,000 | 17,560 | 7,024 | 5,152 |
| 0.875 | 0.095 | 75,000 | 5,201 | 30,000 | 20,803 | 8,321 | 5,807 |
| 0.875 | 0.109 | 75,000 | 6,221 | 30,000 | 24,886 | 9,954 | 6,543 |
| 0.875 | 0.120 | 75,000 | 7,087 | 30,000 | 28,346 | 11,339 | 7,100 |
| 1.000 | 0.028 | 75,000 | 1,112 | 30,000 | 4,449 | 1,780 | 1,633 |
| 1.000 | 0.035 | 75,000 | 1,411 | 30,000 | 5,645 | 2,258 | 2,027 |
| 1.000 | 0.049 | 75,000 | 2,037 | 30,000 | 8,149 | 3,259 | 2,796 |
| 1.000 | 0.065 | 75,000 | 2,802 | 30,000 | 11,207 | 4,483 | 3,647 |
| 1.000 | 0.083 | 75,000 | 3,732 | 30,000 | 14,928 | 5,971 | 4,567 |
| 1.000 | 0.095 | 75,000 | 4,398 | 30,000 | 17,593 | 7,037 | 5,159 |
| 1.000 | 0.109 | 75,000 | 5,227 | 30,000 | 20,908 | 8,363 | 5,827 |
| 1.000 | 0.120 | 75,000 | 5,921 | 30,000 | 23,684 | 9,474 | 6,336 |
| 1.000 | 0.134 | 75,000 | 6,865 | 30,000 | 27,459 | 10,984 | 6,963 |
| 1.250 | 0.035 | 75,000 | 1,112 | 30,000 | 4,449 | 1,780 | 1,633 |
| 1.250 | 0.049 | 75,000 | 1,595 | 30,000 | 6,380 | 2,552 | 2,260 |
| 1.250 | 0.065 | 75,000 | 2,176 | 30,000 | 8,705 | 3,482 | 2,958 |
| 1.250 | 0.083 | 75,000 | 2,871 | 30,000 | 11,485 | 4,594 | 3,719 |
| 1.250 | 0.095 | 75,000 | 3,361 | 30,000 | 13,443 | 5,377 | 4,213 |
| 1.250 | 0.109 | 75,000 | 3,961 | 30,000 | 15,843 | 6,337 | 4,776 |
| 1.250 | 0.120 | 75,000 | 4,455 | 30,000 | 17,822 | 7,129 | 5,207 |
| 1.250 | 0.134 | 75,000 | 5,117 | 30,000 | 20,468 | 8,187 | 5,742 |
| 1.500 | 0.035 | 75,000 | 918 | 30,000 | 3,671 | 1,469 | 1,367 |
| 1.500 | 0.049 | 75,000 | 1,311 | 30,000 | 5,243 | 2,097 | 1,896 |
| 1.500 | 0.065 | 75,000 | 1,779 | 30,000 | 7,117 | 2,847 | 2,487 |
| 1.500 | 0.083 | 75,000 | 2,333 | 30,000 | 9,333 | 3,733 | 3,136 |
| 1.500 | 0.095 | 75,000 | 2,719 | 30,000 | 10,878 | 4,351 | 3,559 |
| 1.500 | 0.109 | 75,000 | 3,188 | 30,000 | 12,754 | 5,101 | 4,043 |
| 1.500 | 0.120 | 75,000 | 3,571 | 30,000 | 14,286 | 5,714 | 4,416 |
| 1.500 | 0.134 | 75,000 | 4,079 | 30,000 | 16,315 | 6,526 | 4,881 |
| 1.500 | 0.148 | 75,000 | 4,610 | 30,000 | 18,439 | 7,375 | 5,336 |
| 1.750 | 0.035 | 75,000 | 781 | 30,000 | 3,125 | 1,250 | 1,176 |
| 1.750 | 0.049 | 75,000 | 966 | 30,000 | 3,864 | 1,546 | 1,434 |
| 1.750 | 0.065 | 75,000 | 1,505 | 30,000 | 6,019 | 2,407 | 2,146 |
| 1.750 | 0.083 | 75,000 | 1,965 | 30,000 | 7,860 | 3,144 | 2,711 |
| 1.750 | 0.095 | 75,000 | 2,284 | 30,000 | 9,135 | 3,654 | 3,080 |
| 1.750 | 0.109 | 75,000 | 2,668 | 30,000 | 10,672 | 4,270 | 3,504 |
| 1.750 | 0.120 | 75,000 | 2,980 | 30,000 | 11,921 | 4,768 | 3,832 |
| 1.750 | 0.134 | 75,000 | 3,391 | 30,000 | 13,563 | 5,425 | 4,242 |
| 1.750 | 0.148 | 75,000 | 3,817 | 30,000 | 15,268 | 6,107 | 4,645 |
| 1.750 | 0.165 | 75,000 | 4,357 | 30,000 | 17,430 | 6,972 | 5,124 |
| 2.000 | 0.035 | 75,000 | 680 | 30,000 | 2,720 | 1,088 | 1,032 |
| 2.000 | 0.049 | 75,000 | 966 | 30,000 | 3,864 | 1,546 | 1,434 |
| 2.000 | 0.065 | 75,000 | 1,303 | 30,000 | 5,214 | 2,086 | 1,887 |
| 2.000 | 0.083 | 75,000 | 1,697 | 30,000 | 6,788 | 2,715 | 2,387 |
| 2.000 | 0.095 | 75,000 | 1,968 | 30,000 | 7,873 | 3,149 | 2,715 |
| 2.000 | 0.109 | 75,000 | 2,294 | 30,000 | 9,175 | 3,670 | 3,092 |
| 2.000 | 0.120 | 75,000 | 2,557 | 30,000 | 10,227 | 4,091 | 3,384 |
| 2.000 | 0.134 | 75,000 | 2,901 | 30,000 | 11,605 | 4,642 | 3,751 |
| 2.000 | 0.148 | 75,000 | 3,257 | 30,000 | 13,028 | 5,211 | 4,111 |
| 2.000 | 0.165 | 75,000 | 3,705 | 30,000 | 14,820 | 5,928 | 4,542 |
