MIL-T4973 Tube
Buy 304 MIL-T-4973 Tubing at Affordable Price, MIL-T-4973 TP304 Seamless Stainless Steel Tubing Suppliers in Mumbai
Stainless Steel 304L AMS-T-4973 Tubing, MIL-T-4973 316L Steel, MIL-T-4973 Corrosion-Resistant Tube, Aerospace Vehicle Hydraulic System 1/8 Hard Condition MIL-T-4973 tubing
TRILOK STEEL INDUSTRIES is one of oldest MIL-T-4973 Tube supplier, the most versatile and widely used stainless steels in Aerospace Vehicle Hydraulic System.As well we are known supplier and manufacturer of MIL-T-4973 Tube. We stock and distribute a large and diverse inventory of MIL-T-4973 TP316L Seamless Tube, MIL-T-4973 TP304L Drawn Tube and MIL-T-4973 TP321 Welded Tube from industry-leading and widely accepted manufacturers who meet or exceed the stringent technical requirements. MIL-T-4973 Tubing is Intended for use in high pressure hydraulic and pneumatic systems where corrosion and heat resistant MIL-T-4973 Tube suitable for use in temperatures to 1200°F, when stresses are low.
MIL-T-4973 Specification (Seamless, Welded & Drawn)
MIL-T-4973 Tubing Stock Size Range:| MISC SPEC | GRADE OR PROCESS | DESCRIPTION |
| MIL-T-4973 | 304 | TUBING, STEEL, CORROSION-RESISTANT (S30400), AEROSPACE VEHICLE HYDRAULIC SYSTEM 1/8 HARD CONDITION |
| Attribute | Value |
|---|---|
| Specifications | AMS-T-4973, MIL-T-4973, AMS 5566 |
| AMS Number | AMS T 4973 |
| MIL-T-4973 Cross-sectional Shape Style | Plain round |
| MIL-T-4973 Tube Wall Thickness | 0.035 inches |
| MIL-T-4973 Tube First End Style: | Plain |
| MIL-T-4973 Tube Diameter | 0.500 inches |
| MIL-T-4973 Alloy | 304 |
| MIL-T-4973 Type | Stainless Steel |
| MIL-T-4973 Maximum Operating Temp | 800.0 deg fahrenheit |
| MIL-T-4973 Tube Maximum Operating Pressure | 3000.0 pounds per square inch |
| MIL-T-4973 Tube Surface Condition And Location | Outside polished |
| MIL-T-4973 Tube Measuring Method And Length | 144.000 inches specific |
| MIL-T-4973 Tube Special Features | Aerospace vehicle hydraulic systems |
| MIL-T-4973 Cross Reference Spec | MIL-T-4973D |
| Misc./Shape | Tubing |
MIL-T-4973 Specifications
MIL-T-4973 304 Seamless Stainless Tube
MIL-T-8504 Corrosion Resistant Tube
UNS S30400 Alloy 30304 MIL-T-4973
MIL-T-4973 Stainless Steel Seamless Tube Dealer, MIL-T-4973 Welded Tubes Importer, MIL-T-4973 Seamless Stainless Steel Tubing Distributor, MIL-T-4973 Drawn Tubing Trader, MIL-T-4973 Seamless Tubing
Suppliers of MIL-T-4973 Stainless Steel Seamless tube, Get MIL-T-4973 347 Tube at Best Price, MIL-T-4973 Welded Stainless Steel Tube, Wholesalers of MIL-T-4973 321 Tube, MIL-T-4973 aircraft hydraulic fine tubing Supplier in Mumbai, India.
MIL-T-4973 Tube Sizes / MIL-T-4973 TP 304 Stainless Steel tubing Sizes
MIL-T-4973 Tubes are finished in accordance with customer needs regarding dimensional and wall thickness specifications as well as heat treatment for more demanding applications. In general MIL-T-4973 TP304 stainless steel seamless tube and MIL-T-4973 TP304 stainless steel seamless tube manufactured according to current standards.
MIL-T-4973 TUBING SIZES
MIL-T-4973 TP304 TUBING SIZES
| Tubing TYPE | NB SIZES | SCH 5 | SCH 10 | SCH 40 | SCH 80 | SCH 160 |
|---|---|---|---|---|---|---|
| TP 304 Seamless Stainless Steel Tubing |
1/8″
|
 |
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
1/4″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
3/8″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
1/2″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
3/4″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
1″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
1 1/4″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
1 1/2″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
2″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
2 1/2″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
3″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
4″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
5″
|
|
|
|
|
|
| TP 304 Seamless Stainless Steel Tubing |
6″
|
|
|
|
|
| NB SIZES | SCH 5 | SCH 10 | SCH 40 | SCH 80 | SCH 160 |
|---|---|---|---|---|---|
|
1/8″
|
|
|
|
|
|
|
1/4″
|
|
|
|
|
|
|
3/8″
|
|
|
|
|
|
|
1/2″
|
|
|
|
|
|
|
3/4″
|
|
|
|
|
|
|
1″
|
|
|
|
|
|
|
1 1/4″
|
|
|
|
|
|
|
1 1/2″
|
|
|
|
|
|
|
2″
|
|
|
|
|
|
|
2 1/2″
|
|
|
|
|
|
|
3″
|
|
|
|
|
|
|
4″
|
|
|
|
|
|
|
5″
|
|
|
|
|
|
|
6″
|
|
|
|
|
TOP NUMBER: Wall Thickness in Inches
BOTTOM NUMBER: Weight Per Foot in Pound
|
Tube
SIZE
|
O.D. INCHES | 5S | 5 | 10S | 10 | 20 | 30 | 40S & STD. | 40 | 60 | 80S & E.H. | 80 | 100 | 120 | 140 | 160 | DBL. E.H. |
| 1/8 | .405 | .035 .1383 | .049 .1363 | .049 .1363 | .068 .2447 | .068 .2447 | .095 .3145 | .095 .3145 | |||||||||
| 1/4 | .540 | .049 .2570 | .065 .3297 | .065 .3297 | .088 .4248 | .088 .4248 | .119 .5351 | .119 .5351 | |||||||||
| 3/8 | .675 | .049 .3276 | .065 .4235 | .065 .4235 | .091 .5676 | .091 .5676 | .126 .7388 | .126 .7388 | |||||||||
| 1/2 | .840 | .065 .5383 | .065 .5380 | .083 .6710 | .083 .6710 | .109 .8510 | .109 .8510 | .147 1.088 | .147 1.088 | .187 1.304 | .294 1.714 | ||||||
| 3/4 | 1.050 | .065 .6838 | .065 .6838 | .083 .8572 | .083 .8572 | .113 1.131 | .113 1.131 | .154 1.474 | .154 1.474 | .218 1.937 | .308 2.441 | ||||||
| 1 | 1.315 | .065 .8678 | .065 .8678 | .109 1.404 | .109 1.404 | .133 1.679 | .133 1.679 | .179 2.172 | .179 2.172 | .250 2.844 | .358 3.659 | ||||||
| 1 1/4 | 1.660 | .065 1.107 | .065 1.107 | .109 1.806 | .109 1.806 | .140 2.273 | .140 2.273 | .191 2.997 | .191 2.997 | .250 3.765 | .382 5.214 | ||||||
| 1 1/2 | 1.900 | .065 1.274 | .065 1.274 | .109 2.085 | .109 2.085 | .145 2.718 | .145 2.718 | .200 3.631 | .200 3.631 | .281 4.859 | .400 6.408 | ||||||
| 2 | 2.375 | .065 1.604 | .065 1.604 | .109 2.638 | .109 2.638 | .154 3.653 | .154 3.653 | .218 5.022 | .218 5.022 | .344 7.462 | .436 9.029 | ||||||
| 2 1/2 | 2.875 | .083 2.475 | .083 2.475 | .120 3.531 | .120 3.531 | .203 5.793 | .203 5.793 | .276 7.661 | .276 7.661 | .375 10.01 | .552 13.70 | ||||||
| 3 | 3.500 | .083 3.029 | .083 3.029 | .120 4.332 | .120 4.332 | .216 7.576 | .216 7.576 | .300 10.25 | .300 10.25 | .438 14.32 | .600 18.58 | ||||||
| 3 1/2 | 4.000 | .083 3.472 | .083 3.472 | .120 4.973 | .120 4.973 | .226 9.109 | .226 9.109 | .318 12.51 | .318 12.51 | .636 22.85 | |||||||
| 4 | 4.500 | .083 3.915 | .083 3.915 | .120 5.613 | .120 5.613 | .237 10.79 | .237 10.79 | .337 14.98 | .337 14.98 | .438 19.00 | .531 22.51 | .674 27.54 | |||||
| 4 1/2 | 5.000 | .247 12.54 | .355 17.60 | ||||||||||||||
| 5 | 5.563 | .109 6.349 | .109 6.349 | .134 7.770 | .134 7.770 | .258 14.62 | .258 14.62 | .375 20.78 | .375 20.78 | .500 20.78 | .625 32.96 | .750 38.55 | |||||
| 6 | 6.625 | .109 7.585 | .109 7.585 | .134 9.289 | .134 9.289 | .280 18.97 | .280 18.97 | .432 28.57 | .432 28.57 | .562 36.39 | .719 43.35 | .864 53.16 | |||||
|
Tube
SIZE
|
O.D. INCHES | 5S | 5 | 10S | 10 | 20 | 30 | 40S & STD. | 40 | 60 | 80S & E.H. | 80 | 100 | 120 | 140 | 160 | DBL. E.H. |
| 7 | 7.625 | .301 23.54 | .500 38.04 | .875 63.08 | |||||||||||||
| 8 | 8.625 | .109 9.914 | .109 9.914 | .148 13.40 | .148 13.40 | .250 22.36 | .277 24.70 | .322 28.55 | .322 28.55 | .406 35.64 | .500 43.39 | .500 43.39 | .594 50.95 | .719 60.71 | .812 67.76 | .906 74.69 | .875 72.42 |
| 9 | 9.625 | .342 33.91 | .500 48.73 | ||||||||||||||
| 10 | 10.75 | .134 15.19 | .134 15.19 | .165 18.70 | .165 18.70 | .250 28.04 | .307 34.24 | .365 40.48 | .365 40.48 | .500 54.74 | .500 54.74 | .594 64.43 | .719 77.03 | .844 82.29 | 1.000 104.1 | 1.125 115.6 | 1.000 104.1 |
| 11 | 11.75 | .375 45.56 | .500 60.08 | ||||||||||||||
| 12 | 12.75 | .156 21.07 | .165 22.18 | .180 24.16 | .180 24.16 | .250 33.38 | .330 43.77 | .375 49.56 | .406 53.52 | .562 73.15 | .500 65.42 | .688 88.63 | .844 107.3 | 1.000 125.5 | 1.125 136.7 | 1.312 160.3 | 1.000 125.5 |
| 14 | 14.00 | .156 23.07 | .188 27.73 | .250 36.71 | .312 45.61 | .375 54.57 | .375 54.57 | .438 63.44 | .594 85.05 | .500 72.09 | .750 106.1 | .938 130.9 | 1.094 150.8 | 1.250 170.2 | 1.406 189.1 | ||
| 16 | 16.00 | .165 27.90 | .188 31.75 | .250 42.05 | .312 52.27 | .375 62.58 | .375 62.58 | .500 82.77 | .656 107.5 | .500 82.77 | .844 136.6 | 1.031 164.8 | 1.219 192.4 | 1.438 223.6 | 1.594 245.3 | ||
| 18 | 18.00 | 165 31.43 | .188 35.76 | .250 47.39 | .312 58.94 | .438 82.15 | .375 70.59 | .562 104.7 | 750 138.2 | .500 93.45 | .938 170.9 | 1.156 208.0 | 1.375 244.1 | 1.562 274.2 | 1.781 308.5 | ||
| 20 | 20.00 | .188 39.78 | .218 46.05 | .250 52.73 | .375 78.60 | .500 104.1 | .375 78.60 | .594 123.1 | .812 166.4 | .500 104.1 | 1.031 208.9 | 1.281 256.1 | 1.500 296.4 | 1.750 341.1 | 1.969 379.2 | ||
| 24 | 24.00 | .218 55.37 | .250 63.41 | .250 63.41 | .375 94.42 | .562 140.7 | .375 94.42 | .688 171.3 | .969 238.4 | .500 125.5 | 1.219 296.8 | 1.531 367.4 | 1.812 429.4 | 2.062 483.1 | 2.344 542.1 | ||
| 26 | 26.00 | .312 85.60 | .500 136.17 | .375 102.63 | .500 136.17 | ||||||||||||
| 28 | 28.00 | .312 92.26 | .500 146.85 | .625 182.73 | .375 110.64 | ||||||||||||
| 30 | 30.00 | .250 79.43 | .312 98.93 | .312 98.93 | .500 157.53 | .625 196.08 | .375 118.65 | .500 157.53 | |||||||||
| 32 | 32.00 | .312 105.59 | .500 168.21 | .625 209.43 | .375 126.66 | .688 230.08 | .500 168.21 | ||||||||||
| 34 | 34.00 | .312 112.25 | .500 178.89 | .625 222.78 | .375 134.67 | .688 244.77 | |||||||||||
| 36 | 36.00 | .312 118.92 | .500 189.57 | .625 236.13 | .375 142.68 | .750 282.35 | .500 189.57 |
MIL-T-4973 Welded Stainless Steel Tube Tolerances
| NPS Designator | Permissible Variations in Outside Diameter | |
|---|---|---|
| Over In. | Under In. | |
| 1/8 to 1-1/2, incl | 1/64 (0.015) | 1/32 (0.031) |
| Over 1-1/2 to 4, incl | 1/32 (0.031) | 1/32 (0.031) |
| Over 4 to 8, incl | 1/16 (0.062) | 1/32 (0.031) |
| Over 8 to 18, incl | 3/23 (0.093) | 1/32 (0.031) |
Nominal Wall Thickness:
| Product | NPS Designator | Outside Diameter in. | Schedule 5S in. | Schedule 10S in. | Schedule 40S in. | Schedule 80S in. |
|---|---|---|---|---|---|---|
| MIL-T-4973 Tube | 1/4 | 0.540 | 0.065 | 0.088 | 0.119 | |
| MIL-T-4973 Tube | 3/8 | 0.675 | 0.065 | 0.091 | 0.126 | |
| MIL-T-4973 Tube | 1/2 | 0.840 | 0.065 | 0.083 | 0.109 | 0.147 |
| MIL-T-4973 Tube | 3/4 | 1.050 | 0.065 | 0.083 | 0.113 | 0.154 |
| MIL-T-4973 Tube | 1.0 | 1.315 | 0.065 | 0.109 | 0.133 | 0.179 |
| MIL-T-4973 Tube | 1 1/4 | 1.660 | 0.065 | 0.109 | 0.140 | 0.191 |
| MIL-T-4973 Tube | 1 1/2 | 1.900 | 0.065 | 0.109 | 0.145 | 0.200 |
| MIL-T-4973 Tube | 2 | 2.375 | 0.065 | 0.109 | 0.154 | 0.218 |
| MIL-T-4973 Tube | 2 1/2 | 2.875 | 0.083 | 0.120 | 0.203 | 0.276 |
| MIL-T-4973 Tube | 3 | 3.500 | 0.083 | 0.120 | 0.216 | 0.300 |
| MIL-T-4973 Tube | 3 1/2 | 4.000 | 0.083 | 0.120 | 0.226 | 0.318 |
| MIL-T-4973 Tube | 4 | 4.500 | 0.083 | 0.120 | 0.237 | 0.337 |
| MIL-T-4973 Tube | 5 | 5.563 | 0.109 | 0.134 | 0.258 | 0.375 |
| MIL-T-4973 Tube | 6 | 6.625 | 0.109 | 0.134 | 0.280 | 0.432 |
| MIL-T-4973 Tube | 8 | 8.625 | 0.109 | 0.148 | 0.322 | 0.500 |
| MIL-T-4973 Tube | 10 | 10.750 | 0.134 | 0.165 | 0.365 | 0.500 |
| MIL-T-4973 Tube | 12 | 12.750 | 0.156 | 0.180 | 0.375 | 0.500 |
Wall Thickness Tolerance MIL-T-4973 Tubes
| NPS | MIL-T-4973 Tube Tolerance, % | |
| + | – | |
| 1/8-2 1 /2 | 20.0 | 12.5 |
| 3~18, t/D≤ 5% | 22.5 | 12.5 |
| 3~18, t/D> 5% | 15.0 | 12.5 |
| ≥ 20, welded | 17.5 | 12.5 |
| ≥ 20, seamless, t/D≤ 5% | 22.5 | 12.5 |
| ≥ 20, seamless, t/D> 5% | 15.0 | 12.5 |
MIL-T-4973 Properties
MIL-T-4973 Chemical Composition
The below table shows the chemical composition of the used for MIL-T-4973 Seamless Stainless Steel Tubing:
| Weight % | Ni | Cr | Mn | C | Si | Mo | S | P | Cu |
|---|---|---|---|---|---|---|---|---|---|
| Minimum | 8.00 | 18.00 | |||||||
| Maximum | 10.50 | 20.00 | 2.00 | .08 | 1.00 | .75 | .03 | .045 | .75 |
MIL-T-4973 TUBE Mechanical Properties (.250" OD and over)
| Ultimate | Yield | Elongation % |
|---|---|---|
| KSI | PSI | |
| 105-140 | 75-110 min | 20% |
Available Stock of MIL-T-4973 TUBE, MIL-T-4973 TP304 SEAMLESS TUBE
| MIL-T-4973 TP304 Stainless Steel Tube | MIL-T-4973 TP304 Stainless teel Tube |
| MIL-T-4973 stainless steel Tube | MIL-T-4973 Tube |
| MIL-T-4973 TP304L Stainless Steel Tube | MIL-T-4973 TP 304 Cold Drawn Tube |
| MIL-T-4973 Seamless Stainless Steel Tube | MIL-T-4973 TP 304 Tube |
| MIL-T-4973 TP304 Welded Stainless Steel Tube | MIL-T-4973 Tube |
| 304 MIL-T-4973 Stainless Steel Round Tube | MIL-T-4973 Grade 304 Tube |
| MIL-T-4973 TP304 Tube | MIL-T-4973 Gr. 304 Tube |
| MIL-T-4973 Corrosion Resistant Tube | MIL-T-4973 Stainless Steel Seamless Tubing |
| MIL-T-4973 TP304 Stainless Steel Rectangular Tube | Welded stainless steel tube MIL-T-4973 |
| MIL-T-4973 1/8 Hard Stainless steel tube | MIL-T-4973 Aerospace tubing |
| MIL-T-4973 Tubing | MIL-T-4973 Steel tubing |
| AMS-T-4973 Seamless Tubes | SAE MIL-T-4973 Tube |
MIL-T-4973 TUBE Price List
- MIL-T-4973 seamless Tube
US $1.5-9 / Kilogram (FOB Price) - MIL-T-4973 welded Tube manufacturer
US $850-2200 / Metric Ton (FOB Price) - MIL-T-4973 stainless steel Tube
US $500-1000 / Ton (FOB Price) - MIL-T-4973 tp304 Tube
US $800-1600 / Ton (FOB Price) - round tube MIL-T-4973 tp304
US $1-100 / Piece (FOB Price) - MIL-T-4973 TP304 Tube
US $500-820 / Ton (FOB Price) - MIL-T-4973 seamless tube
US $2000-6500 / Ton (FOB Price) - MIL-T-4973 tp304 stainless steel Tubing
US $2500-4100 / Ton (FOB Price) - MIL-T-4973 tp321 Tube
US $600-1200 / Ton (FOB Price) - stainless steel Tube MIL-T-4973
US $500-2000 / Ton (FOB Price) - MIL-T-4973 stainless welded Tube
US $850-2200 / Metric Ton (FOB Price) - 304 MIL-T-4973 tube
US $2660-7680 / Ton (FOB Price) - MIL-T-4973 round Tube
US $4400-9300 / Ton (FOB Price)
- MIL-T-4973 tp304l stainless steel Tube
US $3000-6000 / Metric Ton (FOB Price) - MIL-T-4973 304 stainles steel Tube
US $3400-11000 / Ton (FOB Price) - MIL-T-4973 Stainless seamless Tube with different sizes
US $3.8-5 / Kilogram (FOB Price) - MIL-T-4973 Stainless Steel Tube
US $500-2000 / Ton (FOB Price) - MIL-T-4973 welded stainless steel tube
US $1-9999 / Kilogram (FOB Price) - Prime quality MIL-T-4973 tp304 stainless steel Tube
US $2000-3000 / Ton (FOB Price) - AMS-T-4973 Tube
US $2100-2400 / Ton (FOB Price) - MIL-T-4973 seamless stainless steel Tube
US $3000-8000 / Metric Ton (FOB Price) - Prime quality MIL-T-4973 tp304 Tubes
US $2000-3000 / Ton (FOB Price) - MIL-T-4973 flat oval tube
US $40-120 / Kilogram (FOB Price) - MIL-T-4973 Aerospace Vehicle Hydraulic System tube
US $3000-5000 / Metric Ton (FOB Price) - MIL-T-4973 1/8 hard stainless steel Tube
US $6000-15000 / Ton (FOB Price)
MIL-T-4973 TP 304 Seamless Stainless Steel Tubing
Product Name: MIL-T-4973 TP 304 Seamless Stainless Steel Tubing
Manufacturer Test Certificate
IBR Test Certificate (Form III-D)
Laboratory Test Certificate from Govt. Approved Lab.
Under Third Party Inspection with Excise Gate Pass to avail
Modvat benefit.
MIL-T-4973 TP 304 Seamless Stainless Steel Tubing Value Added Services
- Draw & Expansion as per required Size & Length
- Polish (Electro & Commercial) Heat Treatment
- Bending
- Annealed & Pickled
- Sand Blasting
- Machining Etc.
Internal and external protection
We perform sandblasting according to SA 2,5 and protect the Tube surfaces from rust using a primer such as clear varnish, epoxy or zinc phosphate, etc. Upon request, we provide Tube protection by means of polyethylene, polypropylene, fibre-cement casing, or with bitumen. All kinds of paint coatings and galvanisation are also available.
MIL-T-4973 TP 304 Seamless Stainless Steel Tubing Advantages
These MIL-T-4973 Stainless Steel Tube grades are sold to a wide range of industries/markets, due to their overall corrosion resistance and good machinability:
- High strength
- Resistant to high mechanical stresses
- Resistant to high pressure
- Resistant to high temperature
- Good formability
- Reusable
MIL-T-4973 Tubing Packaging
MIL-T-4973 tubing shall be properly separated by size’(outside ~~~me~~~, and wall thickness. The ends of MIL-T-4973 tubing shall be sealed exclude dirt and dust.
MIL-T-4973 Tubing Packaging for shipment. Material shal1 be packaged for shipment in accordance with the methods prescribed in MIL-STD-163.
MIL-T-4973 Marking of shipments. Interior packages and exterior shfpping containers shal1 be marked in accordance with MIL-STO-129. The identification shall include the following information listed in the order shown: Stock No. or other identification number as specified in the purchase document TUBING, STEEL, CORROSION-RESISjANT [304), AEROSPACE VEHICLE HYDRAULIC SYSTEM, 1/8 HARD ‘CONDITION MIL-T-4973 Size (diameter), Wall thickness ,Heat No., Type,Class,Quantity contained,Name of manufacturer,Name of contractor (if different from manufacturer),Contract or Order No.
