Seamless pipes are amongst the strongest pipe grade in the stainless steel grade. A Stainless Steel Seamless Pipe is produced via the extrusion process, where hot steel billets are passed through the metal to precisely shape the pipes. These modules have 20% higher load-bearing capacity when compared to other pipe types in this grade. A Stainless Steel Pipe is a ferrous grade that is designed with a minimum of 11% chromium. This gives the pipe enhanced resistance to corrosive and oxidative media across harsh environments. The Cold Rolled Seamless Stainless Steel Pipe is processed soon after the hot rolling process. Designed without any welds the pipes are later run over dies where their strength and surface finish is enhanced, giving it outstanding properties. The Stainless Steel Round Pipe has a circular cross section and is usually utilized in transporting high pressure and temperature fluids and gases in the system. ASME B36.19 Stainless Steel Pipe is utilized in pressurized vessel grade where the pipes can transport high pressure or temperature fluids and gases in the system. These pipes are very strong and don’t fracture easily under stress.
A Schedule 40 Seamless Stainless Steel Pipe is the most common pipe schedule that is used in the piping industry. These pipes are used across medium pressure setups and are available at reasonable prices. The Sch 10 Ss Pipe is a grade that is preferred in low-pressure applications. These pipes perform efficiently in different applications where the load on the system is very low. In the Stainless Steel High Pressure Pipe, fluids and gases are transported efficiently at extreme pressures. These pipes are designed to operate at 15 psi or higher pressures in the system. If you have any questions or queries about our products or want to get them customized, contact us for more information.
Table of Content
Standard Specification | ASTM A 312/ ASME SA 312/ EN10216-5 |
Size | ½” to 6” NB Sch 10s, 40s, & 80s, 160s |
Wall Thickness | 0.1 - 60 mm |
Length |
|
Specialized in | Large Diameter Size Stainless Steel Pipe Supplier in India |
Surface Finish | Bright, Cold Finish, Annealing, Polished, Pickling |
Standard | JIS, GB, ASME, AISI, ASTM, AMS, EN, DIN, GOST |
Types | Seamless, ERW, Welded, EFW Supplier and Manufacturer |
Manufacturing Shapes | Round, Rectangle, Square, Box Section |
Manufacturing Technology | Hot / Cold Formed |
Inspection, Test Reports | Mill Test Certificates, EN 10204 3.1, PMI Test Reports, Mechanical Reports, Chemical Reports, NABL Approved Lab Reports, Visual Inspection Reports, Third Party Inspection, Destructive and Non Destructive Test Reports |
Technique | Cold Rolled Hot Rolled |
Schedule Pipe Thickness Range | SCH160, XS, SCH120, XXS, STD, SCH140, SCH40, SCH20, SCH60, SCH80, SCH30, SCH80, Supplier in Mumbai |
Marking | All Pipes are marked as follows: Supplier or Manufacturer’s Name, OD, Length, Standard, Grade, Thickness, Heat No. |
Value Added Services provided by Suppliers | Threading, Destructive, Beveling, Non Destructive, Cutting, Ultrasonic Testing, Polishing |
Download PDF: Catalogue 1, Catalogue 2
Per Kg
Stainless Steel Seamless Pipe 41.3*1.2*4590 Mm
$ 3.52
Per Kg
Seamless SS Pipe Hot Finished Od Than 42 Mm
$ 2.63
Per Kg
20mm diameter 0.1mm thin wall SS pipe
$ 1.34
Stainless Steel Pipes
Stainless Steel Round Pipes
Stainless Steel Seamless Pipes
Schedule 40 Seamless SS Pipes
ASME B36.19 Stainless Steel Pipes
Sch 10 Ss Pipes
Schedule 160 SS Pipes
Schedule 80 Seamless SS Pipes
SS Exhaust Pipes
SS Hexagonal Pipes
Cold Rolled Seamless SS Pipes
SS High Pressure Pipes
Grades | Carbon | Manganese | Phosphorus | Sulfur | Silicon | Nickel | Chromium | Other |
SS 304 | 0.08 | 2 | 0.04 | 0.03 | 0.075 | 8.00 11.00 | 18.00 20.00 | |
SS 304L | 0.035 | 2 .00 | 0.04 | 0.03 | 0.75 | 8.00 13.00 | 18.00 20.00 | |
SS 304H | 0.04 0.1 | 2 | 0.04 | 0.03 | 0.75 | 8.00 11 | 18.00 20 | |
SS 310 | 0.15 | 2 | 0.04 | 0.03 | 0.75 | 19.00 22 | 24.00 26 | |
SS 316 | 008 | 2.00 | 0.040 | 0.030 | 0.75 | 11.00 4.00 | 16.00 18.00 | Mo2.00- 3.00 |
SS 316L | 0.035 | 2 | 0.04 | 0.03 | 0.75 | 10.00 15 | 16.00 18 | Mo 2.00 3.00 |
SS 316H | 0_04 0.10 | I 2.00 | 0040 | 0.030 | 0.75 | 11.00 14.00 | 16.00 18.00 | Mo2.00-3.00 |
SS 317 | 0.08 | 2 | 0.04 | 0.03 | 0.75 | 11.00 14 | 18.00 20 | Mo 3.00 4.00 |
SS 321 | 0.48 | 203 | 0.04 | 0.03 | 0.75 | 9.00 13 | 17.00 20 | Ti 5XC-0.60 |
SS 347 | 0.08 | 200 | 0.04 | 0.03 | 0.75 | 7.00 13 | 17.00 20 | Cb + Ta 10 XC-1.00 |
21-6-9 | 0.04 | 8.00 | 60 | 0.03 | 1 | 5.50 7.5 | 19.00 21.5 | N 0.15 0.40 |
SS 416 | 0.15 | 1.25 | 0.066 | 0.15 | 1.00 | 12.00 14.00 |
Type | Yield | Elongation | Tensile | Rockwell Hardness |
SS 304 | 35000 75000 |
55 20 |
85000 105000 |
RB80 RB95 |
SS 304L | 30000 75000 |
55 20 |
80000 105000 |
RB75 RB95 |
SS 304H | 35,000 | 55 | 85,000 | RB80 |
SS 310 | 45,000 | 45 | 95,000 | RB85 |
SS 316 316L 316H |
35000 30000 35000 |
50 50 50 |
85000 80000 85000 |
RB80 RB75 RB80 |
SS 317 | 40,000 | 45 | 90,000 | RB85 |
SS 321 | 35000 75000 |
55 20 |
90,000 105000 |
RB80 RB95 |
SS 347 | 40,000 | 50 | 95,000 | RB85 |
21-6-9 | 60000 120000 |
45 20 |
100000 142000 |
RB9,0 RC30. |
SS 416 | 35,000 | 20 | 75,000 | RB95 |
Nominal size in Inch | Outside diameter in Inch | Outside diameter in MM | Wall thickness in Inch | Wall thickness in MM | Weight [lb/ft] | Weight [kg/m] |
---|---|---|---|---|---|---|
1/4 Inch | 0.540 | 13.7 MM | 0.088 | 2.24 | 0.42 | 0.84 |
12 Inch | 12.750 | 323.8 MM | 0.406 | 10.31 | 53.52 | 79.73 |
1/2 Inch | 0.840 | 21.3 MM | 0.109 | 2.77 | 0.85 | 1.27 |
32 Inch | 32 | 813.0 MM | 0.688 | 17.48 | 230.08 | 342.91 |
2 1/2 Inch | 2.875 | 73.0 MM | 0.203 | 5.16 | 5.79 | 8.63 |
6 Inch | 6.625 | 168.3 MM | 0.280 | 7.11 | 18.97 | 28.26 |
20 Inch | 20 | 508.0 MM | 0.594 | 15.09 | 123.11 | 183.42 |
1/8 Inch | 0.405 | 10.3 MM | 0.068 | 1.73 | 0.24 | 0.37 |
3 Inch | 3.500 | 88.9 MM | 0.216 | 5.49 | 7.58 | 11.29 |
18 Inch | 18 | 457.0 MM | 0.562 | 14.27 | 104.67 | 155.80 |
3/4 Inch | 1.050 | 26.7 MM | 0.113 | 2.87 | 1.13 | 1.69 |
24 Inch | 24 | 610.0 MM | 0.688 | 17.48 | 171.29 | 255.41 |
3 1/2 Inch | 4.000 | 101.6 MM | 0.226 | 5.74 | 9.11 | 13.57 |
5 Inch | 5.563 | 141.3 MM | 0.258 | 6.55 | 14.62 | 21.77 |
1 1/4 Inch | 1.660 | 42.2 MM | 0.140 | 3.56 | 2.27 | 3.39 |
1 Inch | 1.315 | 33.4 MM | 0.133 | 3.38 | 1.68 | 2.50 |
1 1/2 Inch | 1.900 | 48.3 MM | 0.145 | 3.68 | 2.72 | 4.05 |
14 Inch | 14 | 355.6 MM | 0.375 | 11.13 | 54.57 | 94.55 |
2 Inch | 2.375 | 60.3 MM | 0.154 | 3.91 | 3.65 | 5.44 |
4 Inch | 4.500 | 114.3 MM | 0.237 | 6.02 | 10.79 | 16.07 |
10 Inch | 10.750 | 273.0 MM | 0.365 | 9.27 | 40.48 | 60.31 |
8 Inch | 8.625 | 219.1 MM | 0.322 | 8.18 | 28.55 | 42.55 |
16 Inch | 16 | 406.4 MM | 0.500 | 12.70 | 82.77 | 123.30 |
Nominal Pipe Size Designator | Permissible Variations in Outside Diameter | |
Over In. | Under In. | |
Over 1-1/2 to 4, incl | 1/32 (0.031) | 1/32 (0.031) |
Over 8 to 18, incl | 3/23 (0.093) | 1/32 (0.031) |
Over 4 to 8, incl | 1/16 (0.062) | 1/32 (0.031) |
Description | HSN Code |
---|---|
Stainless Steel Seamless Pipe | 73041110 |
