A polished tube is an aesthetically appealing grade that is utilized in different applications. The versatile Polished Stainless Steel Pipe is polished till there are no ridges or scratches on the surface of the pipe. This reduces corrosion build-up and adds a glow to the piping components. This pipe allows for a smooth passage of flow of fluids and gases within the system. A Stainless Steel Polished tubing has both internal and outer radius corners. The tubes can be finished in an array of surface types namely, mirror, electropolished, and so on. The ASTM A554 Gr 304 Polished Pipe is designed with a smooth surface finish. These pipes possess superior composition of chromium and nickel with other constituent items. This gives them excellent corrosion and oxidation resistance properties. They are utilized in cosmetics, food processing, pharmaceutical, vacuum systems, etc. The ASTM A554 Gr 304L Polished Tubing is a low-carbon grade that resists sensitization or formation of grain boundary on the tubes after welding procedures.
We are the Stainless Steel Polished Tube manufacturer in India who believe in quality over anything. Our esteemed workers make use of the latest technology and best raw materials to produce top-of-line products. The SS Polish Tube we produce can be custom designed in different shapes and sizes to meet different product requirements. Out tie-ups with some of the best logistical chains allow us to supply all our tubes to your doorstep within a short span of time. If you have any queries about our range of products or want to get a quote on them, contact us for more information.
Table of Content
ASTM | ASTM A249/ A269/ A270 |
Outer Diameter | 1/8 Inch to 24 Inch Nominal Bore 1/4 Inch to 24 Inch Outer Diameter sizes |
Thickness | 1 to 20 mm |
Type | Seamless, ERW, EFW, Welded, Bead Removed, Semi Seamless |
Length | Up to 6 meters |
Schedule Pipe Thickness Range | SCH XXS, SCH 10, SCH 80, SCH 40, SCH 5, SCH XS, SCH 160, SCH 80S Supplier in Mumbai |
Mill Test Certificate | EN10204 3.1 |
Finish | Electropolished finish inside and outside, BA Finish inside and outside |
Packing | Sleeved, Ends Capped, Wooden Boxed |
Per Kg
Stainless Steel 304 Polished Pipe 38.1*1.65
$ 1.09
Per Kg
SS 304 Polished 50.8*1.65 Pipe
$ 2.18
Per Kg
Stainless Steel Polished 63.5*1.65 Tube
$ 2.10
Stainless Steel Polished Pipes
SS Polished Tubing
SS Polished Pipes
Polished SS Pipes
ASTM A554 Gr 304 Polished Pipes
Polished Stainless Pipes
Polished Stainless Steel Tube
ASTM A554 Gr 304l Polished Pipes
ASTM A554 Gr 201 Polished Pipes
Nominal Pipe Size | Outside Diameter in Inch |
---|---|
1-1/2 | 1.9 |
3-1/2 | 4 |
1/2 | 0.84 |
1 | 1.315 |
3/4 | 1.05 |
2-1/2 | 2.875 |
1-1/4 | 1.66 |
2 | 2.375 |
3 | 3.5 |
Pipe Size in Inch |
Pipe Schedule | 750 | 100 | 700 | 300 | 200 | 400 | 600 | 500 | 650 |
---|---|---|---|---|---|---|---|---|---|---|
3 | 40 | 1072 | 1806 | 1084 | 1400 | 1558 | 1287 | 1140 | 1196 | 1106 |
80 | 1516 | 2553 | 1532 | 1979 | 2202 | 1819 | 1612 | 1691 | 1564 | |
160 | 2280 | 3840 | 2304 | 2976 | 3312 | 2736 | 2424 | 2544 | 2352 | |
1 | 40 | 1810 | 3048 | 1824 | 2362 | 2629 | 2171 | 1924 | 2019 | 1867 |
80 | 2501 | 4213 | 2528 | 3265 | 3634 | 3002 | 2659 | 2791 | 2580 | |
160 | 3646 | 6140 | 3684 | 4759 | 5296 | 4375 | 3876 | 4068 | 3761 | |
8 | 40 | 637 | 1073 | 644 | 832 | 926 | 765 | 678 | 711 | 657 |
80 | 1005 | 1692 | 1015 | 1311 | 1459 | 1205 | 1068 | 1121 | 1036 | |
160 | 1885 | 3175 | 1905 | 2460 | 2738 | 2262 | 2004 | 2103 | 1944 | |
10 | 40 | 578 | 974 | 584 | 755 | 840 | 694 | 615 | 645 | 596 |
80 | 956 | 1609 | 966 | 1247 | 1388 | 1147 | 1016 | 1066 | 986 | |
160 | 1868 | 3147 | 1880 | 2439 | 2714 | 2242 | 1986 | 2085 | 1927 | |
6 | 40 | 724 | 1219 | 732 | 945 | 1052 | 869 | 770 | 808 | 747 |
80 | 1136 | 1913 | 1148 | 1483 | 1650 | 1363 | 1208 | 1267 | 1172 | |
160 | 1953 | 3289 | 1973 | 2549 | 2836 | 2343 | 2076 | 2179 | 2014 | |
5 | 40 | 797 | 1342 | 805 | 1040 | 1158 | 956 | 847 | 889 | 822 |
80 | 1176 | 1981 | 1189 | 1535 | 1709 | 1411 | 1250 | 1312 | 1213 | |
160 | 2027 | 3414 | 2049 | 2646 | 2945 | 2433 | 2155 | 2262 | 2091 | |
2 | 40 | 1129 | 1902 | 1141 | 1474 | 1640 | 1355 | 1201 | 1260 | 1165 |
80 | 1631 | 2747 | 1648 | 2129 | 2369 | 1957 | 1734 | 1820 | 1682 | |
160 | 2671 | 4499 | 2699 | 3486 | 3880 | 3205 | 2840 | 2980 | 2755 | |
1 1/2 | 40 | 1340 | 2257 | 1354 | 1750 | 1947 | 1608 | 1425 | 1496 | 1383 |
80 | 1889 | 3182 | 1909 | 2466 | 2744 | 2267 | 2009 | 2108 | 1949 | |
160 | 2743 | 4619 | 2772 | 3580 | 3984 | 3291 | 2916 | 3060 | 2829 | |
4 | 40 | 909 | 1531 | 919 | 1187 | 1321 | 1091 | 967 | 1014 | 938 |
80 | 1314 | 2213 | 1328 | 1715 | 1909 | 1577 | 1397 | 1466 | 1355 | |
160 | 2138 | 3601 | 2161 | 2791 | 3106 | 2566 | 2273 | 2386 | 2206 |
Grades | Carbon | Manganese | Phosphorous | Sulphur | Silicon | Chromium | Nickel | Molybdenum |
304 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | |
304L | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | |
316 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 |
316L | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
Material | Temperture | Tensile Strength | Yield Strength | Elongation |
TP304 | 1900 (1040) | 75(515) | 30(205) | 35 |
TP304L | 1900 (1040) | 70(485) | 25(170) | 35 |
TP316 | 1900(1040) | 75(515) | 30(205) | 35 |
TP316L | 1900(1040) | 70(485) | 25(170) | 35 |
Grades | WERKSTOFF Nr | UNS NO |
---|---|---|
304 | 1.4301 | S30400 |
304L | 1.4306 | S30403 |
316 | 1.4436 | S31600 |
316L | 1.4404 | S31603 |
