Electropolishing of stainless steel is a process wherein there is reverse plating takes place, making use of an electrochemical solution to remove the exterior skin of the metal part. The Electropolished Stainless Steel Tubing doesn’t have any contaminants, heat tint, or oxide scales. These tubes have excellent corrosion and oxidation resistance properties in stress-induced environments. Electropolished Stainless Steel Pipe has a superior surface finish, and the roughness is reduced. This allows the pipes to have accurate dimensions and allow them to be used in different sensory systems. The EP Tubing is commonly seen in medical, appliance manufacturing, automation sector, food, beverages, racing equipment, and pharmaceutical equipment. The versatile Electropolished Tube can be custom designed in an area of shapes and sizes to meet all customer satisfaction. The tie-ups of our institution with the best logistical supply chains allow us to transport products to your doorstep within a short frame of time.
The Electropolished Stainless Steel grade is generally designed in standard 304 and 316 configurations. Stainless Steel 304 Electro Tubes are manufactured with a superior chemical composition of nickel and chromium with other constituting alloys. The tubes are cost-effective components due to their widespread usage and supply chain. The 304L Stainless Steel Electropolished Tubes are a low-carbon alternative to the 304 grade and can be welded easily. These tubes have lower resistance to sensitization and intergranular corrosion. SS 316LElectropolished Pipe is manufactured with a superior composition of nickel, chromium, and molybdenum. The low-carbon grade pipes have enhanced resistance to reducing media when compared to the 304 grade tubes. If you want to avail of our products or want to know more about our items or their pricing, visit any of our outlets or contact us for more information.
Table of Content
Standard Specification | ASTM A312 / ASTM SA312 Electropolished Stainless Steel Tubing |
ANSI Specification | ANSI/ASME B36.10M, ANSI/ASME B36.19M |
Pipe End Abbreviations | Treaded Both Ends, Bevel small end, Treaded On End, Beveled One End, Beveled end, Plain Both Ends, Bevel large end, Bevel one end, Plain One End, Bevel both ends |
Available Shapes and Types | Hydraulic, Square, Rectangle, Round, Hex, Honed |
Manufacturing Type | Seamless, Fabricated, CDW, 100% X Ray Welded, Welded, ERW |
Surface Finish | No.1, 2B, No.4, No.8 Mirror Finish |
Various Technical Delivery Conditions Types | Cold Drawn, Annealed and Pickled, Polished, Bright Annealed |
Schedule | SCH 80, SCH 5, SCH10, SCH 160, SCH XXS, SCH 40, SCH 80S, SCH XS, |
Per Kg
Electropolishing Round Polished Ss Tube
$ 10.35
Per Kg
Electropolished 50mm Stainless Steel Tubes
$ 11.43
Per Kg
Electropolished Diameter 1/2 X 0.035 600 Ss Tube
$ 10.35
Electropolished Stainless Steel Tubing
Stainless Steel 304 Electro Tubes
SS 316 EP Tubing
Electropolished 316L ASME BPE SF4 tubing
Electropolished Tube
304L Stainless Steel Electropolished Tubes
Stainless Steel Electropolished Tubes
SS 316L Electropolished Pipe
Electropolished Stainless Steel Pipe
Surface Finish | Exterbal Surface(OD) | Internal Surface(ID) | |||
Roughness Average(RA) | Roughness Average(RA) | ||||
μ inch | μm | μ inch | μm | ||
EP | Electro Polish | 32 | 0.8 | 15,10,7,5 | 0.38,0.25,0.20;0.13 |
BA | Beight Annealed | 32 | 0.8 | 40,32,25,20 | 1.0,0.8,0.6,0.5 |
AP | Annealed & Pickled | 40 or Not defined | 1.0 or Not defined | Not defined | Not defined |
MP | Mechanical Polish | 32 | 0.8 | 40,32,25,20 | 1.0,0.8,0.6,0.5 |
Pipe Size in Inches | Pipe Schedule | 500 | 100 | 300 | 200 | 400 | 600 | 700 | 650 | 750 |
---|---|---|---|---|---|---|---|---|---|---|
4 | 40 | 1014 | 1531 | 1187 | 1321 | 1091 | 967 | 919 | 938 | 909 |
80 | 1466 | 2213 | 1715 | 1909 | 1577 | 1397 | 1328 | 1355 | 1314 | |
160 | 2386 | 3601 | 2791 | 3106 | 2566 | 2273 | 2161 | 2206 | 2138 | |
1 1/2 | 40 | 1496 | 2257 | 1750 | 1947 | 1608 | 1425 | 1354 | 1383 | 1340 |
80 | 2108 | 3182 | 2466 | 2744 | 2267 | 2009 | 1909 | 1949 | 1889 | |
160 | 3060 | 4619 | 3580 | 3984 | 3291 | 2916 | 2772 | 2829 | 2743 | |
2 | 40 | 1260 | 1902 | 1474 | 1640 | 1355 | 1201 | 1141 | 1165 | 1129 |
80 | 1820 | 2747 | 2129 | 2369 | 1957 | 1734 | 1648 | 1682 | 1631 | |
160 | 2980 | 4499 | 3486 | 3880 | 3205 | 2840 | 2699 | 2755 | 2671 | |
8 | 40 | 711 | 1073 | 832 | 926 | 765 | 678 | 644 | 657 | 637 |
80 | 1121 | 1692 | 1311 | 1459 | 1205 | 1068 | 1015 | 1036 | 1005 | |
160 | 2103 | 3175 | 2460 | 2738 | 2262 | 2004 | 1905 | 1944 | 1885 | |
6 | 40 | 808 | 1219 | 945 | 1052 | 869 | 770 | 732 | 747 | 724 |
80 | 1267 | 1913 | 1483 | 1650 | 1363 | 1208 | 1148 | 1172 | 1136 | |
160 | 2179 | 3289 | 2549 | 2836 | 2343 | 2076 | 1973 | 2014 | 1953 | |
1 | 40 | 2019 | 3048 | 2362 | 2629 | 2171 | 1924 | 1824 | 1867 | 1810 |
80 | 2791 | 4213 | 3265 | 3634 | 3002 | 2659 | 2528 | 2580 | 2501 | |
160 | 4068 | 6140 | 4759 | 5296 | 4375 | 3876 | 3684 | 3761 | 3646 | |
3 | 40 | 1196 | 1806 | 1400 | 1558 | 1287 | 1140 | 1084 | 1106 | 1072 |
80 | 1691 | 2553 | 1979 | 2202 | 1819 | 1612 | 1532 | 1564 | 1516 | |
160 | 2544 | 3840 | 2976 | 3312 | 2736 | 2424 | 2304 | 2352 | 2280 | |
5 | 40 | 889 | 1342 | 1040 | 1158 | 956 | 847 | 805 | 822 | 797 |
80 | 1312 | 1981 | 1535 | 1709 | 1411 | 1250 | 1189 | 1213 | 1176 | |
160 | 2262 | 3414 | 2646 | 2945 | 2433 | 2155 | 2049 | 2091 | 2027 | |
10 | 40 | 645 | 974 | 755 | 840 | 694 | 615 | 584 | 596 | 578 |
80 | 1066 | 1609 | 1247 | 1388 | 1147 | 1016 | 966 | 986 | 956 | |
160 | 2085 | 3147 | 2439 | 2714 | 2242 | 1986 | 1880 | 1927 | 1868 |
Gauge | Typical Value in Inch | Thickness Range in Inch |
---|---|---|
12 | 0.109 | 0.101 through 0.111 |
20 | 0.035 | 0.031 through 0.035 |
15 | 0.072 | 0.066 through 0.074 |
10 | 0.134 | 0.126 through 0.136 |
19 | 0.042 | 0.038 through 0.042 |
13 | 0.095 | 0.087 through 0.097 |
22 | 0.028 | 0.025 through 0.029 |
18 | 0.049 | 0.044 through 0.049 |
17 | 0.058 | 0.053 through 0.058 |
9 | 0.148 | 0.140 through 0.150 |
16 | 0.065 | 0.060 through 0.065 |
14 | 0.083 | 0.075 through 0.085 |
11 | 0.12 | 0.112 through 0.122 |
8 | 0.165 | 0.157 through 0.167 |
7 | 0.18 | 0.175 through 0.185 |
Nominal Pipe Size | Permissible Variations in Outside Diameter | |
---|---|---|
Over Inch | Under Inch | |
Over 8 to 18, incl | 3/23 (0.093) | 1/32 (0.031) |
Over 1-1/2 to 4, incl | 1/32 (0.031) | 1/32 (0.031) |
1/8 to 1-1/2, incl | 1/64 (0.015) | 1/32 (0.031) |
Over 4 to 8, incl | 1/16 (0.062) | 1/32 (0.031) |
Nominal Pipe Sizes | Wall Thickness | Outside Diameter | Weight | Weight | |||
Schedule | Inch | MM | Inch | MM | Lbs/feet | kg/Meter | |
3/4 | 40 STD | 0.113 | 2.870 | 1.050 | 27 | 1.131 | 1.684 |
80 STD | 0.154 | 3.912 | 1.474 | 2.195 | |||
1 | 40 STD | 0.133 | 3.378 | 1.315 | 33 | 1.679 | 2.501 |
80 STD | 0.179 | 4.547 | 2.172 | 3.325 | |||
1/2 | 40 STD | 0.109 | 2.769 | 0.840 | 21 | 0.851 | 1.268 |
80 STD | 0.147 | 3.734 | 1.088 | 1.621 | |||
1 1/4 | 40 STD | 0.140 | 3.556 | 1.660 | 42 | 2.273 | 3.385 |
80 STD | 0.191 | 4.851 | 2.997 | 4.464 | |||
1 1/2 | 40 STD | 0.145 | 3.683 | 1.900 | 48 | 2.718 | 4.048 |
80 STD | 0.200 | 5.080 | 3.361 | 5.409 | |||
2 | 40 STD | 0.154 | 3.912 | 2.375 | 60 | 3.653 | 5.441 |
80 STD | 0.218 | 5.537 | 5.022 | 7.480 | |||
3 | 40 STD | 0.216 | 5.486 | 3.500 | 89 | 7.576 | 11.284 |
80 STD | 0.300 | 7.620 | 10.253 | 15.272 | |||
4 | 0.237 | 6.020 | 4.500 | 114 | 10.790 | 16.073 | |
0.337 | 8.560 | 14.983 | 22.318 | ||||
2 1/2 | 40 STD | 0.203 | 5.516 | 2.875 | 73 | 5.793 | 8.629 |
80 STD | 0.276 | 7.010 | 7.661 | 11.411 | |||
6 | 0.188 | 4.775 | 6.625 | 168 | 12.924 | 19.252 | |
0.203 | 5.516 | 13.923 | 20.739 | ||||
0.219 | 5.563 | 14.983 | 22.318 | ||||
0.250 | 6.350 | 17.021 | 25.354 | ||||
40 STD | 0.280 | 7.112 | 18.974 | 58.263 | |||
0.312 | 7.925 | 21.036 | 31.334 | ||||
0.375 | 9.525 | 25.031 | 37.285 | ||||
80 XHY | 0.432 | 10.973 | 28.573 | 42.561 | |||
0.500 | 12.700 | 32.708 | 48.719 | ||||
10 | 0.188 | 4.775 | 10.750 | 273 | 21.207 | 31.588 | |
0.219 | 5.563 | 24.631 | 36.689 | ||||
20 | 0.250 | 6.350 | 28.035 | 41.759 | |||
30 | 0.307 | 7.798 | 34.240 | 51.002 | |||
0.344 | 8.738 | 38.231 | 56.946 | ||||
40 STD | 0.365 | 9.271 | 40.483 | 63.301 | |||
0.438 | 11.125 | 48.238 | 71.852 | ||||
60 XHY | 0.500 | 12.700 | 54.735 | 81.530 | |||
80 | 0.594 | 15.088 | 64.429 | 95.969 | |||
8 | 0.188 | 4.775 | 8.625 | 219 | 16.940 | 25.233 | |
0.203 | 5.156 | 18.259 | 27.198 | ||||
0.219 | 5.563 | 19.661 | 29.286 | ||||
20 | 0.250 | 6.350 | 22.361 | 33.308 | |||
30 | 0.277 | 7.036 | 24.696 | 36.786 | |||
40 | 0.322 | 8.179 | 28.554 | 42.352 | |||
0.375 | 9.525 | 33.041 | 49.216 | ||||
60 | 0.406 | 10.312 | 35.638 | 53.085 | |||
80 XHY | 0.500 | 12.700 | 43.388 | 64.627 | |||
12 | 0.188 | 4.775 | 12.750 | 324 | 25.222 | 37.570 | |
0.219 | 5.563 | 29.309 | 43.657 | ||||
0.250 | 6.350 | 33.375 | 49.713 | ||||
0.281 | 7.137 | 37.420 | 55.739 | ||||
0.312 | 7.925 | 41.445 | 61.735 | ||||
0.375 | 9.525 | 49.562 | 73.824 | ||||
0.406 | 10.312 | 53.525 | 79.727 | ||||
0.500 | 12.700 | 65.415 | 97.438 | ||||
0.562 | 14.275 | 73.154 | 108.966 | ||||
16” | 0.188 | 4.775 | 16.000 | 406 | 21.748 | 47.290 | |
0.219 | 5.563 | 36.910 | 54.980 | ||||
10 | 0.250 | 6.350 | 42.053 | 62.639 | |||
0.281 | 7.137 | 47.174 | 70.268 | ||||
20 | 0.312 | 7.925 | 52.275 | 77.866 | |||
0.344 | 8.738 | 57.519 | 85.677 | ||||
30 STD |
0.375 | 9.525 | 62.578 | 93.213 | |||
0.438 | 11.125 | 72.797 | 108.433 | ||||
40 XHY |
0.500 | 12.700 | 82.770 | 123.289 | |||
14 | 0.188 | 4.775 | 14.000 | 356 | 27.732 | 41.308 | |
0.219 | 5.563 | 32.233 | 48.012 | ||||
20 | 0.250 | 6.350 | 36.713 | 54.685 | |||
0.281 | 7.137 | 41.172 | 61.327 | ||||
0.312 | 7.925 | 45.611 | 67.939 | ||||
STD | 0.375 | 9.525 | 54.568 | 81.281 | |||
40 | 0.438 | 11.125 | 63.441 | 94.498 | |||
XHY | 0.500 | 12.700 | 72.090 | 107.381 | |||
0.625 | 15.875 | 89.278 | 132.983 | ||||
18 | 0.219 | 5.563 | 18.000 | 457 | 41.588 | 61.948 | |
0.250 | 6.350 | 47.393 | 70.593 | ||||
0.281 | 7.137 | 53.176 | 79.208 | ||||
20 | 0.312 | 7.925 | 58.939 | 87.792 | |||
STD | 0.375 | 9.525 | 70.588 | 105.144 | |||
30 | 0.438 | 11.125 | 82.152 | 122.369 | |||
XHY | 0.500 | 12.700 | 93.450 | 139.198 | |||
40 | 0.562 | 14.275 | 104.666 | 155.904 | |||
0.625 | 15.875 | 115.978 | 172.754 | ||||
20 | 0.250 | 6.350 | 20.000 | 508 | 52.733 | 78.547 | |
0.282 | 7.163 | 59.386 | 88.458 | ||||
0.312 | 7.925 | 65.604 | 97.719 | ||||
20 STD | 0.375 | 9.525 | 78.598 | 117.075 | |||
0.438 | 11.125 | 91.508 | 136.305 | ||||
30 XHY | 0.500 | 12.700 | 104.130 | 155.106 | |||
40 | 0.594 | 15.088 | 123.110 | 183.378 | |||
0.625 | 15.875 | 129.328 | 192.640 | ||||
0.688 | 17.475 | 141.901 | 211.368 | ||||
24 | 0.250 | 6.350 | 24.000 | 610 | 63.413 | 94.456 | |
0.281 | 7.137 | 71.183 | 106.029 | ||||
0.312 | 7.925 | 18.932 | 117.573 | ||||
20 STD | 0.375 | 9.525 | 64.618 | 140.938 | |||
0.438 | 11.125 | 110.219 | 164.176 | ||||
XHY | 0.500 | 12.700 | 125.490 | 186.923 | |||
0.625 | 15.875 | 156.028 | 232.410 | ||||
40 | 0.688 | 17.475 | 171.293 | 255.148 | |||
0.750 | 19.050 | 186.233 | 277.401 | ||||
30 | 0.250 | 6.350 | 30.000 | 762 | 79.433 | 118.318 | |
0.281 | 7.137 | 89.189 | 132.851 | ||||
10 | 0.312 | 7.925 | 98.925 | 147.353 | |||
STD | 0.375 | 9.525 | 118.648 | 176.731 | |||
0.438 | 11.125 | 138.286 | 205.983 | ||||
20 XHY | 0.500 | 12.700 | 157.530 | 234.647 | |||
30 | 0.625 | 15.875 | 196.078 | 292.066 | |||
0.688 | 17.475 | 215.380 | 320.817 | ||||
0.750 | 19.050 | 234.293 | 348.988 | ||||
36 | 0.250 | 6.350 | 36.000 | 914 | 95.453 | 142.180 | |
0.281 | 7.137 | 107.196 | 159.672 | ||||
10 | 0.312 | 7.925 | 118.918 | 177.133 | |||
STD | 0.375 | 9.525 | 142.678 | 215.525 | |||
0.438 | 11.125 | 166.353 | 247.790 | ||||
20 XHY | 0.500 | 12.700 | 198.570 | 282.372 | |||
0.625 | 15.875 | 236.128 | 351.723 | ||||
0.688 |
17.475 | 259.467 | 386.487 | ||||
0.750 |
19.050 | 282.353 | 420.576 | ||||
42 | 0.312 | 7.925 | 42.000 | 1067 | 138.911 | 206.914 | |
STD | 0.375 | 9.525 | 166.708 | 248.319 | |||
XHY | 0.500 | 12.700 | 221.610 | 33.097 | |||
0.750 | 19.050 | 330.413 | 492.163 | ||||
48 | STD | 0.375 | 9.525 | 48.000 | 1219 | 190.738 | 284.112 |
0.438 | 11.125 | 222.487 | 331.404 | ||||
XHY | 0.500 | 12.700 | 253.650 | 377.822 | |||
0.750 | 19.050 | 378.473 | 563.750 | ||||
0.875 | 22.225 | 440.383 | 655.969 |
Nominal size in inches | Outside diameter in inches | Outside diameter in mm | Wall thickness in mm | Wall thickness in inches | Weight [kg/meter] | Weight [lbs/feet] |
---|---|---|---|---|---|---|
1/8 6 | 0.41 | 10.3 | 1.73 | 0.068 | 0.37 | 0.24 |
1/4 8 | 0.54 | 13.7 | 2.24 | 0.088 | 0.63 | 0.42 |
3/8 10 | 0.68 | 17.1 | 2.31 | 0.091 | 0.84 | 0.57 |
1/2 15 | 0.84 | 21.3 | 2.77 | 0.109 | 1.27 | 0.85 |
3/4 20 | 1.05 | 26.7 | 2.87 | 0.113 | 1.69 | 1.13 |
1 25 | 1.32 | 33.4 | 3.38 | 0.133 | 2.5 | 1.68 |
1 1/4 32 | 1.66 | 42.2 | 3.56 | 0.14 | 3.39 | 2.27 |
1 1/2 40 | 1.9 | 48.3 | 3.68 | 0.145 | 4.05 | 2.72 |
2 50 | 2.375 | 60.3 | 3.91 | 0.154 | 5.44 | 3.65 |
2 1/2 65 | 2.875 | 73 | 5.16 | 0.203 | 8.63 | 5.79 |
3 80 | 3.5 | 88.9 | 5.49 | 0.216 | 11.29 | 7.58 |
3 1/2 90 | 4 | 101.6 | 5.74 | 0.226 | 13.57 | 9.11 |
4 100 | 4.5 | 114.3 | 6.02 | 0.237 | 16.07 | 10.79 |
5 125 | 5.563 | 141.3 | 6.55 | 0.258 | 21.77 | 14.62 |
6 150 | 6.625 | 168.3 | 7.11 | 0.28 | 28.26 | 18.97 |
8 200 | 8.625 | 219.1 | 8.18 | 0.322 | 42.55 | 28.55 |
10 250 | 10.75 | 273 | 9.27 | 0.365 | 60.31 | 40.48 |
12 300 | 12.75 | 323.8 | 10.31 | 0.406 | 79.73 | 53.52 |
14 350 | 14 | 355.6 | 11.13 | 0.437 | 94.55 | 54.57 |
16 400 | 16 | 406.4 | 12.7 | 0.5 | 123.3 | 82.77 |
18 450 | 18 | 457 | 14.27 | 0.562 | 155.8 | 104.67 |
20 500 | 20 | 508 | 15.09 | 0.594 | 183.42 | 123.11 |
24 600 | 24 | 610 | 17.48 | 0.688 | 255.41 | 171.29 |
32 800 | 32 | 813 | 17.48 | 0.688 | 342.91 | 230.08 |
ASTM Standards
Pipe Specifications
