The Stainless Steel 316 Pipe is of the austenitic grade and it offers good resistance to the chloride ion stress corrosion cracking. They also show good resistance in the acidic mediums. The 316 ss pipes are versatile and have some great mechanical properties. They are also known for their superior tensile strength. Thus, the 316 SS pipes are used for those applications which need superior properties compared to the Stainless Steel 304 Pipe.
The schedule 10 316 stainless steel pipe is basically a low schedule pipe with a smaller wall thickness and hence it has lower pressure bearing capabilities. The wall thickness varies with the schedule defined for the pipe. This means that the schedule 40 316 stainless steel pipe has a higher schedule and greater wall thickness. Thus, they are able to bear higher pressure when compared to the SCH 10 SS 3156 pipes.
The 316 stainless steel seamless pipes do not have any weldings or joints,whereas the SS 316 ERW pipe, on the other hand, has welded joints and seams. They are basically manufactured by longitudinally welding steel ribbons. Another major point of difference between these two pipes are in their pricing. The seamless pipes are more expensive compared to the ERW pipes.
The 316 ss is an upgraded version of the 304 SS due to additional molybdenum and a little a bit higher nickel content. This chemical competition has given the 316 ss pipes enhanced resistance to different types of corrosions and improved physical properties. They have a higher strength and offer better creep resistance at higher temperatures. They also possess excellent mechanical properties at a sub-zero temperature. They have a hardness of 165 Brinell.
The Price Of 316 Stainless Steel Pipe Per Foot varies from one supplier to another depending on the quality of the raw material used for manufacturing the pipe. When compared to the USA market, the price of the ss 316 pipe per foot is a lot cheaper, and that is why there is an increased demand for the Indian products worldwide. The same quality pipes are available at a much lower price.
There has been significant growth when it comes to industrialization in Malaysia and Singapore. The countries have seen a considerable increase in the manufacturing sector that includes industries chemical, petroleum, rubber, etc. The Stainless Steel 316 Pipes are used widely in these industries, due to its unique physical and mechanical properties and hence, this is the reason behind increasing demand of the given pipes from these countries.
The 1.4401 pipe material also known as the 316 grade is widely used for sea water applications due to its enhanced resistance to chloride ion stress corrosion cracking. They also have titanium in the composition which is a great at resisting salt water and are widely used in several critical underwater applications.
Stainless Steel 316 Pipe
316 Stainless Steel Seamless Pipe
316 Stainless Steel Welded Pipe
Table of Content
Stainless Steel 316 Pipe ASTM Specification | SA/ A312 |
International Standards | AMS, TOCT, DIN, ASME, GB, JIS, DS, SAE, NF, ASTM, DTD, AISI, EN |
316 Stainless Steel Seamless Pipe Size |
|
Stainless Steel 316 Welded Pipe Size |
|
316 Marine Grade Stainless Steel EFW Pipe Size |
|
316 Grade Stainless Steel Pipe Wall Thickness | SCH 5, SCH 10, SCH 40, SCH 80, SCH 80S, SCH 160 SCH XS, SCH XXS |
Manufacturing methods of SS 316 Pipe | LSAW, EFW, Redrawn, Fabricated, CDW, Seam-Welded, Seamless, Welded, ERW |
316 SS Pipe Origin | Korean, Indian, European, Japanese |
1.4401 Stainless Steel Pipe Ends | PBE, TBE, BLE, BBE, POE/BOE, Beveled(BE), BSE, TOE/BOE, TOE/POE |
Shape | Rectangular, Hex, Round, Square |
SUS 316 Pipe Length | Single-Random or Double-Random |
Delivery Condition of AISI 316 Pipe | Hot-Finished, Polished, Bright-Annealed, Pickled, Cold-Drawn, Annealed |
DIN 1.4401 Stainless Steel Pipe Packing |
|
X5crnimo17-12-2 AISI 316 SS Pipe Value Added Services | Groove, Polished, Cut to size, and thread |
Stainless Steel 316 Pipe surface finish |
2B, hairline, No.8, SATIN, 1D, No.4, No.1, 8K, brush, BA, 2D, mirror, |
We Export to | Find Trilok Steel executive in the following countries, get a free quote of Stainless Steel 316 Pipe and delivery Schedule:
|
Port | Mumbai, Chennai, and Ahmedabad (India) |
Stocking distributor of leading Stainless Steel 316 Pipe manufacturers |
|
X5crnimo17-12-2 AISI 316 SS Pipe Dimensional Standard | ANSI/ ASME B36.10, B36.19, B2.1 |
Marking on 1.4408 AISI Pipe |
|
Stainless Steel 316 Pipe ASTM Specification | SA/ A312 |
International Standards | AMS, TOCT, DIN, ASME, GB, JIS, DS, SAE, NF, ASTM, DTD, AISI, EN |
316 Stainless Steel Seamless Pipe Size |
|
Stainless Steel 316 Welded Pipe Size |
|
316 Marine Grade Stainless Steel EFW Pipe Size |
|
316 Grade Stainless Steel Pipe Wall Thickness | SCH 5, SCH 10, SCH 40, SCH 80, SCH 80S, SCH 160 SCH XS, SCH XXS |
Manufacturing methods of SS 316 Pipe | LSAW, EFW, Redrawn, Fabricated, CDW, Seam-Welded, Seamless, Welded, ERW |
316 SS Pipe Origin | Korean, Indian, European, Japanese |
1.4401 Stainless Steel Pipe Ends | PBE, TBE, BLE, BBE, POE/BOE, Beveled(BE), BSE, TOE/BOE, TOE/POE |
Shape | Rectangular, Hex, Round, Square |
SUS 316 Pipe Length | Single-Random or Double-Random |
Delivery Condition of AISI 316 Pipe | Hot-Finished, Polished, Bright-Annealed, Pickled, Cold-Drawn, Annealed |
DIN 1.4401 Stainless Steel Pipe Packing |
|
X5crnimo17-12-2 AISI 316 SS Pipe Value Added Services | Groove, Polished, Cut to size, and thread |
Stainless Steel 316 Pipe surface finish |
2B, hairline, No.8, SATIN, 1D, No.4, No.1, 8K, brush, BA, 2D, mirror, |
We Export to | Find Trilok Steel executive in the following countries, get a free quote of Stainless Steel 316 Pipe and delivery Schedule:
|
Port | Mumbai, Chennai, and Ahmedabad (India) |
Stocking distributor of leading Stainless Steel 316 Pipe manufacturers |
|
X5crnimo17-12-2 AISI 316 SS Pipe Dimensional Standard | ANSI/ ASME B36.10, B36.19, B2.1 |
Marking on 1.4408 AISI Pipe |
|
SS 316 Seamless Pipe, Schedule 40 | ||
---|---|---|
Size | UNIT PER LENGTH | |
Inch | Metric (mm) | 1 Length=6 Meters |
1/2 Inch | 15 | 5,801 |
3/4 Inch | 20 | 6,526 |
1 Inch | 25 | 8,061 |
1-1/4 Inch | 32 | 10,791 |
1-1/2 Inch | 40 | 14,761 |
2 Inch | 50 | 20,296 |
2-1/2 Inch | 65 | 23,975 |
3 Inch | 80 | 31,355 |
4 Inch | 100 | 52,880 |
5 Inch | 125 | 62,110 |
6 Inch | 150 | 87,410 |
8 Inch | 200 | 133,201 |
10 Inch | 250 | 144,310 |
12 Inch | 300 | 210,910 |
14 Inch | 350 | 288,610 |
16 Inch | 400 | 355,210 |
Stainless Steel 316 Pipe Price List only for bare pipe - without pressure tested | |||
OD | SCH 5S FOB Mumbai/ Ahmedabad/ Chennai Port | SCH 10S FOB Mumbai/ Ahmedabad/ Chennai Port | SCH 40S FOB Mumbai/ Ahmedabad/ Chennai Port |
SIZE INCH | 316 | 316 | 316 |
1/2 Inch | 3013.82 | 3013.82 | 2827.34 |
3/4 Inch | 3013.82 | 3013.82 | 2827.34 |
1 Inch | 3013.82 | 2827.34 | 2827.34 |
1 1/4 Inch | 2984.97 | 2769.72 | 2769.72 |
1 1/2 Inch | 2984.97 | 2769.72 | 2769.72 |
2 Inch | 2984.97 | 2769.72 | 2769.72 |
2 1/2 Inch | 2957.00 | 2740.91 | 2769.72 |
3 Inch | 2957.00 | 2740.91 | 2769.72 |
3 1/2 Inch | 2957.00 | 2740.91 | 2769.72 |
4 Inch | 2957.00 | 2740.91 | 2769.72 |
5 Inch | 2754.91 | 2754.91 | 2827.34 |
6 Inch | 2754.91 | 2754.91 | 2827.34 |
8 Inch | 2754.91 | 2754.91 | 2827.34 |
Price in USD/ TON |
---|
SS 316 Welded Pipe, Schedule 40 | ||
---|---|---|
Size | UNIT PER LENGTH | |
Inch | Metric (mm) | 1 Length=6 Meters |
1/2 Inch | 15 mm | 3,117 |
3/4 Inch | 20 mm | 4,135 |
1 Inch | 25 mm | 5,137 |
1-1/4 Inch | 32 mm | 6,106 |
1-1/2 Inch | 40 mm | 7,156 |
2 Inch | 50 mm | 9,212 |
2-1/2 Inch | 65 mm | 13,844 |
3 Inch | 80 mm | 16,866 |
4 Inch | 100 mm | 25,480 |
5 Inch | 125 mm | 34,321 |
6 Inch | 150 mm | 43,601 |
8 Inch | 200 mm | 75,302 |
10 Inch | 250 mm | 124,546 |
12 Inch | 300 mm | 148,288 |
14 Inch | 350 mm | 245,567 |
16 Inch | 400 mm | 280,145 |
18 Inch | 450 mm | 314,728 |
20 Inch | 500 mm | 349,305 |
22 Inch | 550 mm | 383,884 |
24 Inch | 600 mm | 418,462 |
26 Inch | 650 mm | 453,045 |
28 Inch | 700 mm | 467,622 |
30 Inch | 750 mm | 522,214 |
32 Inch | 800 mm | 556,760 |
34 Inch | 850 mm | 591,352 |
36 Inch | 900 mm | 625,944 |
40 Inch | 1000 mm | 660,536 |
SS 316 Welded Pipe, Schedule 10 | ||
---|---|---|
Size | UNIT PER LENGTH | |
Inch | Metric (mm) | 1 Length=6 Meters |
1/2 Inch | 15 mm | 2,777 |
3/4 Inch | 20 mm | 3,268 |
1 Inch | 25 mm | 4,042 |
1-1/4 Inch | 32 mm | 5,906 |
1-1/2 Inch | 40 mm | 4,962 |
2 Inch | 50 mm | 6,387 |
2-1/2 Inch | 65 mm | 8,927 |
3 Inch | 80 mm | 10,668 |
4 Inch | 100 mm | 14,163 |
5 Inch | 125 mm | 19,596 |
6 Inch | 150 mm | 23,435 |
8 Inch | 200 mm | 36,496 |
10 Inch | 250 mm | 50,400 |
12 Inch | 300 mm | 64,924 |
14 Inch | 350 mm | 118,483 |
16 Inch | 400 mm | 138,119 |
18 Inch | 450 mm | 155,467 |
20 Inch | 500 mm | 199,826 |
22 Inch | 550 mm | 219,928 |
24 Inch | 600 mm | 274,609 |
26 Inch | 650 mm | 297,648 |
28 Inch | 700 mm | 320,688 |
30 Inch | 750 mm | 427,582 |
32 Inch | 800 mm | 456,319 |
34 Inch | 850 mm | 485,056 |
36 Inch | 900 mm | 513,774 |
40 Inch | 1000 mm | 571,256 |
21.3mm OD x 2.8mm (1/2" NB Sch 10) | from £49.10 |
26.7mm OD x 2.1mm (3/4" NB Sch 10) | from £54.15 |
26.7mm OD x 2.9mm (3/4" NB Sch 40) | from £13.71 |
33.4mm OD x 2.8mm (1" NB Sch 10) | from £16.83 |
33.4mm OD x 3.4mm (1" NB Sch 40) | from £18.59 |
42.2mm OD x 2.8mm (1 1/4" NB Sch 10) | from £17.58 |
48.3mm OD x 2.8mm (1 1/2" NB Sch 10) | from £19.25 |
42.2mm OD x 3.6mm (1 1/4" NB Sch 40) | from £18.02 |
60.3mm OD x 2.8mm (2" NB Sch 10) | from £23.95 |
60.3mm OD x 3.9mm (2" NB Sch 40) | from £28.19 |
Type | Price |
---|---|
1 1/2 inch, 10 ft Length, Schedule 5S, Unthreaded | $163.86 / each |
2 inch, 10 ft Length, Schedule 5S, Unthreaded, Welded | $217.09 / each |
Klang (Malaysia) | Singapore (Singapore) |
EXW (Netherlands) | Laem Chabang (Thailand) |
Ho Chi Minh (Vietnam) | Vancouver (Canada) |
Port of Melbourne (Australia) | Jakarta (Indonesia) |
Surabaya (Indonesia) | FCA Antwerp (Netherlands) |
Stainless Steel 316 Seamless Pipe
Stainless Steel 316 Welded Pipe
Stainless Steel 316 ERW Pipe
Stainless Steel 316 Round Pipe
Schedule 40 Stainless Steel 316 Pipe
Stainless Steel 316 Square Pipe
Stainless Steel 316 Rectangular Pipe
Stainless Steel 316 Polished Pipe
NPS | ID | WT inch (mm) | OD inch (mm) | Weight lb/ft (kg/m) |
1/8 | 5S | 0.405 (10.3) | ... | |
1/8 | 10S | 0.049 (1.24) | 0.405 (10.3) | 0.19 (0.28) |
1/8 | 40S | 0.068 (1.73) | 0.405 (10.3) | 0.24 (0.37) |
1/8 | 80S | 0.095 (2.41) | 0.405 (10.3) | 0.31 (0.47) |
1/4 | 5S | 0.54 (13.7) | ... | |
1/4 | 10S | 0.065 (1.65) | 0.54 (13.7) | 0.33 (0.49) |
1/4 | 40S | 0.088 (2.24) | 0.54 (13.7) | 0.43 (0.63) |
1/4 | 80S | 0.119 (3.02) | 0.54 (13.7) | 0.54 (0.8) |
3/8 | 5S | 0.675 (17.1) | ... | |
3/8 | 10S | 0.065 (1.65) | 0.675 (17.1) | 0.42 (0.63) |
3/8 | 40S | 0.091 (2.31) | 0.675 (17.1) | 0.57 (0.84) |
3/8 | 80S | 0.126 (3.2) | 0.675 (17.1) | 0.74 (1.1) |
1/2 | 5S | 0.065 (1.65) | 0.84 (21.3) | 0.54 (0.8) |
1/2 | 10S | 0.083 (2.11) | 0.84 (21.3) | 0.67 (1.0) |
1/2 | 40S | 0.109 (2.77) | 0.84 (21.3) | 0.85 (1.27) |
1/2 | 80S | 0.147 (3.73) | 0.84 (21.3) | 1.09 (1.62) |
3/4 | 5S | 0.065 (1.65) | 1.05 (26.7) | 0.68 (1.02) |
3/4 | 10S | 0.083 (2.11) | 1.05 (26.7) | 0.86 (1.28) |
3/4 | 40S | 0.113 (2.87) | 1.05 (26.7) | 1.13 (1.69) |
3/4 | 80S | 0.154 (3.91) | 1.05 (26.7) | 1.48 (2.2) |
1 | 5S | 0.065 (1.65) | 1.315 (33.4) | 0.87 (1.29) |
1 | 10S | 0.109 (2.77) | 1.315 (33.4) | 1.41 (2.09) |
1 | 40S | 0.133 (3.38) | 1.315 (33.4) | 1.68 (2.5) |
1 | 80S | 0.179 (4.55) | 1.315 (33.4) | 2.17 (3.24) |
1.1/4 | 5S | 0.065 (1.65) | 1.66 (42.2) | 1.11 (1.65) |
1.1/4 | 10S | 0.109 (2.77) | 1.66 (42.2) | 1.81 (2.69) |
1.1/4 | 40S | 0.14 (3.56) | 1.66 (42.2) | 2.27 (3.39) |
1.1/4 | 80S | 0.191 (4.85) | 1.66 (42.2) | 3.0 (4.47) |
1.1/2 | 5S | 0.065 (1.65) | 1.9 (48.3) | 1.28 (1.9) |
1.1/2 | 10S | 0.109 (2.77) | 1.9 (48.3) | 2.09 (3.11) |
1.1/2 | 40S | 0.145 (3.68) | 1.9 (48.3) | 2.72 (4.05) |
1.1/2 | 80S | 0.2 (5.08) | 1.9 (48.3) | 3.63 (5.41) |
2 | 5S | 0.065 (1.65) | 2.375 (60.3) | 1.61 (2.39) |
2 | 10S | 0.109 (2.77) | 2.375 (60.3) | 2.64 (3.93) |
2 | 40S | 0.154 (3.91) | 2.375 (60.3) | 3.66 (5.44) |
2 | 80S | 0.218 (5.54) | 2.375 (60.3) | 5.03 (7.48) |
2.1/2 | 5S | 0.083 (2.11) | 2.875 (73) | 2.48 (3.69) |
2.1/2 | 10S | 0.12 (3.05) | 2.875 (73) | 3.53 (5.26) |
2.1/2 | 40S | 0.203 (5.16) | 2.875 (73) | 5.8 (8.63) |
2.1/2 | 80S | 0.276 (7.01) | 2.875 (73) | 7.67 (11.41) |
3 | 5S | 0.083 (2.11) | 3.5 (88.9) | 3.03 (4.52) |
3 | 10S | 0.12 (3.05) | 3.5 (88.9) | 4.34 (6.46) |
3 | 40S | 0.216 (5.49) | 3.5 (88.9) | 7.58 (11.29) |
3 | 80S | 0.3 (7.62) | 3.5 (88.9) | 10.26 (15.27) |
3.1/2 | 5S | 0.083 (2.11) | 4.0 (101.6) | 3.48 (5.18) |
3.1/2 | 10S | 0.12 (3.05) | 4.0 (101.6) | 4.98 (7.41) |
3.1/2 | 40S | 0.226 (5.74) | 4.0 (101.6) | 9.12 (13.57) |
3.1/2 | 80S | 0.318 (8.08) | 4.0 (101.6) | 12.52 (18.64) |
4 | 5S | 0.083 (2.11) | 4.5 (114.3) | 3.92 (5.84) |
4 | 10S | 0.12 (3.05) | 4.5 (114.3) | 5.62 (8.37) |
4 | 40S | 0.237 (6.02) | 4.5 (114.3) | 10.8 (16.08) |
4 | 80S | 0.337 (8.56) | 4.5 (114.3) | 15.0 (22.32) |
5 | 5S | 0.109 (2.77) | 5.563 (141.3) | 6.36 (9.46) |
5 | 10S | 0.134 (3.4) | 5.563 (141.3) | 7.78 (11.56) |
5 | 40S | 0.258 (6.55) | 5.563 (141.3) | 14.63 (21.77) |
5 | 80S | 0.375 (9.53) | 5.563 (141.3) | 20.8 (30.97) |
6 | 5S | 0.109 (2.77) | 6.625 (168.3) | 7.59 (11.31) |
6 | 10S | 0.134 (3.4) | 6.625 (168.3) | 9.3 (13.83) |
6 | 40S | 0.28 (7.11) | 6.625 (168.3) | 18.99 (28.26) |
6 | 80S | 0.432 (10.97) | 6.625 (168.3) | 28.6 (42.56) |
8 | 5S | 0.109 (2.77) | 8.625 (219.1) | 9.92 (14.78) |
8 | 10S | 0.148 (3.76) | 8.625 (219.1) | 13.41 (19.97) |
8 | 40S | 0.322 (8.18) | 8.625 (219.1) | 28.58 (42.55) |
8 | 80S | 0.5 (12.7) | 8.625 (219.1) | 43.43 (64.64) |
10 | 5S | 0.134 (3.4) | 10.75 (273) | 15.21 (22.61) |
10 | 10S | 0.165 (4.19) | 10.75 (273) | 18.67 (27.78) |
10 | 40S | 0.365 (9.27) | 10.75 (273) | 40.52 (60.29) |
10 | 80S | 0.5 (12.7) | 10.75 (273) | 54.79 (81.53) |
12 | 5S | 0.156 (3.96) | 12.75 (323.8) | 21.0 (31.24) |
12 | 10S | 0.18 (4.57) | 12.75 (323.8) | 24.19 (35.98) |
12 | 40S | 0.375 (9.53) | 12.75 (323.8) | 49.61 (73.86) |
12 | 80S | 0.5 (12.7) | 12.75 (323.8) | 65.48 (97.44) |
14 | 5S | 0.156 (3.96) | 14.0 (355.6) | 23.09 (34.34) |
14 | 10S | 0.188 (4.78) Notes (1),(2) | 14.0 (355.6) | 27.76 (41.36) |
14 | 40S | 0.375 (9.53) | 14.0 (355.6) | 54.62 (81.33) |
14 | 80S | 0.5 (12.7) | 14.0 (355.6) | 72.16 (107.4) |
16 | 5S | 0.165 (4.19) | 16.0 (406.4) | 27.93 (41.56) |
16 | 10S | 0.188 (4.78) Notes (1),(2) | 16.0 (406.4) | 31.78 (47.34) |
16 | 40S | 0.375 (9.53) | 16.0 (406.4) | 62.64 (93.27) |
16 | 80S | 0.5 (12.7) | 16.0 (406.4) | 82.85 (123.31) |
18 | 5S | 0.165 (4.19) | 18.0 (457) | 31.46 (46.79) |
18 | 10S | 0.188 (4.78) Notes (1),(2) | 18.0 (457) | 35.8 (53.31) |
18 | 40S | 0.375 (9.53) | 18.0 (457) | 70.65 (...) |
18 | 80S | 0.5 (12.7) | 18.0 (457) | 93.54 (...) |
20 | 5S | 0.188 (4.78) | 20.0 (508) | 39.82 (59.32) |
20 | 10S | 0.218 (5.54) Notes (1),(2) | 20.0 (508) | 46.1 (68.65) |
20 | 40S | 0.375 (9.53) | 20.0 (508) | 78.67 (117.15) |
20 | 80S | 0.5 (12.7) | 20.0 (508) | 104.23 (155.13) |
22 | 5S | 0.188 (4.78) | 22.0 (559) | 43.84 (65.33) |
22 | 10S | 0.218 (5.54) Notes (1),(2) | 22.0 (559) | 50.76 (75.62) |
22 | 40S | ... | 22.0 (559) | ... |
22 | 80S | ... | 22.0 (559) | ... |
24 | 5S | 0.218 (5.54) | 24.0 (610) | 55.42 (82.58) |
24 | 10S | 0.25 (6.35) | 24.0 (610) | 63.47 (94.53) |
24 | 40S | 0.375 (9.53) | 24.0 (610) | 94.71 (141.12) |
24 | 80S | 0.5 (12.7) | 24.0 (610) | 125.61 (187.07) |
30 | 5S | 0.25 (6.35) | 30.0 (762) | 79.51 (118.34) |
30 | 10S | 0.312 (7.92) | 30.0 (762) | 99.02 (147.29) |
30 | 40S | ... | 30.0 (762) | ... |
30 | 80S | ... | 30.0 (762) | ... |
Welding, brazing, mechanical, Adhesive-bonding, hubless-coupling, CSST, heat-fusion-weld, press, quick-connect, PEX, solvent-weld, SV-gasket, threaded, flanged, solder, grooved
Japan Standard | Types |
---|---|
JIS G3459 | UNS S31600 Pipe |
JIS G3468 | Large diameter welded 316 Grade Stainless Steel Pipe |
JIS G3448 | Light gauge SS 316 Pipe |
OD | NOMINAL PIPE SIZE (NPS) |
---|---|
0.84 | 1/2" |
1.05 | 3/4" |
1.315 | 1" |
1.66 | 1-1/4" |
1.9 | 1-1/2" |
2.375 | 2" |
2.875 | 2-1/2" |
3.5 | 3" |
4 | 3-1/2" |
4.5 | 4" |
Standard | Manufacturing Method | Wall Thickness Tolerance | OD Tolerance | Others | |
---|---|---|---|---|---|
Outer Diameter (mm) | Class | ||||
EN10216-5 | Hot Finished 316 Stainless Steel Seamless Pipe | +22.5%T,-15%T | 219.1~610 | D1 | T/D≤0.05 |
T1 | T/D≤0.09 | ||||
T2 | T/D>0.09 | ||||
T1 | 30~219.1 | D2 | |||
T2 | |||||
Cold Finished Stainless Steel 316 Seamless Pipe | T3 | ≤219.1 | D3 | ||
T4 | D4 | Agreement | |||
EN10297-2 | Hot Finished 316 Marine Grade Stainless Steel Seamless Pipe | T1 | D1 | ||
T2 | D2 | Agreement | |||
Cold Finished UNS S31600 Seamless Pipe | T3 | D3 | |||
T4 | D4 | Agreement | |||
EN10217-7 | 316 Stainless Steel Welded Pipe | T3 | >168.3 | D2 | |
T3 | ≤168.3 | D3 | |||
T3 | D4 | Agreement | |||
EN10296-2 | Stainless Steel 316 Welded Pipe | T3 | >168.3 | D2 | |
T3 | ≤168.3 | D3 | |||
T3 | ≤114.3 | D4 | Agreement | ||
EN10312 | 316 Marine Grade Stainless Steel Welded Pipe | T3 | Series 1 | D4 | T=0.6~2 Mm |
T3 – T4 | Series 2 | D3 – D4 | T=1~3 Mm |
316 Stainless Steel Pipe American Standard | |
---|---|
ASTM A999 | |
ASTM A312 / A312M | ASTM A790 / A790M |
ASTM A778 | ASTM A928 / A928M |
ASTM A409 / A409M | ASTM A814 / A814M |
ASTM A376 / A376M | ASTM A813 / A813M |
Stainless Steel 316 Pipe Wall Thickness | Outside Diameter / O.D. | ||
---|---|---|---|
Class | Tolerance | Class | Tolerance |
T1 | ±15%, Or ±0.6 Mm Min. | D1 | ±1.5%, Or ±0.75 Mm Min. |
T2 | ±12.5%, Or ±0.4 Mm Min. | D2 | ±1.0%, Or ±0.5 Mm Min. |
T3 | ±10%, Or ±0.2 Mm Min. | D3 | ±0.75%, Or. ±0.3 Mm Min. |
T4 | ±7.5%, Or ±0.15 Mm Min. | D4 | ±0.50%, Or ±0.1 Mm Min. |
T5 | +/- 5.0 %, Or +/- 0.10 Mm Min. |
Metric | |
Brinell Hardness | 149 |
Knoop Hardness | 169 |
Rockwell B Hardness | 80 |
Vickers Hardness | 155 |
(Oxidising conditions)
Nominal Pipe Size (NPS) | Outside Diameter (OD) | SCH 40 S | SCH 10 S | SCH 5 S | SCH 20 S | SCH 80 S | SCH 160 S | XXS | ||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
mm | inch | mm | WT mm | Kg/m Weight | WT mm | Kg/m Weight | WT mm | Kg/m Weight | WT mm | Kg/m Weight | WT mm | Kg/m Weight | WT mm | Kg/m Weight | WT mm | Kg/m Weight |
3 | 1/8 | 10.3 | 1.73 | 00.37 | 1.24 | 00.28 | 1.2 | 00.20 | 1.5 | 00.33 | 2.41 | 00.47 | - | - | - | - |
6 | 1/4 | 13.7 | 2.24 | 00.630 | 1.65 | 00.49 | 1.2 | 00.37 | 2.00 | 00.58 | 3.02 | 00.80 | - | - | - | - |
10 | 3/8 | 17.1 | 2.31 | 00.840 | 1.65 | 00.63 | 1.2 | 00.47 | 2.00 | 00.74 | 3.20 | 1.10 | - | - | - | - |
15 | 1/2 | 21.3 | 2.77 | 1.27 | 2.11 | 1.00 | 1.65 | 00.80 | 2.30 | 1.07 | 3.73 | 1.62 | 4.75 | 1.94 | 7.47 | 2.55 |
20 | 3/4 | 26.7 | 2.87 | 1.69 | 2.11 | 1.28 | 1.65 | 1.03 | 2.55 | 1.52 | 3.91 | 2.20 | 5.56 | 2.90 | 7.82 | 3.64 |
25 | 1 | 33.4 | 3.38 | 2.50 | 2.77 | 2.09 | 1.65 | 1.30 | 2.55 | 1.94 | 4.55 | 3.24 | 6.35 | 4.24 | 9.09 | 5.45 |
32 | 1.1/4 | 42.2 | 3.56 | 3.39 | 2.77 | 2.70 | 1.65 | 1.65 | 3.00 | 2.90 | 4.85 | 4.47 | 6.35 | 5.61 | 9.70 | 7.77 |
40 | 1.1/2 | 48.3 | 3.68 | 4.05 | 2.77 | 3.11 | 1.65 | 1.91 | 3.00 | 3.55 | 5.08 | 5.41 | 7.14 | 7.25 | 11.1 | 10.18 |
50 | 2 | 60.3 | 3.91 | 5.44 | 2.77 | 3.93 | 1.65 | 2.40 | 3.00 | 4.24 | 5.54 | 7.48 | 8.74 | 11.11 | 11.07 | 13.44 |
65 | 2.1/2 | 73.0 | 5.16 | 8.63 | 3.05 | 5.26 | 2.11 | 3.69 | 4.00 | 6.81 | 7.01 | 11.41 | 9.53 | 14.91 | 14.02 | 20.39 |
80 | 3 | 88.9 | 5.49 | 11.29 | 3.05 | 6.45 | 2.11 | 4.51 | 4.00 | 8.37 | 7.62 | 15.27 | 11.1 | 21.30 | 15.24 | 27.68 |
100 | 4 | 114.3 | 6.02 | 16.07 | 3.05 | 8.36 | 2.11 | 5.84 | 4.50 | 12.18 | 8.56 | 22.32 | 13.49 | 33.54 | 17.12 | 41.03 |
125 | 5 | 141.3 | 6.55 | 21.8 | 3.40 | 11.57 | 2.77 | 9.47 | 5.00 | 16.80 | 9.53 | 30.97 | 15.88 | 49.11 | 19.05 | 57.43 |
150 | 6 | 168.3 | 7.11 | 28.26 | 3.40 | 13.84 | 2.77 | 11.32 | 6.35 | 25.36 | 10.97 | 42.56 | 18.25 | 67.53 | 21.95 | 79.22 |
200 | 8 | 219.1 | 8.18 | 42.55 | 3.76 | 19.96 | 2.77 | 14.79 | 6.35 | 33.31 | 12.7 | 64.64 | 23.01 | 111.27 | 22.23 | 107.92 |
250 | 10 | 273.1 | 9.27 | 60.31 | 4.19 | 27.78 | 3.40 | 22.63 | 6.35 | 41.77 | 12.7 | 96.01 | 28.58 | 172.33 | 25.40 | 155.15 |
300 | 12 | 323.8 | 9.53 | 73.88 | 4.57 | 36.00 | 3.96 | 31.25 | 6.35 | 49.7 | 12.7 | 132.05 | 33.32 | 238.76 | 25.40 | 186.97 |
Relationship between Stainless Steel 316 Pipe Actual Outside Diameter, Schedules, NPS sizes, and Wall Thickness
NOMINAL PIPE SIZE | OD | SCH 5 | SCH 10 | SCH 40 | SCH 80 |
---|---|---|---|---|---|
1/2" | 0.84 | 0.065 | 0.083 | 0.109 | 0.147 |
3/4" | 1.05 | 0.065 | 0.083 | 0.113 | 0.154 |
1" | 1.315 | 0.065 | 0.109 | 0.133 | 0.179 |
1-1/4" | 1.66 | 0.065 | 0.109 | 0.14 | 0.191 |
1-1/2" | 1.9 | 0.065 | 0.109 | 0.145 | 0.2 |
2" | 2.375 | 0.083 | 0.109 | 0.154 | 0.218 |
2-1/2" | 2.875 | 0.083 | 0.12 | 0.203 | 0.276 |
3" | 3.5 | 0.083 | 0.12 | 0.216 | 0.3 |
3-1/2" | 4 | 0.083 | 0.12 | 0.226 | 0.318 |
4" | 4.5 | 0.083 | 0.12 | 0.237 | 0.337 |
SS 316 Control lines | 316 Marine Grade Stainless Steel Precision Pipes |
316 Marine Grade Stainless Steel Nuclear Pipes | UNS S31600 Transmission Pipes |
UNS S31600 Chemical process Pipes | 316 Grade Stainless Steel Pitot Pipes |
316 Grade Stainless Steel Medical Pipes | SS 316 encapsulated coiled Pipes |
1.4401 Stainless Steel Polish Pipes | 316 SS High Precision Pipes |
316 SS Umbilicals | 1.4401 Stainless Steel Nuclear Control Rod Pipes |
X5crnimo17-12-2 AISI 316 SS EFW Pipes | SUS 316 Seamless Pipes |
SUS 316 Hydraulic Pipes | AISI 316 Gas Pipe Ar 15 |
AISI 316 High pressure Pipes | DIN 1.4401 Stainless Steel Bourdon Pipes |
1.4408 AISI Instrumentation Pipes | 1.4408 AISI Capillary Pipes |
Alloy 316 Electropolished Pipes | Alloy 316 Furnace Pipes |
TP316 elliptical and Oval Pipes | TP316 Gas Pipes |
X5crnimo17-12-2 AISI 316 SS Seamless Heating Pipes | WNR 1.4401 Decorative Pipes |
UNS S31600 custom Pipes | 316 Stainless Steel Mortar Pipes |
316 Stainless Steel SCH 40 Pipes | Stainless Steel 316 Radiant Pipes |
SCH 80 Stainless Steel 316 Pipes | 316 Marine Grade Stainless Steel Square Pipes |
316 Marine Grade Stainless Steel Condenser Pipes | UNS S31600 Heat Exchager Pipes |
316 SS straight Pipe heat exchanger | 316 Grade Stainless Steel HSAW Pipes |
Bright Annealed UNS S31600 Pipes | 1.4401 Stainless Steel Straight Pipe boiler |
SUS 316 cold drawn seamless Pipes | Annealed Pickled 316 Marine Grade Stainless Steel Pipes |
AISI 316 Aero engine Pipes | 1.4401 Stainless Steel U Shaped Pipes |
DIN 1.4401 Stainless Steel Aerospace Engine Pipes | SUS 316 Exhaust Pipes |
X5crnimo17-12-2 AISI 316 SS Furnace Pipes | AISI 316 Condensers Pipes |
316 Stainless Steel Aerospace Pipes | DIN 1.4401 Stainless Steel Protection Pipes |
316 Stainless Steel Drawn over mandrel (DOM) | 1.4408 AISI Pipe for Heat Exchangers |
TP316 Hot finished seamless Pipe (HFS) | Alloy 316 redrawn Pipes |
WNR 1.4401 Cold drawn seamless Pipe (CDS) | TP316 seam-welded Pipes |
Stainless Steel 316 Finned Pipes | 316 Stainless Steel Chemical Process Pipes |
316 Marine Grade Stainless Steel Pipes for Precision Components | Stainless Steel 316 Welded coiled Pipes |
SS 316 Round Pipes | 316 Grade Stainless Steel header Pipes |
SS 316 Rectangular Pipes | 316 SS Cold Rolled Coiled Pipes |
SS 316 Boiler Pipes | 1.4401 Stainless Steel Seamless Hollow Pipes |
AISI 316 Hexagonal Pipes | DIN 1.4401 Stainless Steel Hollow Pipes |
X5crnimo17-12-2 AISI 316 SS thermocouple Pipes | DIN 1.4401 Stainless Steel DSAW Pipes |
X5crnimo17-12-2 AISI 316 SS Super Heater Pipes | X5crnimo17-12-2 AISI 316 SS Decorative Pipes |
TP316 ERW Pipes | Alloy 316 Oil Pipes |
WNR 1.4401 Colour Coated Pipes | TP316 Thick Wall Pipes |
316 Stainless Steel Welded Pipes | WNR 1.4401 Triangle Pipes |
Stainless Steel 316 Secondary & Surplus Pipes | 316 Stainless Steel High-strength capillary Pipes |
316 Marine Grade Stainless Steel Outside Polished Pipes | Stainless Steel 316 Bellows Pipes |
UNS S31600 Polished Pipes | 316 SS Cold Drawn Pipes |
316 Stainless Steel Electric Fusion Welding Pipes | Stainless Steel 316 LSAW Pipes |
316 Marine Grade Stainless Steel heat resistant Pipes | 1.4401 Stainless Steel seamless straight Pipes |
Stainless Steel 316 Pipe Sizes | OD | ||
---|---|---|---|
DIA | Sch 10 Stainless Steel 316 Pipe | ||
Inch | DN | Meter MM | Weight in Kg/Mtr |
1/8 Inch | DN 6 | 10.3 | |
1/4 Inch | DN 8 | 13.7 | |
3/8 Inch | DN 10 | 17.2 | |
1/2 Inch | DN 15 | 21.3 | 1.02 |
3/4 Inch | DN 20 | 26.7 | 1.3 |
1 Inch | DN 25 | 33.4 | 2.13 |
11/4 Inch | DN 32 | 24.2 | 2.73 |
11/2 Inch | DN 40 | 48.3 | 3.16 |
2 Inch | DN 50 | 60.3 | 3.99 |
21/2 Inch | DN 65 | 73 | 5.34 |
3 Inch | DN 80 | 88.9 | 6.56 |
31/2 Inch | DN 90 | 101.6 | 7.53 |
4 Inch | DN 100 | 114.3 | 8.5 |
5 Inch | DN 125 | 141.3 | 11.74 |
6 Inch | DN 150 | 168.3 | 14.04 |
8 Inch | DN 200 | 219.1 | 20.27 |
10 Inch | DN 250 | 273.1 | 28.2 |
12 Inch | DN 300 | 323.9 | 36.54 |
14 Inch | DN 350 | 355.6 | 55.53 |
16 Inch | DN 400 | 406.4 | 63.61 |
18 Inch | DN 450 | 457.2 | 71.69 |
2C Inch | DN 500 | 508 | 79.76 |
22 Inch | DN 550 | 558.8 | 87.84 |
24 Inch | DN 600 | 609.6 | 95.92 |
26 Inch | DN 650 | 660.4 | 129.4 |
28 Inch | DN 700 | 711.2 | 139.47 |
3C Inch | DN 750 | 762 | 149.55 |
32 Inch | DN 800 | 812.8 | 159.62 |
34 Inch | DN 850 | 863.6 | 169.64 |
36 Inch | DN 900 | 914.4 | 179.77 |
Inch | DN | Meter MM | Weight in Kg/Mtr |
Stainless Steel 316 Pipe Sizes | OD | ||
---|---|---|---|
DIA | SCH 10 316 Marine Grade Stainless Steel Pipe | ||
Inch | DN | Meter MM | Thickness |
1/8 Inch | DN 6 | 10.3 | |
1/4 Inch | DN 8 | 13.7 | |
3/8 Inch | DN 10 | 17.2 | |
1/2 Inch | DN 15 | 21.3 | 2.11 |
3/4 Inch | DN 20 | 26.7 | 2.11 |
1 Inch | DN 25 | 33.4 | 2.77 |
11/4 Inch | DN 32 | 24.2 | 2.77 |
11/2 Inch | DN 40 | 48.3 | 2.77 |
2 Inch | DN 50 | 60.3 | 2.77 |
21/2 Inch | DN 65 | 73 | 3.05 |
3 Inch | DN 80 | 88.9 | 3.05 |
31/2 Inch | DN 90 | 101.6 | 3.05 |
4 Inch | DN 100 | 114.3 | 3.05 |
5 Inch | DN 125 | 141.3 | 3.43 |
6 Inch | DN 150 | 168.3 | 3.43 |
8 Inch | DN 200 | 219.1 | 3.76 |
10 Inch | DN 250 | 273.1 | 4.19 |
12 Inch | DN 300 | 323.9 | 4.57 |
14 Inch | DN 350 | 355.6 | 6.35 |
16 Inch | DN 400 | 406.4 | 6.35 |
18 Inch | DN 450 | 457.2 | 6.35 |
2C Inch | DN 500 | 508 | 6.35 |
22 Inch | DN 550 | 558.8 | 6.35 |
24 Inch | DN 600 | 609.6 | 6.35 |
26 Inch | DN 650 | 660.4 | 7.92 |
28 Inch | DN 700 | 711.2 | 7.92 |
3C Inch | DN 750 | 762 | 7.92 |
32 Inch | DN 800 | 812.8 | 7.92 |
34 Inch | DN 850 | 863.6 | 7.92 |
36 Inch | DN 900 | 914.4 | 7.92 |
NPS | 1/8 to 30 |
---|---|
DN | 6 to 750 |
ID | 5S to 80S |
OD in Inch | 0.405 to 30.0 Inch |
OD in mm | 10.3 to 762 mm |
Wall Thickness in Inch | 0.049 to 0.312 inch |
Wall Thickness in mm | 1.24 to 7.92 mm |
Stainless Steel 316 Welded Pipe standard lengths | 6.0 to 6.1 metres |
---|---|
Stainless Steel 316 Seamless Pipe standard lengths | 6.0 to 7.5 metres |
OD in Inch | 0.405 to 30.0 Inch |
---|---|
Wall Thickness in Inch | 0.049 to 0.312 inch |
Element | % Present |
---|---|
Carbon (C) | 0.07 |
Silicon (Si) | 1.00 |
Manganese (Mn) | 2.00 |
Phosphorous (P) | 0.045 |
Sulfur (S) | 0.0151) |
Chromium (Cr) | 16.50 - 18.50 |
Nickel (Ni) | 10.00 - 13.00 |
Nitrogen (N) | 0.10 |
Molybdenum (Mo) | 2.00 - 2.50 |
Iron (Fe) | Balance |
Tensile Strength | 515-580 MPa |
Proof Strength, (Offset 0.2%) | 205- 310 MPa |
Elongation % | 40-55% |
BS | USA | UNS | WNR/ DIN |
316S31 | 316 | S31600 | 1.4401 |
316S33 | 316 | S31600 | 1.4436 |
Stainless Steel Pipe
ASTM Standards
Pipe Specifications
