Stainless Steel Oval Tubes Manufacturer In India
ASTM A554 Gr 304 Flat Side Oval Tubes and SS oval steel pipe Exporter in Mumbai
A stainless steel oval grade module is designed in an elongated shape. Stainless Steel Oval Pipe is a very compact pipe that takes less space than other piping types in the system. These pipes are ideal for use in applications where there is limited space available. They have outstanding corrosion resistance properties and are seen in applications where they are susceptible to high temperatures. We are the leading Stainless Steel Oval Tubes Manufacturer In India. We believe in quality over anything and supply the best products across all our outlets. Our institution has a vast stock of oval tubes of different dimensions and sizes.
The Stainless Steel Flat Sided Oval Tube is shaped in the shape of an egg and has a flat surface. These tubes offer outstanding strength and are usually produced in seamless or welded configurations. These tubes can be easily installed across different applications. This ASTM A554 Gr 304 Flat Side Oval Tubes are produced with a superior composition of 18/8 chromium and nickel, allowing these tubes to have enhanced tolerance and resistance across stress-induced setups. A SS 316 Oval Steel Tube, on the contrary, has nearly identical chromium and nickel content, but the presence of molybdenum within these tubes gives them enhanced resistance to pitting that the SS304 tubes are susceptible to. The A554 Grade 201 Oval Tube is a common feature in mechanical applications. These tubes have good pressure ratings and tolerance within the system. Our tie-ups with the best logistical supply chains allow us to transport and supply all our products to your doorstep in a short span of time. For any questions and queries about our products or their pricing, contact us or visit any of our outlets for more information.
SS 304 flat sided oval tube and 316 Oval Tubing supplier in India, Buy Stainless Steel Oval Pipe at best price in India
Table of Content
- Stainless Steel Oval Tubes Specification Chart
- Stainless Steel Oval Pipe Price list
- ASTM A554 Gr 304 Flat Side Oval Tubes Types
- SS oval steel pipe Sizes
- ASTM A554 Gr 316 Flat Side Oval Tubes Chemical Composition
- Mechanical Properties of Stainless Steel Oval Tubes
- Equivalent of ASTM A554 Gr 201 Flat Side Oval Tubes
- SS Oval Tube Tolerance
Stainless Steel Oval Tubes Specification Chart
Supplier and exporter of ASTM A554 Gr 316 Flat Side Oval Tubes & Stainless Steel Oval Pipe in wide size range in India
| Size | 33*13, 65*25, 19*11, 45*19, 35*15, 23*12 |
| Oval Tubing Grades | 409/L, 202, 439, 321/H, 347/H, 430Ti, 316/L/H/Ti, 410, 304/L/H, 317L |
| Standards | ASTM-A270, ASTM-A790, ASTM-A789, ASTM-A213, ASTM-A269, ASTM-A249 |
| Form | Oval Tubes |
| Oval Tubing Type | Fabricated Tubes, Seamless Tubes, EFW Tubes, Welded Tubes, ERW Tubes, Cold Drawn Welded Tubes |
| Tolerance on length | Commercial Length: 6000mm +/- 30mm Fix Length: from 1200 mm up to 12000mm with a tolerance up to -0/+ 5mm |
| Oval Tubing Finish | Brushed, Seamless, Pickled, Welded, Solution Annealed and Pickled up to O.D. 219.1mm, Polished Grit 120 – 600, Mirror Polished |
Stainless Steel Oval Pipe Price list
Per Kg
Hot Dipped Flat Oval Steel Tube For Construction Material
$ 7.74
Per Kg
AISI 304 316L stainless steel oval tube for handrail
$ 3.10
Per Kg
40x80mmx24x24 stainless steel oval single slot tube
$ 2.48
ASTM A554 Gr 304 Flat Side Oval Tubes Types
Stainless Steel Flat Side Oval Tubes
ASTM A554 Gr 316 Oval Tubes
ASME SA554 Gr 304L Flat Side Oval Tubes
A554 Gr 201 Flat Side Oval Tubes
Stainless Steel Oval Pipe
ASTM A554 Gr 316L Flat Side Oval Tubes
ASTM A554 Gr 304 Oval Tubes
316 SS Oval Tubing
Stainless Steel Oval Tubes
SS oval steel pipe Sizes
Find exact length Stainless Steel Flat Side Oval Tubes as per ASTM A554 Standard, Check SS 316L oval pipe Dimension and Updated price list
| Oval Tube Sizes | |
| 11 x 19 | 0.9mm – 1.5mm |
| 12 x 23 | 0.9mm – 1.5mm |
| 13 x 33 | 0.9mm – 1.5mm |
| 15 x 33 | 0.9mm – 1.5mm |
| 19 x 45 | 0.9mm – 1.5mm |
| 25 x 65 | 0.9mm – 1.5mm |
ASTM A554 Gr 316 Flat Side Oval Tubes Chemical Composition
| Grade | Carbon | Silicon | Manganese | Phosphorous | Sulphur | Titanium | Molybdenum | Nickel | Chromium | Nitrogen | Iron | |
| 304 | min. | 8.0 | 18.0 | |||||||||
| max. | 0.08 | 0.75 | 2.0 | 0.045 | 0.030 | 10.5 | 20.0 | 0.10 | ||||
| 304L | min. | 8.0 | 18.0 | |||||||||
| max. | 0.030 | 0.75 | 2.0 | 0.045 | 0.030 | 12.0 | 20.0 | 0.10 | ||||
| 304H | min. | 0.04 | 8.0 | 18.0 | ||||||||
| max. | 0.010 | 0.75 | 2.0 | 0.045 | 0.030 | 10.5 | 20.0 | |||||
| SS 310 | 0.015 | 0.015 | 2 | 0.020 | 0.015 | 0.10 | 19.00 21.00 | 24.00 26.00 | 54.7 min | |||
| SS 310S | 0.08 | 1.00 | 2 | 0.045 | 0.030 | 0.75 | 19.00 21.00 | 24.00 26.00 | 53.095 min | |||
| SS 310H | 0.04 0.10 | 1.00 | 2 | 0.045 | 0.030 | 19.00 21.00 | 24.00 26.00 | 53.885 min | ||||
| 316 | min. | 2.03.0 | 10.0 | 16.0 | ||||||||
| max. | 0.035 | 0.75 | 2.0 | 0.045 | 0.030 | 14.0 | 18.0 | |||||
| 316L | min. | 2.03.0 | 10.0 | 16.0 | ||||||||
| max. | 0.035 | 0.75 | 2.0 | 0.045 | 0.030 | 14.0 | 18.0 | |||||
| 316TI | 0.08 | 2.0 | 10.00 14.00 | 0.045 | 0.030 | 0.75 | 2.00 3.00 | 16.00 18.00 | ||||
| 317 | 0.08 | 1 | 2 | 0.045 | 0.030 | 3.00 4.00 | 18.00 20.00 | 57.845 min | ||||
| SS 317L | 0.035 | 1.0 | 2.0 | 0.045 | 0.030 | 3.00 4.00 | 11.00 15.00 | 18.00 20.00 | 57.89 min | |||
| SS 321 | 0.08 | 1.0 | 2.0 | 0.045 | 0.030 | 5(C+N) 0.70 | 9.00 12.00 | 17.00 19.00 | 0.10 | |||
| SS 321H | 0.04 0.10 | 1.0 | 2.0 | 0.045 | 0.030 | 4(C+N) 0.70 | 9.00 12.00 | 17.00 19.00 | 0.10 | |||
| 347/ 347H | 0.08 | 1.0 | 2.0 | 0.045 | 0.030 | 9.0013.00 | 17.00 20.00 | |||||
| 410 | min. | 11.5 | ||||||||||
| max. | 0.15 | 1.00 | 1.0 | 0.040 | 0.030 | 0.75 | 13.5 | |||||
| 446 | min. | 23.0 | 0.10 | |||||||||
| max. | 0.2 | 0.75 | 1.5 | 0.040 | 0.030 | 0.50 | 30.0 | 0.25 | ||||
| 904L | min. | 4.00 | 23.00 | 19.0 | 0.10 | |||||||
| max. | 0.20 | 1.00 | 2.00 | 0.045 | 0.035 | 5.00 | 28.00 | 23.0 | 0.25 | |||
Mechanical Properties of Stainless Steel Oval Tubes
| Grade | Melting Point °C/°F | Yield Strength | Density g/cm3 | Tensile Strength | Elongation |
| 304/ 304L | 1400 °C (2550 °F) | 30000 , MPa 205 | 8.0 | 75000 , MPa 515 | 35 |
| 304H | 1400 °C (2550 °F) | 30000 , MPa 205 | 8.0 | 75000 , MPa 515 | 40 |
| 310 / 310S / 310H | 1402 °C (2555 °F) | 30000 , MPa 205 | 7.9 | 75000 , MPa 515 | 40 |
| 306/ 316H | 1400 °C (2550 °F) | 30000 , MPa 205 | 8.0 | 75000 , MPa 515 | 35 |
| 316L | 1399 °C (2550 °F) | 30000 , MPa 205 | 8.0 | 75000 , MPa 515 | 35 |
| 317 | 1400 °C (2550 °F) | 30000 , MPa 205 | 7.9 | 75000 , MPa 515 | 35 |
| 321 | 1457 °C (2650 °F) | 30000 , MPa 205 | 8.0 | 75000 , MPa 515 | 35 |
| 347 | 1454 °C (2650 °F) | 30000 , MPa 205 | 8.0 | 75000 , MPa 515 | 35 |
| 904L | 1350 °C (2460 °F) | 32000 , MPa 220 | 7.95 | 71000 , MPa 490 | 35 |
Equivalent of ASTM A554 Gr 201 Flat Side Oval Tubes
Looking for Stainless Steel Oval Tubes Manufacturer In India? Check price and available sizes of European SS 201 Oval Pipe in Mumbai
| Standard | Werkstoff Nr. | Unified Numbering System | European Standards | British Standards | GOST | Japanese Industrial Standards | AFNOR |
| 304 | 1.4301 | S30400 | X5CrNi18-10 | 304S31 | 08Х18Н10 | SUS 304 | Z7CN18‐09 |
| 304L | 1.4306 / 1.4307 | S30403 | X2CrNi18-9 / X2CrNi19-11 | 3304S11 | 03Х18Н11 | SUS 304L | Z3CN18‐10 |
| 304H | 1.4301 | S30409 | |||||
| 310 | 1.4841 | S31000 | X15CrNi25-20 | 310S24 | 20Ch25N20S2 | SUS 310 | |
| 310S | 1.4845 | S31008 | X8CrNi25-21 | 310S16 | 20Ch23N18 | SUS 310S | |
| 310H | S31009 | ||||||
| 316 | 1.4401 / 1.4436 | S31600 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 | 316S31 / 316S33 | SUS 316 | Z7CND17‐11‐02 | |
| 316L | 1.4404 / 1.4435 | S31603 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | SUS 316L | Z3CND17‐11‐02 / Z3CND18‐14‐03 |
| 316H | 1.4401 | S31609 | |||||
| 316Ti | 1.4571 | S31635 | X6CrNiMoTi17-12-2 | 320S31 | 08Ch17N13M2T | SUS 316Ti | Z6CNDT17‐123 |
| 317 | 1.4449 | S31700 | SUS 317 | ||||
| 317L | 1.4438 | S31703 | X2CrNiMo18-15-4 | SUS 317L | |||
| 321 | 1.4541 | S32100 | X6CrNiTi18-10 | SUS 321 | |||
| 321H | 1.4878 | S32109 | X12CrNiTi18-9 | SUS 321H | |||
| 347 | 1.4550 | S34700 | X6CrNiNb18-10 | 08Ch18N12B | SUS 347 | ||
| 347H | 1.4961 | S34709 | X6CrNiNb18-12 | SUS 347H | |||
| 904L | 1.4539 | N08904 | X1NiCrMoCu25-20-5 | 904S13 | STS 317J5L | SUS 904L | Z2 NCDU 25-20 |
SS Oval Tube Tolerance
| Outer Diameter | Length Tolerance | Nominal Wall Thickness | Wall Thickness Tolerance | Outside Diameter Tolerance | ||||
|---|---|---|---|---|---|---|---|---|
| Inch | MM | Inch | MM | Inch | MM | % | Inch | MM |
| 2½ | 63.5 | +⅛, -0 | +3.18, -0 | 0.065 | 1.65 | +/-10.0% | +/-0.010 | +/-0.25 |
| 2 | 50.8 | +⅛, -0 | +3.18, -0 | 0.065 | 1.65 | +/-10.0% | +/-0.008 | +/-0.20 |
| ½ | 12.7 | +⅛, -0 | +3.18, -0 | 0.065 | 1.65 | +/-10.0% | +/-0.005 | +/-0.13 |
| 6 | 152.4 | +1, -0 | +25.4, -0 | 0.109 | 2.77 | +/-10.0% | +/-0.030 | +/-0.76 |
| 1 | 25.4 | +⅛, -0 | +3.18, -0 | 0.065 | 1.65 | +/-10.0% | +/-0.005 | +/-0.13 |
| 1½ | 38.1 | +⅛, -0 | +3.18, -0 | 0.065 | 1.65 | +/-10.0% | +/-0.008 | +/-0.20 |
| ¾ | 19.1 | +⅛, -0 | +3.18, -0 | 0.065 | 1.65 | +/-10.0% | +/-0.005 | +/-0.13 |
| 3 | 76.2 | +⅛, -0 | +3.18, -0 | 0.065 | 1.65 | +/-10.0% | +/-0.010 | +/-0.25 |
| 4 | 101.6 | +⅛, -0 | +3.18, -0 | 0.083 | 2.11 | +/-10.0% | +/-0.015 | +/-0.38 |
