ASTM A312 Tp321 Seamless Pipe and SS 321 Welded Tube Supplier in India


Stainless Steel 321 Pipe

Stainless steel 321 grade is an austenitic grade of steel product. The Stainless Steel 321 Pipe is designed with a superior chemical composition consisting of chromium and nickel while being stabilized by titanium. These pipes showcase superior strength and can be utilized in an array of corrosive and reducing media. The 321 Stainless Steel Pipe can be used in temperatures between 538 to 870 degrees C. They have a minimum tensile strength of 515mpa with a minimum yield strength of 205mpa. The pipes in the SS 321 grade can be easily elongated by 40% and possess a hardness of Rockwell 95 HRB max. This versatile grade of pipes possesses an excellent forming capacity and can be welded in place following standard welding procedures.

The ASTM A312 TP321 Seamless Pipe is produced by passing hot steel billets through the extruded metal grade. This makes the pipe free of any seams or welds, allowing them to have superior load-bearing capacity in different environmental conditions. Designed with a density of 8.27 g/cm3, the Stainless Steel 321 Seamless Tube exhibits outstanding strength as compared to the seamless pipes. These tubes can be formed in square, round, rectangular cross sections allowing them to adapt to different applications. The robust 321 Stainless Steel Tubing can be either hot or cold rolled and further heat treated. These tubes are generally annealed at temperatures around 1605 degrees F, followed by a water quenching process. This gives the tubing enhanced resistance to corrosive media. EN 1.4541 Tubing can be custom designed in an array of shapes and sizes. This tubing is commonly seen in expansion joints, heat exchangers, furnace parts, aircraft exhaust manifolds, bellows, etc. If you have any questions or queries with regards to our products or want to customize them visit us or contact us for more information.

Supplier and exporter of AISI 321 ERW Pipe in Mumbai, Check weight of EN 1.4541 Tubing and UNS S32100 Stainless Steel Pipe Price in India


Stainless Steel 321 Pipe Specification

Manufacturer and Distributor of ASME SA 213 TP 321 Stainless Steel Tube for automotive and marine exhaust applications

Standard Specification ASTM A 312/ ASME SA 312/ EN10216-5
Size ½ to 6 Inch NB
Wall Thickness 0.1 To 60 mm
Manufacturing Technology Hot / Cold Formed
Standard DIN, JIS, AMS, GB, AISI, ASME, ASTM, EN, GOST
Technique Cold Rolled
Hot Rolled
Surface Finish Bright, Cold Finish, Annealing, Polished, Pickling
Schedule Pipe Thickness Range SCH 80, SCH 40, SCH XXS, SCH 5, SCH 80S, SCH10, SCH XS, SCH 160 Supplier in Mumbai
Manufacturing Shapes Round, Rectangle, Square, Box Section
Types Seamless, ERW, Welded, EFW

ASTM A312 Tp321 Seamless Pipe Price List

Trilok Steel Industries

Per Kg

Stainless Steel 321 Seamless Pipe Size 273.1mm Od X 23.90mm Thk X 5.5-6.2m

$ 3.07

Trilok Steel Industries

Per Kg

Seamless Stainless Steel Grade 321 Pipes Od Not Less Than 42 Mm

$ 2.64

Trilok Steel Industries

Per Kg

3 Sch 160s Ss Smls Pipe Gr 321(Stainless Steel Smls Pipes)


$ 17.22

SS 321 Welded Tube Types

321 SS Pipes

321 SS Pipes

Stainless Steel 321 Pipes

Stainless Steel 321 Pipes

321 Stainless Steel Pipes

321 Stainless Steel Pipes

321 Stainless Tube

321 Stainless Tube

321 Stainless Steel Tubing

321 Stainless Steel Tubing

Tp321 Stainless Steel Pipes

Tp321 Stainless Steel Pipes

321 SS Tubing

321 SS Tubing

SS 321 Seamless Pipes

SS 321 Seamless Pipes

321 Stainless Pipes

321 Stainless Pipes

AISI 321 ERW Pipe Dimension Chart

Check DIN 1.4541 Seamless Pipe, AISI 321 Tube Specification & Extra Strong (XS) Weight as per ASME B36.19M/ B36.19 Standards
Nominal Pipe Size in Inch Outside diameter in Inch Outside diameter in MM Wall thickness in MM Wall thickness in Inch Weight [lb/ft] Weight [Kg/M]
2 1/2 2.875 73.0 2.11 0.083 2.49 3.71
1/2 0.840 21.3 1.65 0.065 0.54 0.80
12 12.750 323.9 3.96 0.156 21.13 31.44
8 8.625 219.1 2.77 0.109 9.99 14.87
1 1.315 33.4 1.65 0.065 0.87 1.30
1 1/4 1.660 42.2 1.65 0.065 1.12 1.66
18 18.000 457.0 4.19 0.165 31.64 47.09
22 22.000 559.0 4.78 0.188 44.18 65.75
6 6.625 168.3 2.77 0.109 7.65 11.38
10 10.750 273.1 3.4 0.134 15.29 22.76
14 14.000 355.6 3.96 0.156 23.22 34.56
3/4 1.050 26.7 1.65 0.065 0.69 1.03
3 1/2 4.000 101.6 2.11 0.083 3.50 5.21
1 1/2 1.900 48.3 1.65 0.065 1.28 1.91
2 2.375 60.3 1.65 0.065 1.61 2.40
30 30.000 762.0 6.35 0.250 80.02 119.09
3 3.500 88.9 2.11 0.083 3.05 4.54
5 5.563 141.3 2.77 0.109 6.40 9.52
16 16.000 406.4 4.19 0.165 28.11 41.83
4 4.500 114.3 2.11 0.083 3.95 5.88
20 20.000 508.0 4.78 0.188 40.12 59.70
24 24.000 610.0 5.54 0.218 55.85 83.11

UNS S32100 Stainless Steel Pipe Pressure rating

Pipe Schedule Pipe Size in Inch Outside Diameter Inch Wall Thickness Inch Temperature
100 200 300 400 500 600 650 700 750
40 1 1/2 1.900 0.145 1629 1629 1629 1512 1404 1317 1287 1258 1229
80 1.900 0.200 2303 2303 2303 2138 1986 1862 1821 1779 1738
160 1.900 0.281 3362 3362 3362 3120 2899 2717 2657 2597 2536
40 1 1.315 0.133 2205 2205 2205 2047 1902 1783 1743 1703 1664
80 1.315 0.179 3061 3061 3061 2841 2640 2475 2420 2365 2310
160 1.315 0.250 4493 4493 4493 4170 3874 3632 3552 3471 3390
40 2 2.375 0.154 1371 1371 1371 1272 1182 1108 1083 1059 1034
80 2.375 0.218 1985 1985 1985 1843 1712 1605 1569 1534 1498
160 2.375 0.344 3283 3283 3283 3047 2831 2654 2595 2536 2477
40 3 3.500 0.216 1301 1301 1301 1208 1122 1052 1028 1005 982
80 3.500 0.300 1844 1844 1844 1712 1590 1491 1458 1425 1391
160 3.500 0.438 2787 2787 2787 2587 2403 2253 2203 2153 2103
40 4 4.500 0.237 1102 1102 1102 1023 950 891 871 851 831
80 4.500 0.337 1596 1596 1596 1482 1377 1291 1262 1233 1204
160 4.500 0.531 2611 2611 2611 2424 2552 2111 2064 2017 1970
40 5 5.563 0.258 965 965 965 896 832 780 763 746 728
80 5.563 0.375 1428 1428 1428 1325 1231 1154 1129 1103 1077
160 5.563 0.625 2474 2474 2474 2296 2133 2000 1955 1911 1866
40 6 6.625 0.280 877 877 877 814 756 709 693 677 661
80 6.625 0.432 1379 1379 1379 1280 1189 1115 1090 1065 1040
160 6.625 0.719 2382 2382 2382 2211 2054 1925 1883 1840 1797
40 8 8.625 0.322 771 771 771 716 665 623 610 596 582
80 8.625 0.500 1218 1218 1218 1131 1050 985 963 941 919
160 8.625 0.906 2298 2298 2298 2133 1982 1858 1817 1775 1734
40 10 10.750 0.365 699 699 699 649 603 565 553 540 528
80 10.750 0.594 1159 1159 1159 1075 999 937 916 895 874
160 10.750 1.125 2289 2289 2289 2124 1974 1850 1809 1768 1727

ASME SA 213 TP 321 Stainless Steel Tube Chemical compostion

Grade Carbon Silicon Manganese Nitrogen Phosphorous Sulphur Nickel Chromium Titanium
Stainless Steel 321 Pipe 0.08 1 2 9 - 12 0.045 0.030 0.10 17 - 19 5(C+N) - 0.70

DIN 1.4541 Seamless Pipe Mechanical Properties

Stocking distributor of 321 SS Tube in various shape and sizes, Buy AISI 321 Schedule 40 Pipe and ASTM A312 Type 321 Welded Pipe at factory price in Mumbai
Density Melting Point Yield Strength Tensile Strength Elongation
8.0 g/cm3 1457 °C (2650 °F) Psi - 30000 , MPa - 205 Psi - 75000 , MPa - 515 35

Equivalent of AISI 321 Schedule 40 Pipe

Standard Unified Numbering System Werkstoff Nr. European Standards Japanese Standards
Stainless Steel 321 Pipe S32100 1.4541 X6CrNiTi18-10 SUS 321

ASTM A312 Type 321 Welded Pipe Weight Chart

Outside Diameter Nominal Pipe Size Schedule 5 S Schedule 40 S Schedule 20 S Schedule 10 S Schedule 80 S Schedule 160 S XXS
mm mm inch Wall Thickness in mm WEIGHT (KGM) Wall Thickness in mm WEIGHT in Kg Wall Thickness in mm WEIGHT in Kg Wall Thickness in mm WEIGHT in Kg Wall Thickness in mm WEIGHT in Kg Wall Thickness in mm WEIGHT in Kg Wall Thickness in mm WEIGHT in Kg
10.3 3 1/8 1.2 0.20 1.73 0.37 1.5 0.33 1.24 0.28 2.41 0.47
13.7 6 1/4 1.2 0.37 2.24 0.630 2.00 0.58 1.65 0.49 3.02 0.80
17.1 10 3/8 1.2 0.47 2.31 0.840 2.00 0.74 1.65 0.63 3.20 1.10
21.3 15 1/2 1.65 0.80 2.77 1.27 2.30 1.07 2.11 1.00 3.73 1.62 4.75 1.94 7.47 2.55
26.7 20 3/4 1.65 1.03 2.87 1.69 2.55 1.52 2.11 1.28 3.91 2.20 5.56 2.90 7.82 3.64
33.4 25 1 1.65 1.30 3.38 2.50 2.55 1.94 2.77 2.09 4.55 3.24 6.35 4.24 9.09 5.45
42.2 32 1.1/4 1.65 1.65 3.56 3.39 3.00 2.90 2.77 2.70 4.85 4.47 6.35 5.61 9.70 7.77
48.3 40 1.1/2 1.65 1.91 3.68 4.05 3.00 3.55 2.77 3.11 5.08 5.41 7.14 7.25 11.1 10.18
60.3 50 2 1.65 2.40 3.91 5.44 3.00 4.24 2.77 3.93 5.54 7.48 8.74 11.11 11.07 13.44
73.0 65 2.1/2 2.11 3.69 5.16 8.63 4.00 6.81 3.05 5.26 7.01 11.41 9.53 14.91 14.02 20.39
88.9 80 3 2.11 4.51 5.49 11.29 4.00 8.37 3.05 6.45 7.62 15.27 11.1 21.30 15.24 27.68
114.3 100 4 2.11 5.84 6.02 16.07 4.50 12.18 3.05 8.36 8.56 22.32 13.49 33.54 17.12 41.03
141.3 125 5 2.77 9.47 6.55 21.8 5.00 16.80 3.40 11.57 9.53 30.97 15.88 49.11 19.05 57.43
168.3 150 6 2.77 11.32 7.11 28.26 6.35 25.36 3.40 13.84 10.97 42.56 18.25 67.53 21.95 79.22
219.1 200 8 2.77 14.79 8.18 42.55 6.35 33.31 3.76 19.96 12.7 64.64 23.01 111.27 22.23 107.92
273.1 250 10 3.40 22.63 9.27 60.31 6.35 41.77 4.19 27.78 12.7 96.01 28.58 172.33 25.40 155.15
323.8 300 12 3.96 31.25 9.53 73.88 6.35 49.7 4.57 36.00 12.7 132.05 33.32 238.76 25.40 186.97
355.6 350 14 3.96 34.36 11.13 94.59 7.92 67.80 4.78 41.3
406.4 400 16 4.19 41.56 12.7 123.30 7.92 77.83 4.78 47.29
457.2 450 18 4.19 46.81 14.27 155.80 7.92 87.71 4.78 53.26
508.0 500 20 4.78 59.25 15.09 183.42 9.53 117.14 5.54 68.61
610.0s 600 24 5.54s 82.47 17.48 255.41 9.53 141.12 6.35 94.45
