An ERW pipe is produced by passing high-voltage current to longitudinally weld the piping component. The Stainless Steel ERW Pipe is generally designed with a maximum outer diameter of 609mm. Containing good content of chromium, they have good corrosion and oxidation resistance properties. These pipes are used in the transportation of fluids and gases across different channels. Stainless Steel EFW Pipe is seen only in the high-frequency welding process. They are generally used in welding dissimilar welding material in place at high temperatures.
A Stainless Steel Welded Pipe is produced by rolling pieces of sheet or strip followed by welding them in place, making use of standard welding procedures. These pipes are utilized for moderate to low-pressure systems and are available at affordable rates. A Schedule 40 Welded Stainless Steel Pipe is amongst the most common schedule of pipe within this grade. These pipes allow for moderate to low pressure movement and transfer in the system. The Schedule 80 SS Welded Pipe, on the contrary, has a slightly higher pressure holding capacity, allowing it to process higher volumes of fluids and gases than the schedule 40 pipe. A Large Diameter Stainless Steel Welded Pipe is utilized in the construction of structural modules that are used in oil and gas, structural module applications. These pipes are generally welded in ERW, SSAW, or LSAW welding process. In a Stainless Steel Spiral Welded Pipe, an inert gas weld overlay is used to create a continuous penetration in the metal to create a strong weld. The welding process eliminates any distortion of the component due to unbalanced stress that may be induced during normal welding procedures. Our products can be customized to meet all customer requirements by our esteemed workers. For queries and additional questions about our products or their pricing, contact us or visit our outlets for more information.
Table of Content
Standard Specification | Stainless Steel ERW Pipe |
ANSI / ASME Specification | ANSI/ASME B36.10M, ANSI/ASME B36.19M |
Shapes and Types we produce | Square, Rectangle, Hex, Hydraulic, Round, Honed |
Material Surface Finish | 2B, No.8, No.1, No.4 Mirror Finish or custom Finish as per customer Requirements |
Pipe End Forming | Plain One End, Bevel one end, Beveled One End, Bevel large end, Bevel small end, Beveled end, Bevel both ends, Treaded Both Ends, Plain Both Ends, Treaded On End |
Manufacturing Type | Fabricated, Electric Resistance Welded, 100% X Ray Welded, CDW, Welded |
Various TDC Types | Polished, Annealed and Pickled, Cold Drawn, Bright Annealed |
Schedules | SCH 80, SCH 40, SCH XXS, SCH 5, SCH 80S, SCH10, SCH XS, SCH 160 |
Per Kg
Stainless Steel Seamless Pipe Grade 316l Erw sch40s 6 Mtr
$ 4.45
Per Kg
Pipe Stainless Steel Erw Pipe A 312 Tp 304 Sch 10s 6 M/pc
$ 32.02
Per Kg
Stainless Steel Welded Pipe Erw Pipe A312 Tp 304l
$ 2.42
Stainless Steel Welded Pipes
Stainless Steel EFW Pipes
Schedule 40 Welded SS Pipes
Large Diameter SS Welded Pipes
SS Spiral Welded Pipes
Schedule 80 SS Welded Pipes
EFW Stainless Steel Pipes
Stainless Steel ERW Pipes
SCH 10 SS Welded Pipes
Size in Inch | Schedule | 750 | 100 | 600 | 200 | 500 | 300 | 700 | 400 | 650 |
---|---|---|---|---|---|---|---|---|---|---|
3 | 40 | 1072 | 1806 | 1140 | 1558 | 1196 | 1400 | 1084 | 1287 | 1106 |
80 | 1516 | 2553 | 1612 | 2202 | 1691 | 1979 | 1532 | 1819 | 1564 | |
160 | 2280 | 3840 | 2424 | 3312 | 2544 | 2976 | 2304 | 2736 | 2352 | |
1 | 40 | 1810 | 3048 | 1924 | 2629 | 2019 | 2362 | 1824 | 2171 | 1867 |
80 | 2501 | 4213 | 2659 | 3634 | 2791 | 3265 | 2528 | 3002 | 2580 | |
160 | 3646 | 6140 | 3876 | 5296 | 4068 | 4759 | 3684 | 4375 | 3761 | |
8 | 40 | 637 | 1073 | 678 | 926 | 711 | 832 | 644 | 765 | 657 |
80 | 1005 | 1692 | 1068 | 1459 | 1121 | 1311 | 1015 | 1205 | 1036 | |
160 | 1885 | 3175 | 2004 | 2738 | 2103 | 2460 | 1905 | 2262 | 1944 | |
4 | 40 | 909 | 1531 | 967 | 1321 | 1014 | 1187 | 919 | 1091 | 938 |
80 | 1314 | 2213 | 1397 | 1909 | 1466 | 1715 | 1328 | 1577 | 1355 | |
160 | 2138 | 3601 | 2273 | 3106 | 2386 | 2791 | 2161 | 2566 | 2206 | |
1 1/2 | 40 | 1340 | 2257 | 1425 | 1947 | 1496 | 1750 | 1354 | 1608 | 1383 |
80 | 1889 | 3182 | 2009 | 2744 | 2108 | 2466 | 1909 | 2267 | 1949 | |
160 | 2743 | 4619 | 2916 | 3984 | 3060 | 3580 | 2772 | 3291 | 2829 | |
2 | 40 | 1129 | 1902 | 1201 | 1640 | 1260 | 1474 | 1141 | 1355 | 1165 |
80 | 1631 | 2747 | 1734 | 2369 | 1820 | 2129 | 1648 | 1957 | 1682 | |
160 | 2671 | 4499 | 2840 | 3880 | 2980 | 3486 | 2699 | 3205 | 2755 | |
5 | 40 | 797 | 1342 | 847 | 1158 | 889 | 1040 | 805 | 956 | 822 |
80 | 1176 | 1981 | 1250 | 1709 | 1312 | 1535 | 1189 | 1411 | 1213 | |
160 | 2027 | 3414 | 2155 | 2945 | 2262 | 2646 | 2049 | 2433 | 2091 | |
6 | 40 | 724 | 1219 | 770 | 1052 | 808 | 945 | 732 | 869 | 747 |
80 | 1136 | 1913 | 1208 | 1650 | 1267 | 1483 | 1148 | 1363 | 1172 | |
160 | 1953 | 3289 | 2076 | 2836 | 2179 | 2549 | 1973 | 2343 | 2014 | |
10 | 40 | 578 | 974 | 615 | 840 | 645 | 755 | 584 | 694 | 596 |
80 | 956 | 1609 | 1016 | 1388 | 1066 | 1247 | 966 | 1147 | 986 | |
160 | 1868 | 3147 | 1986 | 2714 | 2085 | 2439 | 1880 | 2242 | 1927 |
Nominal size in Inch | Wall thickness in Inch | Outside diameter in mm | Wall thickness in mm | Outside diameter in Inch | Weight [Kg/M] | Weight [lb/ft] |
---|---|---|---|---|---|---|
1/2 Inch | 0.065 | 21.3 mm | 1.65 | 0.840 | 0.80 | 0.54 |
3/4 Inch | 0.065 | 26.7 mm | 1.65 | 1.050 | 1.03 | 0.69 |
1 Inch | 0.065 | 33.4 mm | 1.65 | 1.315 | 1.30 | 0.87 |
1 1/4 Inch | 0.065 | 42.2 mm | 1.65 | 1.660 | 1.66 | 1.12 |
1 1/2 Inch | 0.065 | 48.3 mm | 1.65 | 1.900 | 1.91 | 1.28 |
2 Inch | 0.065 | 60.3 mm | 1.65 | 2.375 | 2.40 | 1.61 |
2 1/2 Inch | 0.083 | 73.0 mm | 2.11 | 2.875 | 3.71 | 2.49 |
3 Inch | 0.083 | 88.9 mm | 2.11 | 3.500 | 4.54 | 3.05 |
3 1/2 Inch | 0.083 | 101.6 mm | 2.11 | 4.000 | 5.21 | 3.50 |
4 Inch | 0.083 | 114.3 mm | 2.11 | 4.500 | 5.88 | 3.95 |
5 Inch | 0.109 | 141.3 mm | 2.77 | 5.563 | 9.52 | 6.40 |
6 Inch | 0.109 | 168.3 mm | 2.77 | 6.625 | 11.38 | 7.65 |
8 Inch | 0.109 | 219.1 mm | 2.77 | 8.625 | 14.87 | 9.99 |
10 Inch | 0.134 | 273.1 mm | 3.4 | 10.750 | 22.76 | 15.29 |
12 Inch | 0.156 | 323.9 mm | 3.96 | 12.750 | 31.44 | 21.13 |
14 Inch | 0.156 | 355.6 mm | 3.96 | 14.000 | 34.56 | 23.22 |
16 Inch | 0.165 | 406.4 mm | 4.19 | 16.000 | 41.83 | 28.11 |
18 Inch | 0.165 | 457.0 mm | 4.19 | 18.000 | 47.09 | 31.64 |
20 Inch | 0.188 | 508.0 mm | 4.78 | 20.000 | 59.70 | 40.12 |
22 Inch | 0.188 | 559.0 mm | 4.78 | 22.000 | 65.75 | 44.18 |
24 Inch | 0.218 | 610.0 mm | 5.54 | 24.000 | 83.11 | 55.85 |
30 Inch | 0.250 | 762.0 mm | 6.35 | 30.000 | 119.09 | 80.02 |
Grade | Carbon | Silicon | Manganese | Nickel | Chromium | Phosphorus | Sulfur | Nitrogen | |
---|---|---|---|---|---|---|---|---|---|
SS 304 | min. max. |
- 0.08 |
- 0.75 |
- 2.0 |
8.0 10.5 |
18.0 20.0 |
- 0.045 |
- 0.030 |
- 0.10 |
SS 304L | min. max. |
- 0.030 |
- 0.75 |
- 2.0 |
8.0 12.0 |
18.0 20.0 |
- 0.045 |
- 0.030 |
- 0.10 |
SS 304H | min. max. |
0.04 0.10 |
- 0.75 |
- 2.0 |
8.0 10.5 |
18.0 20.0 |
-0.045 | - 0.030 |
- |
Grade | SS 304 |
---|---|
Yield Strength | Psi – 30000, MPa – 205 |
Melting Point | 2550 °F |
Density | 8.0 g/cm3 |
Tensile Strength | Psi – 75000, MPa – 515 |
Elongation | 35 |
Grade | Elastic Modulus (GPa) | Electrical Resistivity (nΩ.m) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Density (kg/m3) | Specific Heat 0-100°C (J/kg.K) | Thermal Conductivity (W/m.K) | |||
---|---|---|---|---|---|---|---|---|---|
0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
SS ERW Pipe | 193 | 720 | 17.2 | 17.8 | 18.4 | 8000 | 500 | 16.2 | 21.5 |
