Stainless steel 317l belongs to a low carbon austenitic grade. The Stainless Steel 317L Pipe is designed with a chemical composition consisting of iron, chromium, nickel, molybdenum, manganese, silicon, phosphorous, carbon, and sulfur. The content embedded in them allows these modules to possess enhanced corrosion and oxidation resistance properties across stress-induced environments. Stainless Steel Grade 317L Pipe works well in aqueous conditions due to the content of molybdenum within them. The lower carbon content also allows them to be resistant to sensitization and gives them higher creep-rupture properties. The 317l stainless steel tubing is non-magnetic in the annealed condition. They can be readily welded in place following standard procedure. The grade can be dual certified by the addition of a strengthening agent like nitrogen in its composition. The tubes cannot be heat treated but are usually cold worked to harden them in the system.
The ASTM A312 TP317L Seamless Pipe is produced via the extrusion process where heated steel billets are passed through the metal creating a hollow opening. The process is time-consuming and expensive due to the requirement of specialized materials. However, the WNR. 1.4438 Seamless Pipe has excellent load-bearing capacity and strength as compared to other pipes in this grade. The pipes can transport 20% higher fluids as compared to other pipe types. The SS 317L Welded Pipe is a cost-effective alternative to a seamless pipe. These welded pipes are manufactured by rolling steel and welding it in place using standard processes. A welded pipe grade has a lower load-bearing capacity but can be produced in different sizes. The AISI 317L ERW Tubes are produced by cold rolling tubes and longitudinally welding them in place by passing using a high-voltage current through them. For any queries, customization, or pricing of our products, contact us for more information.
Table of Content
Standard Specification | Stainless Steel 317/ 317L Pipe ASTM A312 Tp317/ 317L, ASTM A213 Tp317/ 317L |
Surface Finish | Polished, Bright, Cold Finish, Annealing, Pickling |
Size | ½ to 6 Inch |
Schedule Pipe Thickness Range | SCH XXS, SCH 40, SCH 160, SCH10, SCH 5, SCH 80, SCH 80S, SCH XS Supplier in Mumbai |
Types | Welded, ERW, Seamless, EFW |
Manufacturing Technology | Hot / Cold Formed |
Technique | Cold Rolled Hot Rolled |
Wall Thickness | 0.1 To 60 mm |
Manufacturing Shapes | Round, Rectangle, Square, Box Section |
Standard | ASME, EN, DIN, JIS, ASTM, AMS, GOST, AISI, GB |
Per Kg
ASTM A312 Grade Tp317l Size 33.4mm Od*4.55mm*5.2-5.8m
$ 2.58
Per Kg
Stainless Steel Od 60.3mm Sch 40s A312 Gr tp317/317l
$ 2.61
Per Kg
Stainless Steel Hot Finished Pipes 317l Od Not Less Than 42 Mm
$ 2.18
Stainless Steel 317L Pipes
ASTM A312 tp 317 SS Tubing
SS 317L Seamless Pipes
WNR. 1.4438 Welded Pipes
AISI 317L ERW Tubes
ASTM A312 TP 317L Pipes
SS Grade 317L Seamless Pipes
ASTM A213 TP317L Tubing
ASME SA312 TP317L EFW Pipes
Grade | Carbon | Manganese | Silicon | Phosphorous | Sulphur | Chromium | Molybdenum | Nickel | Flerovium |
SS 317L | 0.035 | 2.0 | 1.0 | 0.045 | 0.030 | 18.00 - 20.00 | 3.00 - 4.00 | 11.00 - 15.00 | 57.89 |
SS 317 | 0.08 | 2.0 | 1.0 | 0.045 | 0.030 | 18.00 - 20.00 | 3.00 - 4.00 | 11.00 - 15.00 | 57.845 |
Grade | Melting Point | Density | Yield Strength | Tensile Strength | Elongation |
SS 317 / SS 317L | 1400 °C (2550 °F) | 7.9 g/cm3 | Psi – 30000 , MPa – 205 | Psi – 75000 , MPa – 515 | 35 % |
Grade | Werkstoff Nr. | Unified Numbering System | Japanese Industrial Standards | European Standards |
SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
SS 317 | 1.4449 | S31700 | SUS 317 |
Pipe Size in Inch | Schedule | 100 | 750 | 300 | 500 | 600 | 700 | 650 |
---|---|---|---|---|---|---|---|---|
5 | 40 | 1342 | 797 | 1040 | 889 | 847 | 805 | 822 |
80 | 1981 | 1176 | 1535 | 1312 | 1250 | 1189 | 1213 | |
160 | 3414 | 2027 | 2646 | 2262 | 2155 | 2049 | 2091 | |
1 | 40 | 3048 | 1810 | 2362 | 2019 | 1924 | 1824 | 1867 |
80 | 4213 | 2501 | 3265 | 2791 | 2659 | 2528 | 2580 | |
160 | 6140 | 3646 | 4759 | 4068 | 3876 | 3684 | 3761 | |
6 | 40 | 1219 | 724 | 945 | 808 | 770 | 732 | 747 |
80 | 1913 | 1136 | 1483 | 1267 | 1208 | 1148 | 1172 | |
160 | 3289 | 1953 | 2549 | 2179 | 2076 | 1973 | 2014 | |
2 | 40 | 1902 | 1129 | 1474 | 1260 | 1201 | 1141 | 1165 |
80 | 2747 | 1631 | 2129 | 1820 | 1734 | 1648 | 1682 | |
160 | 4499 | 2671 | 3486 | 2980 | 2840 | 2699 | 2755 | |
3 | 40 | 1806 | 1072 | 1400 | 1196 | 1140 | 1084 | 1106 |
80 | 2553 | 1516 | 1979 | 1691 | 1612 | 1532 | 1564 | |
160 | 3840 | 2280 | 2976 | 2544 | 2424 | 2304 | 2352 | |
1 1/2 | 40 | 2257 | 1340 | 1750 | 1496 | 1425 | 1354 | 1383 |
80 | 3182 | 1889 | 2466 | 2108 | 2009 | 1909 | 1949 | |
160 | 4619 | 2743 | 3580 | 3060 | 2916 | 2772 | 2829 | |
4 | 40 | 1531 | 909 | 1187 | 1014 | 967 | 919 | 938 |
80 | 2213 | 1314 | 1715 | 1466 | 1397 | 1328 | 1355 | |
160 | 3601 | 2138 | 2791 | 2386 | 2273 | 2161 | 2206 | |
8 | 40 | 1073 | 637 | 832 | 711 | 678 | 644 | 657 |
80 | 1692 | 1005 | 1311 | 1121 | 1068 | 1015 | 1036 | |
160 | 3175 | 596 | 2460 | 2103 | 2004 | 615 | 1944 |
Outer Diameter | Nominal Pipe Size | Schedule 40S | Schedule 5S | Schedule 80S | Schedule 10S |
13.72 | 1/4 | 2.24 | 3.02 | 1.65 | |
17.15 | 3/8 | 2.31 | 3.2 | 1.65 | |
21.34 | 1/2 | 2.77 | 1.65 | 3.73 | 2.11 |
26.67 | 3/4 | 2.87 | 1.65 | 3.91 | 2.11 |
33.4 | 1 | 3.38 | 1.65 | 4.55 | 2.77 |
42.16 | 1.25 | 3.56 | 1.65 | 4.85 | 2.77 |
48.26 | 1.5 | 3.68 | 1.65 | 5.08 | 2.77 |
60.33 | 2 | 3.91 | 1.65 | 5.54 | 2.77 |
73.03 | 2.5 | 5.16 | 2.11 | 7.01 | 3.05 |
88.9 | 3 | 5.49 | 2.11 | 7.62 | 3.05 |
101.6 | 3.5 | 5.74 | 2.11 | 8.08 | 3.05 |
114.3 | 4 | 6.02 | 2.11 | 8.56 | 3.05 |
141.3 | 5 | 6.55 | 2.77 | 9.53 | 3.4 |
168.28 | 6 | 7.11 | 2.77 | 10.97 | 3.4 |
219.08 | 8 | 8.18 | 2.77 | 12.7 | 3.76 |
273.05 | 10 | 9.27 | 3.4 | 12.7 | 4.19 |
323.85 | 12 | 9.53 | 3.96 | 12.7 | 4.57 |
355.6 | 14 | 9.53 | 3.96 | 12.7 | 4.78 |
406.4 | 16 | 9.53 | 4.19 | 12.7 | 4.78 |
457.2 | 18 | 9.53 | 4.19 | 12.7 | 4.78 |
508 | 20 | 9.53 | 4.78 | 12.7 | 5.54 |
558.8 | 22 | 4.78 | 5.54 | ||
609.6 | 24 | 9.53 | 5.54 | 12.7 | 6.35 |
660.4 | 26 | ||||
711.2 | 28 | ||||
762 | 30 | 6.35 | 7.92 |
Nominal Pipe Size | Tolerance | |
+ | – | |
3~18, t/D≤ 5% | 22.5 | 12.5 |
1/8-2 1 /2 | 20.0 | 12.5 |
3~18, t/D> 5% | 15.0 | 12.5 |
≥ 20, seamless, t/D≤ 5% | 22.5 | 12.5 |
≥ 20, welded | 17.5 | 12.5 |
≥ 20, seamless, t/D> 5% | 15.0 | 12.5 |
