A SS U tube is designed to allow the fluid flow to take place and prevent the entry of gas trying to get back into the area. The U Shaped Stainless Steel Tube helps seal the module and prevents the decomposition of water leading to foul odors. These tubes showcase excellent strength and protect the tubes in corrosive environments. The robust U Shaped Stainless Steel Tubing is absolutely necessary for buildings and industries for sewage and drainage applications. We are the Stainless Steel U Tube Manufacturer who makes use of the latest technology and best raw materials to produce top-of-line products. These sections we produce can be custom designed in different shapes and sizes to meet different product requirements.
The steel U tube is generally designed in seamless and welded configurations. A SS 304 Seamless U Tubing is manufactured with a superior composition of nickel and chromium. These tubes are produced via an extrusion process where hot steel billets are passed through them to shape them in precise dimensions. The Grade 304 welded U Shaped Tubes are a cost-effective alternative to the seamless tubes. These U tubes are produced as steel is rolled and welded using standard welding procedures. The versatile Stainless Steel Welded U Tube can be designed in an array of sizes and dimensions that is not possible with seamless tubes. The welded component may require processing to protect it against corrosive media. The TP304 welded heat U tube is heat treated, giving them excellent strength and torsion in the system. These U tubes are seen in oil field drilling applications to transmit fluid flow inside the pipe. If you want to avail our products or want to know more about our items, visit any of our outlets or contact us for more information.
Table of Content
Standards Specification | ASTM A213, ASME SA213 Stainless Steel U Tube |
Sizes | 6.35 Mm Outer Diameter to 273 Mm Outer Diameter |
Schedule | SCH 80, SCH10, SCH 5, SCH 160, SCH XXS, SCH 40, SCH 80S, SCH XS, |
Outside Diameter | 9.52 Outer Diameter to 50.80 mm Outer Diameter |
Wall Thickness in MM | 0.7 mm to 3.68 mm |
Length | Maximum upto 22 Meter |
Type | Seamless/ Welded |
Per Kg
13mm Stainless Steel Customized U Tube
$ 11.39
Per Kg
Inox 304 stainless steel U slot tube
$ 2.89
Per Kg
50mmx50mmx15x15 Stainless Steel U Slot Tube
$ 2.48
Stainless Steel U Tube
U Shaped Stainless Steel Tube
SS 304 Seamless U Tubing
316 Seamless U Tube
Austenitic Stainless Steel U Tube
Grade 304 welded U Shaped Tubes
Ss 316L U Tube
Stainless Steel Welded U Tube
TP304 welded heat U tube
Wall thickness in mm | 0.5 | 2 | 0.8 | 0.7 | 1 | 3.6 | 1.2 | 0.6 | 1.6 | 3.2 | 2.6 | 3 |
Outer Diameter in mm. | Weight in kg/meter | |||||||||||
9.52 | 0.112 | 0.174 | 0.154 | 0.213 | 0.249 | 0.134 | 0.317 | |||||
15.87 | 0.192 | 0.694 | 0.301 | 0.266 | 0.372 | 0.44 | 0.229 | 0.571 | ||||
10 | 0.119 | 0.184 | 0.163 | 0.225 | 0.264 | 0.141 | 0.336 | |||||
12.7 | 0.153 | 0.238 | 0.21 | 0.293 | 0.345 | 0.182 | 0.444 | |||||
44.5 | 2.125 | 3.681 | 1.299 | 1.716 | 3.304 | 2.724 | 3.113 | |||||
6 | 0.069 | 0.104 | 0.093 | 0.125 | 0.144 | 0.081 | 0.176 | |||||
25.4 | 0.311 | 1.17 | 0.492 | 0.432 | 0.61 | 1.962 | 0.726 | 0.372 | 0.952 | 1.776 | 1.482 | 1.68 |
63.5 | 3.075 | 5.391 | 2.476 | 4.824 | 3.959 | 4.538 | ||||||
14 | 0.169 | 0.264 | 0.233 | 0.325 | 0.384 | 0.201 | 0.496 | |||||
19 | 0.231 | 0.85 | 0.364 | 0.32 | 0.45 | 0.534 | 0.276 | 0.696 | 1.264 | 1.066 | 1.2 | |
25 | 0.306 | 1.15 | 0.484 | 0.425 | 0.6 | 1.926 | 0.714 | 0.366 | 0.936 | 1.744 | 1.456 | 1.65 |
31.8 | 1.49 | 2.538 | 0.918 | 1.208 | 2.288 | 1.898 | 2.16 | |||||
38 | 1.8 | 3.096 | 1.104 | 1.456 | 2.784 | 2.301 | 2.625 | |||||
50.8 | 2.44 | 4.248 | 1.488 | 1.968 | 3.808 | 3.133 | 3.585 | |||||
76.1 | 3.705 | 6.525 | 2.98 | 5.832 | 4.778 | 5.483 | ||||||
101.6 | 4.98 | 8.82 | 4 | 7,872 | 6 | 7 |
Gauge | Typical Value in Inch | Thickness Range in Inch |
---|---|---|
17 | 0.058 | 0.053 through 0.058 |
11 | 0.12 | 0.112 through 0.122 |
20 | 0.035 | 0.031 through 0.035 |
19 | 0.042 | 0.038 through 0.042 |
9 | 0.148 | 0.140 through 0.150 |
22 | 0.028 | 0.025 through 0.029 |
18 | 0.049 | 0.044 through 0.049 |
10 | 0.134 | 0.126 through 0.136 |
16 | 0.065 | 0.060 through 0.065 |
15 | 0.072 | 0.066 through 0.074 |
13 | 0.095 | 0.087 through 0.097 |
12 | 0.109 | 0.101 through 0.111 |
14 | 0.083 | 0.075 through 0.085 |
8 | 0.165 | 0.157 through 0.167 |
7 | 0.18 | 0.175 through 0.185 |
Outer Daimeter (Fraction) | Outer Daimeter (Decimal) | 0.109 | 0.065 | 0.083 | 0.035 | 0.095 | 0.120 | 0.028 | 0.049 | 0.058 | 0.072 |
3/16 | 0.188 | 4062 | 7108 | 5077 | |||||||
13404 | 23457 | 16755 | |||||||||
1/4 | 0.250 | 7091 | 3055 | 6327 | 5345 | 3818 | |||||
23400 | 10080 | 20880 | 17640 | 12600 | |||||||
5/16 | 0.313 | 5664 | 2440 | 7232 | 5054 | 4270 | 3050 | 6274 | |||
18690 | 8051 | 23866 | 16677 | 14089 | 10064 | 20703 | |||||
1/8 | 0.125 | 6109 | 10691 | 7636 | |||||||
20160 | 35280 | 25200 | |||||||||
3/8 | 0.375 | 7927 | 4727 | 2036 | 6909 | 6036 | 8727 | 4218 | 3564 | 2545 | 5236 |
26160 | 15600 | 6720 | 22800 | 19920 | 28800 | 13920 | 11760 | 8400 | 17280 | ||
7/16 | 0.438 | 6787 | 4047 | 1743 | 5915 | 5168 | 7472 | 3611 | 3051 | 2179 | 4483 |
22397 | 13356 | 5753 | 19521 | 17055 | 24658 | 11918 | 10068 | 7192 | 14795 | ||
7/8 | 0.875 | 3397 | 2026 | 873 | 2961 | 2587 | 3740 | 1808 | 1527 | 1091 | 2244 |
11211 | 6686 | 2880 | 9771 | 8537 | 12343 | 5966 | 5040 | 3600 | 7406 | ||
9/16 | 0.563 | 5280 | 3149 | 1356 | 4602 | 4021 | 5813 | 2810 | 2374 | 1695 | 3488 |
17425 | 10391 | 4476 | 15187 | 13268 | 19183 | 9272 | 7833 | 5595 | 11510 | ||
1 3/4 | 1.750 | 1699 | 1013 | 436 | 1481 | 1294 | 1870 | 904 | 764 | 545 | 1122 |
5606 | 3343 | 1440 | 4886 | 4269 | 6171 | 2983 | 2520 | 1800 | 3703 | ||
1 1/8 | 1.125 | 2642 | 1576 | 679 | 2303 | 2012 | 2909 | 1406 | 1188 | 848 | 1745 |
8720 | 5200 | 2240 | 7600 | 6640 | 9600 | 4640 | 3920 | 2800 | 5760 | ||
5/8 | 0.625 | 4756 | 2836 | 1222 | 4145 | 3622 | 5236 | 2531 | 2138 | 1527 | 3142 |
15696 | 9360 | 4032 | 13680 | 11952 | 17280 | 8352 | 7056 | 5040 | 10368 | ||
11/16 | 0.688 | 4321 | 2577 | 1110 | 3766 | 3290 | 4757 | 2299 | 1942 | 1387 | 2854 |
14259 | 8503 | 3663 | 12427 | 10858 | 15698 | 7587 | 6410 | 4578 | 9419 | ||
1/2 | 0.500 | 5945 | 3545 | 1527 | 5182 | 4527 | 6545 | 3164 | 2673 | 1909 | 3927 |
19620 | 11700 | 5040 | 17100 | 14940 | 21600 | 10440 | 8820 | 6300 | 12960 | ||
3/4 | 0.750 | 3964 | 2364 | 1018 | 3455 | 3018 | 4364 | 2109 | 1782 | 1273 | 2618 |
13080 | 7800 | 3360 | 11400 | 9960 | 14400 | 6960 | 5880 | 4200 | 8640 | ||
1 | 1.000 | 2973 | 1773 | 764 | 2591 | 2264 | 3273 | 1582 | 1336 | 955 | 1964 |
9810 | 5850 | 2520 | 8550 | 7470 | 10800 | 5220 | 4410 | 3150 | 6480 | ||
1 1/4 | 1.250 | 2378 | 1418 | 611 | 2073 | 1811 | 2618 | 1265 | 1069 | 764 | 1571 |
7848 | 4680 | 2016 | 6840 | 5976 | 8640 | 4176 | 3528 | 2520 | 5184 | ||
1 1/2 | 1.500 | 1982 | 1182 | 509 | 1727 | 1509 | 2182 | 1055 | 891 | 636 | 1309 |
6540 | 3900 | 1680 | 5700 | 4980 | 7200 | 3480 | 2940 | 2100 | 4320 | ||
2 | 2.000 | 1486 | 886 | 382 | 1295 | 1132 | 1636 | 791 | 668 | 477 | 982 |
4905 | 2925 | 1260 | 4275 | 3735 | 5400 | 2610 | 2205 | 1575 | 3240 |
Grades | Carbon | Sulfur | Manganese | Silicon | Nickel | Phosphorus | Chromium | Molybdenum |
TP304 | 0.08 | 0.03 | 2 | 1 | 8.0-11.0 | 0.045 | 18.0-20.0 | |
TP304L | 0.035 | 0.03 | 2 | 1 | 8.0-13.0 | 0.045 | 18.0-20.0 | |
TP316 | 0.08 | 0.03 | 2 | 1 | 11.0-14.0 | 0.045 | 16.0-18.0 | 2.0-3.0 |
TP316L | 0.035 | 0.03 | 2 | 1 | 10.0-14.0 | 0.045 | 16.0-18.0 | 2.0-3.0 |
Grade | Yield Strength | Temperure | Heat | Tensile Strength | Elongation |
Ksi (MPa), Min. | º F(º C) | Treatment | Ksi (MPa), Min. | ||
TP304 | 30(205) | 1900 (1040) | Solution | 75(515) | 35 |
TP304L | 25(170) | 1900 (1040) | Solution | 70(485) | 35 |
TP316 | 30(205) | 1900(1040) | Solution | 75(515) | 35 |
TP316L | 25(170) | 1900(1040) | Solution | 70(485) | 35 |
