ASTM A358 is a standard grade that covers specification of austenitic electric fusion welded stainless steel grade. The ASTM A358 Pipe is designed with an outstanding composition of chromium and nickel. The content embedded in this pipe gives these modules enhanced resistance to corrosive and oxidative media. ASTM A358 EFW Pipes are designated in classes 1, 2, 3, 4, and 5. These pipes are manufactured by passing high-speed beams that allow the conversion of kinetic energy into heat, where the workpiece melts. These pipes can work well in high temperature service and are available in an array of shapes and sizes.
The ASME SA358 Gr 304 Class 1 Seamless Pipe is a pressurized-vessel grade that is designated for use in extremely high temperatures. These pipes have enhanced strength and have an 18/8 chromium and nickel chemical composition. This gives the ASTM A358 grade 304 pipe the ability to work in corrosive and reducing media that is seen across an array of stress-induced setups. These pipes are very robust and can be hot or cold worked to attain desired characteristics. The ASTM A358 TP304L stainless steel pipe is a low carbon version of the 304 grade. These pipes are immune to sensitization and can be readily welded in their correct place using standard welding procedures. The pressurized ASME SA358 GR 316 Seamless Pipe on the contrary has a good content of nickel, chromium, and molybdenum. This allows them to be utilized in environments where the pipes are susceptible to pitting and crevice corrosion due to the build-up of contaminants in the system. SA358 Stainless Welded Pipes offer a good cheap solution to seamless pipes. Their strength is lower but can be availed in sizes above 24 inches or more. For any additional queries or questions about our products, get in touch with us for more.
Table of Content
Standard Specification | ASTM A358 ASME SA358 |
Size | ½ to 6 inch Nominal Bore |
Types | Welded, Seamless, ERW, EFW Supplier and Manufacturer |
Wall Thickness | 0.1 - 60 mm |
Length |
|
Surface Finish | Polished, Bright, Annealing, Cold Finish, Pickling |
Schedule Pipe Thickness Range | Schedule 160, Schedule 60, XS, Schedule 120, Schedule 40, STD, Schedule 140, Schedule 20, Schedule 80, Schedule 80, XXS, Schedule 30, Supplier in Mumbai |
Standard | ASME, DIN, JIS, ASTM, GB, AISI, AMS, EN, GOST |
Manufacturing Shapes | Square, Round, Box Section, Rectangle |
Manufacturing Technology | Hot Cold Formed |
Technique | Cold Rolled Hot Rolled |
Per Kg
ASTM A358 EFW TP316L stainless tube
$ 12.44
Per Kg
ASTM A358 TP304/304L EFW CL.1 Stainless Steel Welded Pipe
$ 19.71
Per Kg
8 inch stainless steel pipe ASTM A358 SS 304 EFW Pipes
$ 22.08
ASTM A358 Pipes
ASME SA358 Gr 304 Class 1 Seamless Pipe
ASTM A358 EFW Pipes
SA358 Stainless Welded Pipes
ASME SA358 GR 316 Seamless Pipe
ASTM A358 TP304L stainless steel pipe
SA 358 TP 316L Class 3 Welded Pipes
ASTM A358 grade 304 pipe
ASTM A358 Class 5 Pipe
Grade | Carbon | Sulfur | Manganese | Chromium | Phosphorus | Silicon | Molybdenum | Nickel | Titanium | Niobium | Nitrogen |
---|---|---|---|---|---|---|---|---|---|---|---|
TP304 | 0.08 | 0.030 | 2.0 | 18.0-20.0 | 0.045 | 1.0 | 8.0-11.0 | ||||
TP304L |
0.035 | 0.030 | 2.0 | 18.0-20.0 | 0.045 | 1.0 | 8.0-13.0 | ||||
TP304H |
0.04-0.10 | 0.030 | 2.0 | 18.0-20.0 | 0.045 | 1.0 | 8.0-11.0 | ||||
TP304N |
0.08 | 0.030 | 2.0 | 18.0-20.0 | 0.045 | 1.0 | 8.0-18.0 | 0.10-0.16 | |||
TP304LN |
0.035 | 0.030 | 2.0 | 18.0-20.0 | 0.045 | 1.0 | 8.0-12.0 | 0.10-0.16 | |||
TP309S |
0.08 | 0.030 | 2.0 | 22.0-24.0 | 0.045 | 1.0 | 0.75 | 12.0-15.0 | |||
TP309H |
0.04-0.10 | 0.030 | 2.0 | 22.0-24.0 | 0.045 | 1.0 | 12.0-15.0 | ||||
TP309Cb |
0.08 | 0.030 | 2.0 | 22.0-24.0 | 0.045 | 1.0 | 0.75 | 12.0-16.0 | 10xC min 1.10 max | ||
TP309HCb |
0.04-0.10 | 0.030 | 2.0 | 22.0-24.0 | 0.045 | 1.0 | 0.75 | 12.0-16.0 | 10xC min 1.10 max | ||
TP310S |
0.08 | 0.030 | 2.0 | 24.0-26.0 | 0.045 | 1.0 | 0.75 | 19.0-22.0 | |||
TP310H |
0.04-0.10 | 0.030 | 2.0 | 24.0-26.0 | 0.045 | 1.0 | 19.0-22.0 | ||||
TP310Cb |
0.08 | 0.030 | 2.0 | 24.0-26.0 | 0.045 | 1.0 | 0.75 | 19.0-22.0 | 10xC min 1.10 max | ||
TP310HCb |
0.04-0.10 | 0.030 | 2.0 | 24.0-26.0 | 0.045 | 1.0 | 0.75 | 19.0-22.0 | 10xC min 1.10 max | ||
TP316 |
0.08 | 0.030 | 2.0 | 16.0-18.0 | 0.045 | 1.0 | 2.0-3.0 | 11.0-14.0 | |||
TP316L |
0.035 | 0.030 | 2.0 | 16.0-18.0 | 0.045 | 1.0 | 2.0-3.0 | 10.0-14.0 | |||
TP316H |
0.04-0.10 | 0.030 | 2.0 | 16.0-18.0 | 0.045 | 1.0 | 2.0-3.0 | 11.0-14.0 | |||
TP316Ti |
0.08 | 0.030 | 2.0 | 16.0-18.0 | 0.045 | 0.75 | 2.0-3.0 | 10.0-14.0 | 5x (C-N) -0.70 | 0.10 | |
TP316N |
0.08 | 0.030 | 2.0 | 16.0-18.0 | 0.045 | 1.0 | 2.0-3.0 | 10.0-14.0 | 0.10-0.16 | ||
TP316LN |
0.035 | 0.030 | 2.0 | 16.0-18.0 | 0.045 | 1.0 | 2.0-3.0 | 11.0-14.0 | 0.10-0.16 | ||
TP317 |
0.08 | 0.030 | 2.0 | 18.0-20.0 | 0.045 | 1.0 | 3.0-4.0 | 10.0-14.0 | |||
TP317L |
0.035 | 0.030 | 2.0 | 18.0-20.0 | 0.045 | 1.0 | 3.0-4.0 | 11.0-15.0 | |||
TP321 |
0.08 | 0.030 | 2.0 | 17.0-19.0 | 0.045 | 1.0 | 9.0-12.0 | 0.10 | |||
TP321H |
0.04-0.10 | 0.030 | 2.0 | 17.0-19.0 | 0.045 | 1.0 | 9.0-12.0 | 0.10 | |||
TP347 |
0.08 | 0.030 | 2.0 | 17.0-19.0 | 0.045 | 1.0 | 9.0-13.0 | ||||
TP347H |
0.04-0.10 | 0.030 | 2.0 | 17.0-19.0 | 0.045 | 1.0 | 9.0-13.0 | ||||
TP347LN |
0.05-0.02 | 0.030 | 2.0 | 17.0-19.0 | 0.045 | 1.0 | 9.0-13.0 | 0.20- 50.0 | 0.06-0.10 | ||
TP348 |
0.08 | 0.030 | 2.0 | 17.0-19.0 | 0.045 | 1.0 | 9.0-13.0 | ||||
TP348H |
0.04-0.10 | 0.030 | 2.0 | 17.0-19.0 | 0.045 | 1.0 | 9.0-13.0 |
Grade | Temperure | Heat | Yield Strength | Tensile Strength | Elongation |
Min. | Treatment | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
º F(º C) | |||||
TP304 | 1900 (1040) | Solution | 30(205) | 75(515) | 35 |
TP304L | 1900 (1040) | Solution | 25(170) | 70(485) | 35 |
TP316 | 1900(1040) | Solution | 30(205) | 75(515) | 35 |
TP316L | 1900(1040) | Solution | 25(170) | 70(485) | 35 |
ASTM STANDARD | UNS NO. | GERMAN | ITALIAN | KOREA/JAPANES | FRENCH | BRITISH | ||||||||||
DIN Type | DIN Number | Materiral Number | Remarks | UNI Type | UNI Number | Ramarks | KS/JIS Symbol | KS/JIS Numbe | AFNOR Type | NF Number | Ramarks | B.S Number | B.S Grade | Remarks | ||
Grade 304 | S30400 | X5 CrNi 18 9 | 17440 | 1.4301 | (3b) | X6 CrNi 18 10 | 8317 | (3b) | STS 304TPY/ SUS310STPY | D3588 / G3468 | Z6 CN 18.09 | A36-209 | (3b) | 3605 | 304S25 | LWHT(3b) |
Grade 310 | S31000 | X 12 CrNi 25 21 | 1.4845 | WBL-470(3b) | X22 CrNi 25 20 | 6900 | (3b)(11) | STS 310STPY/ SUS310STPY | D3588 / G3468 | A36-209 | (3) | |||||
Grade 316 | S31600 | X5 CrNiMo 18 10 | 17440 | 1.4401 | (3b) | X6CrNiMo 17 12 | 8317 | (3b) | STS 316TPY / SUS316TPY | D3588 / G3468 | Z6 CND 17.11 | A36-209 | (3b) | 3605 | 316S26 | LWHT(3b) |
Grade 321 | S32100 | X10 CrNiTi 18 9 | 17440 | 1.4541 | (3b)(17) | X6 CrNiTi 18 10 | 8317 | (3b) | STS 321TPY/ SUS 321TPY | D3588 / G3468 | Z6 CNT 18.10 | A36-209 | (3b) | 3605 | 321S22 | LWHT(3b) |
Grade 347 | S34700 | X10 CrNiNb 18 9 | 17440 | 1.4550 | (3b)(17) | X6 CrNiNb 18 10 | 8317 | (3b)#nps | STS 347TPY/ SUS 347TPY | D3588 / G3468 | Z6 CN Nb 18.10 | A36-209 | (3b) | 3605 | 347S17 | LWHT(3b) |
Outside Diameter in. | Nominal Pipe Size | Schedule 80S in. | Schedule 5S in. | Schedule 40S in. | Schedule 10S in. |
---|---|---|---|---|---|
0.540 | 1/4 | 0.119 | 0.088 | 0.065 | |
0.675 | 3/8 | 0.126 | 0.091 | 0.065 | |
0.840 | 1/2 | 0.147 | 0.065 | 0.109 | 0.083 |
1.050 | 3/4 | 0.154 | 0.065 | 0.113 | 0.083 |
1.315 | 1.0 | 0.179 | 0.065 | 0.133 | 0.109 |
1.660 | 1 1/4 | 0.191 | 0.065 | 0.140 | 0.109 |
1.900 | 1 1/2 | 0.200 | 0.065 | 0.145 | 0.109 |
2.375 | 2 | 0.218 | 0.065 | 0.154 | 0.109 |
2.875 | 2 1/2 | 0.276 | 0.083 | 0.203 | 0.120 |
3.500 | 3 | 0.300 | 0.083 | 0.216 | 0.120 |
4.000 | 3 1/2 | 0.318 | 0.083 | 0.226 | 0.120 |
4.500 | 4 | 0.337 | 0.083 | 0.237 | 0.120 |
5.563 | 5 | 0.375 | 0.109 | 0.258 | 0.134 |
6.625 | 6 | 0.432 | 0.109 | 0.280 | 0.134 |
8.625 | 8 | 0.500 | 0.109 | 0.322 | 0.148 |
10.750 | 10 | 0.500 | 0.134 | 0.365 | 0.165 |
12.750 | 12 | 0.500 | 0.156 | 0.375 | 0.180 |
Nominal Pipe Size | Tolerance | |
+ | – | |
≥ 20, welded | 17.5 | 12.5 |
3~18, t/D≤ 5% | 22.5 | 12.5 |
≥ 20, seamless, t/D> 5% | 15.0 | 12.5 |
3~18, t/D> 5% | 15.0 | 12.5 |
1/8-2 1 /2 | 20.0 | 12.5 |
≥ 20, seamless, t/D≤ 5% | 22.5 | 12.5 |
